Adtran Opti-3 19-in. Or 23-in. Rackmount Chassis

US $310.00

Los Angeles, California, United States
Feb 18th

Open on mobile:
QR code

Overview:Service providers are continually challenged to provide cost-effective DS3 service off SONET rings and point-to-point. Some common types of deployment are to cell sites and customer premises.The ADTRAN® OPTI-3TM sets a new mark for OC-3 multiplexers, delivering three DS3 circuits from a single OC-3 feed. Designed to meet the growing demand for DS3 deployment in today’s economy, the OPTI-3 eliminates the need for expensive SONET multiplexer equipment in terminal mode applications and provides the fullest use of OC-3 capacity.The OPTI-3 is interoperable with other SONET devices complying with GR-253 for easy deployment in new and existing SONET networks. A carrier-class device, the OPTI-3 meets the needs of applications that require extended temperature range operation such as remote terminals. The fully integrated design supports optional redundancy and is easily managed with support for TL1 commands over the Data Communications Channel (DCC). Additional management features include a local craft interface, remote alarm transport via DCC, and alarm reporting to legacy alarm systems. Front panel LEDs conveniently display status information.The unit requires only a fraction of the footprint normally needed for optical deployments. The space-saving OPTI-3 occupies standard slots in either a small two rack unit high wallmount chassis (WMC) or one rack unit high rackmount chassis (RMC). The OPTI-3 can also be configured to operate redundantly with optional protection. It can upgrade online from unprotected to protected status.The DS3 BNC coax connectors are located on the rear of the OPTI-3 chassis. This permits easy access to the customer side of the network for a convenient demarcation point, or to extend services to DS3 multiplexer applications. The fiber optics enter the chassis from the front of the unit and terminate on the card with a dual SC connector for simple installation. The unit provides for external auxiliary alarm inputs, and the RMC chassis provides additional alarm outputs for CO alarms. Features:One GR-253 compliant OC-3 port, three DS3 ports1+1 optical and 1:1 electrical protection, 1+1 SONET Automatic Protection Switch (APS)Interoperable with industrystandard SONET multiplexersTwo or, with redundancy, four SM fibers at 1310 nm over a 40 km range or 1550 nm over an 80 km rangeDS3 signals, channelized/ unchannelizedSpace-saving wallmount chassis (WMC) or a one rack unit high 19-in. or 23-in. rackmounted chassis (RMC)Single card, hot swappable solution increases reliability and reduces costManagement functions over the DCC, TL-1 (including GNE), and SNMPLocal craft port interface for local management and Telnet for remote menu operationTelcordia OSMINE compliant and NMA (via DCC) supportedAlarm historyManagement of subtended units via IP/DCCNEBS Level 3 compliantIndustry-leading 10-year warrantyFront Panel FeaturesLEDsBoard statusOptics statusDS3-1DS3-2DS3-3ACOSwitchesACOTest/APS enableAPSCraft interface connectorMechanicalDimensions of WMC: 3.5 in. H x 6 in. W x 12 in. DMounting of WMC: Wall, shelf, or cabinet mountableDimensions of RMC: 1.75 in. H x 13.5 in. W x 12 in. DMounting of RMC: 19-in. or 23-in. rack mountableInterfacesSingle OC-3 standard optical interface to network with dual SC connectorGR-253 compliant, 1310 nm or 1550 nm3 DS3 level signals with standard 75 ohm BNC connectors, DS3 or DS3 UNI2 BITS clock inputs, wire wrapElectricalPower Requirements–48 VDC nominal (–42 to –56 VDC) or +24 VDC nominal (+22 to +26 VDC) or –24 VDC nominal (–22 to –26 VDC)8.5 watts nominal at –48 VDCRegulatory StandardsNEBS Level 3GR-1089-CORE, Issue 3NRTL Safety ListedGR-63-CORE, Issue 2EnvironmentalRackmount ChassisOperating temperature: –40°C to +65°C (19 in. and 23 in.)Storage temperature: –40°C to +85°C (19 in. and 23 in.)Relative humidity: 5 to 95 percent, noncondensingWallmount ChassisOperating temperature: –40°C to +70°CStorage temperature: –40°C to +50°CRelative humidity: 5 to 95 percent, noncondensing

“Now bidding on a new Adtran Opti Multiplexer open item unused still in original packaging. We guarantee item to be ready for your business needs. Please take a look at its pictures to ensure that you are aware of what you see is what you get in mint pristine quality.”

Type	Expansion Module
MPN	H15G2612
Brand	ADTRAN
Accessories Included	Cables
Model	OPTI-3 19/23IN RACK MT CHASS
Country/Region of Manufacture	China
