Adafruit Feather 32u4 Rfm95 Lora Packet Radio Transceiver 900mhz Iot Arduino

US $920

Carrollton, Texas, United States
Jun 13th

Open on mobile:
QR code

Atoms Industries Adafruit Feather 32u4 RFM95 LoRa Radio - 900MHz Details: Feather 32u4 LoRa Radio SX1276 LoRa based module with SPI interface Packet radio with ready-to-go Arduino libraries Description Feather is the new development board from Adafruit, and like its namesake it is thin, light, and lets you fly! We designed Feather to be a new standard for portable microcontroller cores. This is the Adafruit Feather 32u4 LoRa Radio (RFM9x) - our take on an microcontroller with a "Long Range (LoRa)" packet radio transceiver with built in USB and battery charging. Its an Adafruit Feather 32u4 with a 868/915 MHz radio module cooked in! Great for making wireless networks that can go further than 2.4GHz 802.15.4 and similar, are more flexible than Bluetooth LE and without the high power requirements of WiFi. We have other boards in the Feather family, check'em out here. This is the 900 MHz radio version, which can be used for either 868MHz or 915MHz transmission/reception. We also sell a 433MHz version of the same radio chipset! And if you don't need LoRa radio, we have plain 900MHz packet radios as well At the Feather 32u4's heart is at ATmega32u4 clocked at 8 MHz and at 3.3V logic, a chip setup we've had tons of experience with as it's the same as the Flora. This chip has 32K of flash and 2K of RAM, with built in USB so not only does it have a USB-to-Serial program & debug capability built in with no need for an FTDI-like chip, it can also act like a mouse, keyboard, USB MIDI device, etc. To make it easy to use for portable projects, we added a connector for any of our 3.7V Lithium polymer batteries and built in battery charging. You don't need a battery, it will run just fine straight from the micro USB connector. But, if you do have a battery, you can take it on the go, then plug in the USB to recharge. The Feather will automatically switch over to USB power when its available. We also tied the battery thru a divider to an analog pin, so you can measure and monitor the battery voltage to detect when you need a recharge. Here's some handy specs! Like all Feather 32u4's you get: Measures 2.0" x 0.9" x 0.28" (51mm x 23mm x 8mm) without headers soldered in Light as a (large?) feather - 5.5 grams ATmega32u4 @ 8MHz with 3.3V logic/power 3.3V regulator with 500mA peak current output USB native support, comes with USB bootloader and serial port debugging You also get tons of pins - 20 GPIO pins Hardware Serial, hardware I2C, hardware SPI support 8 x PWM pins 10 x analog inputs Built in 100mA lipoly charger with charging status indicator LED Pin #13 red LED for general purpose blinking Power/enable pin 4 mounting holes Reset button This Feather 32u4 LoRa Radio uses the extra space left over to add an RFM9x LoRa 868/915 MHz radio module. These radios are not good for transmitting audio or video, but they do work quite well for small data packet transmission when you need more range than 2.4 GHz (BT, BLE, WiFi, ZigBee). SX1276 LoRa® based module with SPI interface Packet radio with ready-to-go Arduino libraries Uses the license-free ISM bands (ITU "Europe" @ 433MHz and ITU "Americas" @ 900MHz) +5 to +20 dBm up to 100 mW Power Output Capability (power output selectable in software) ~300uA during full sleep, ~120mA peak during +20dBm transmit, ~40mA during active radio listening. Simple wire antenna or spot for uFL connector Our initial tests with default library settings: over 1.2mi/2Km line-of-sight with wire quarter-wave antennas. (With setting tweaking and directional antennas, 20Km is possible). Comes fully assembled and tested, with a USB bootloader that lets you quickly use it with the Arduino IDE. We also toss in some headers so you can solder it in and plug into a solderless breadboard. You will need to cut and solder on a small piece of wire (any solid or stranded core is fine) in order to create your antenna. Lipoly battery and USB cable not included but we do have lots of options in the shop if you'd like! Check out Adafruit Learning System tutorial for all sorts of details including pinouts, power management, Arduino IDE setup, and more! Notes and Resources Want to get up and running quickly? Check out the Adafruit Learning System tutorial Light soldering required Lipo battery, breadboard, antenna, USB Cable, etc are NOT included Datasheet(s) SX1272 RFM9X What's included 1x Adafruit Feather 32u4 RFM95 LoRa Radio - 900MHz Male Headers You may also like... Portable power! This board has a built in charger, so you may want to grab a lithium battery to go with it Want to check out more of the Adafruit Feather line? See what other Adafruit Feather board are available FAQ Do you offer combined shipping? Combined shipping discounts are provided automatically through the Add To Cart feature. Most additional items added to the cart ship at a highly discounted rate. Be sure to check out the Atoms Industries Store, the more you buy the more you save! Payment Policy Paypal, credit card (Paypal account is not required), and any other option Paypal offers you are accepted. Order must ship to a confirmed address, otherwise payment will be refunded and order cancelled. Immediate payment is required. Shipping Policy You can not change your address after you have placed your order. Please check that your address is correct. Orders ship on the same or next business day. On most Saturdays too, but there is no guarantee on that. 99.9% of the time the day the label is created is the day the post office gets your package. Return Policy Returns are accepted only if the item has not been damaged or opened. The item must be returned in resalable condition within 14 days of delivery. Buyer pays return shipping. "Return to sender" packages will not be refunded shipping costs. Atoms Industries About us Since starting in 2012 Atoms Industries has come a long way. Even though it is very much a small business, it is my only business. I use every working moment I have to make this the company I have always wanted I worked for. The kind of company I would happily give my business. -Ben
