Ae20125 10 Mhz Sweep Dds Function Generator Kit With Usb And Modulation

US $72.98

Wuppertal, Germany
Jan 29th

Open on mobile:
QR code

ASCEL ELECTRONIC Revision 3: Improved Performance! Many improvements: multilayer PCB, firmware updates over USB, increased signal quality... AE20125 10MHz Sweep DDS Function Generator Kit with Modulation and USB DESCRIPTION: The AE20125 is a kit for a 10 MHz DDS Function Generator with Sweep, Frequency- and Phase Modulation and USB Sine (0.1 Hz to 10 MHz), Triangle and Square wave (0.1 Hz to 2.5 MHz) Frequency Resolution: 0.1 Hz over the whole range Output Amplitude: 0 - 5Vpp, 50 Ohm impedance DC Offset: 10V (-5V to +5V) Sweep: start, stop and sweep frequency as well as direction and type (Start->Stop->... or Start->Stop->Start->...) adjustable, Sync-Output Modulation: frequency and phase modulation, internal or external modulation source, adjustable internal frequency PLL Display function with -factor and -offset for the use as a PLL reference 5 storable Presets USB Interface (optional, see below) full software control, software inclusive. Data format fully documented Frequency Accuracy: 50ppm out-of-the-box, menu-based calibration for even greater accuracy Yellow-green or blue LCD with backlight All settings can be stored, start-up frequency and waveform adjustable A comprehensive printed 64 pages Assembly and Operation Manual is included (in english, german and english manuals in PDF format also available on the enclosed CD). The manual covers all the techniques needed including soldering. All SMD parts are pre-assembled, only through-hole components have to be soldered! The kit contains all necessary parts, the programmed and tested microcontroller, the high quality, E-Tested PCB with gold finish and a 2x16 LCD with backlight. No additional parts or components are required! Yellow-green or blue backlight is selectable at no additional cost. A machined enclosure is also available (see below). This kit is also suitable for beginners in electronics. We provide continuous support before and after you buy. Please contact us if you have any questions. Also if you need a modification or a device custom built to your needs. OPTIONS: USB Interface: The USB option is available for only $7. It provides an USB 1.1/2.0 interface that allows reading out the values and full software control. The software is included. It also allows firmware updates, which will add new features in the future. Screenshot of the included software. The plain text data format is fully documented in the included documentation to allow simple integration with external tools and systems. A matching USB-A-A cable is available here. Display: Two displays with backlight are available for no extra charge: yellow-green (-YG) and blue (-BL). Case Enclosure: A machined enclosure with all needed cut-outs and labeling is available for $16. Size: (WxHxL) 110x60x107mm (4.33"x2.36"x4.21"). Accessories: 15V Mains Adapter (220V Euro plug): $11 15V Mains Adapter (120V US/Canada plug): $11 SPECIFICATIONS: Waveforms: Sinus, Square, Triangle Max. Frequency: Sinus: 0.1 Hz - 10 MHz Square: 0.1 Hz - 2.5 MHz Triangle: 0.1 Hz - 2.5 MHz Adjustment Step: 0.1 Hz over the whole range Accuracy: 50ppm (calibratable) Max. Amplitude: 5Vpp DC Offset: 10V (-5V to +5V) Output Impedance: 50 Ohm Modulation: FSK, PSK FSK Frequency Swing: ±0.1 Hz - 10 MHz PSK Phase Swing: ±0.1° - 359.9° Modulation Source: intern, extern Internal Modulation Frequency: 0.1 Hz - 1 kHz Sweep Range: 0.1 Hz - 10 MHz Sweep Cycle Frequency: 0.1 Hz - 10 Hz Display: 2x16 characters dot-matrix LCD with backlight PLL Factor: 1x - 9999.9x PLL Offset: ±1 Hz - 1 GHz PC Interface: USB 1.1/2.0 (optional) Supply Voltage: 14-18V DC Payments: PayPal or Bank Transfer (SEPA). We ship worldwide! Shipping and handling: $13 registered with tracking number. We ship within 24 hours of receiving cleared payment! No shipping costs for additional items. Check out the Ascel Electronic Shop for additional kits (LC Meter, 5.8 GHz Frequency Counter / Power Meter), Kelvin(Four Wire) and SMD Test Clips, Breadboard Jumper Wires etc.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	AE20125
Manufacturer	Ascel Electronic
MPN	AE20125
Country/Region of Manufacture	Germany
