Active Directional Log Periodic Antenna 700mhz - 4ghz

US $1,498.00

Auw, Germany
Jan 29th

Open on mobile:
QR code

HyperLOG 7040 X 700MHz to 4GHz active LogPeriodic Antenna with 44dBi gain! Details see manufacturers website at aaronia.com Only US$ 1498 incl. worldwide EXPRESS shipping and 10 years warranty! Picture shows the antenna with optional laser Compatible with any Spectrum Analyzer brand Design: ACTIVE Logarithmic-Periodic (LogPer) Frequency range: 700MHz to 4GHz Nominal impedance: 50 Ohm VSWR: <1:2 (typ.) Gain: 44dBi (typ.) Antenna factor: See data sheet graph RF connection: SMA (f) or N (see optional adapter) Tripod connection: 1/4" Interface: USB 2.0/1.1 Calibration points: 333 (10MHz-steps) Dimensions (L/W/D): 340x200x25 mm Weight: 400gr Warranty: 10 years Highlights: Ultra high gain for detecting even lowest RF sources Integrated Low Noise Preamplifier incl. LiPo battery Runs with battery or external power supply (included) Integrated calibration data on EEprom (readout via USB) Additional standard calibration data (on CD) Special designed radome for perfect antenna protection Gold coating for stable performance Wide bandwidth Coverage of various mobile radio frequency ranges Suitable for field-strength and EMC measurements due to high precision Compact and sturdy design Can be used in the lab and for open-field application Included in delivery: Active LogPer HyperLOG 7040 X antenna Low Noise Preamplifier with integrated LiPo battery (3,5h run time) International battery charger and power supply Calibration data on EEprom (readout via USB) Typical calibration data with 333 calibration points (10MHz steps!) on CD Large aluminum carrying case with foam protection Pistol grip with mini tripod function Aaronia SMA tool set with over-torque protection Aaronia AG, Gewerbegebiet Aaronia AG, DE-54597 Euscheid, Germany Tel. ++49(0)6556-93033, Fax ++49(0)6556-93034 Email:mail@aaronia.de URL:www.aaronia.com
