Ae20401 5.8 Ghz Frequency Counter / Rf Power Meter / Pulse Counter Kit

US $72.98

Wuppertal, Germany
Jun 9th

Open on mobile:
QR code

ASCEL ELECTRONIC AE20401 5.8 GHz Frequency Counter / 8 GHz Power Meter / Pulse Counter with USB DESCRIPTION: The AE20401 is a kit for a 5.8 GHz Frequency Counter/ Power Meter / Pulse Counter that measures Frequency, Period, RPM and Power The AE20401 is a versatile instrument that combines three different functions: A Frequency Counter - from mHz to 5.8 GHz Power Meter - 500 MHz / 85 dB or 8 GHz / 50 dB Pulse Counter - adjustable number of pulses per count, external gate input The USB Interface allows to readout the measured values of all modes and control all functions. The included software (see below) also enables advanced features like charting, logging, pass/fail, statistics etc. Yellow/green or blue LCD with backlight for no extra charge. CHANNEL A (2 Hz - 80 MHz): Low frequency input of the Frequency Counter. Resolution up to 0.001 Hz due to reciprocal counting algorithms Modes: Frequency, Period, RPM Sensitivity: from 50mV rms (frequency dependent) Adjustable Sensitivity/Attenuation to suppress noise and distortion Adjustable Trigger slope Offset Function: multiplies the value with a factor and adds/subtracts another value Smooth Function: displays a moving average for easier reading of unstable values Gate indicator Adjustable number of pulses per revolution for RPM Mode Channel C (Pulse Counter): Dedicated Pulse Counter can be used in many ways, e.g. as an event counter Adjustable number of pulses per count Control via keys (local), external Gate Input (on the back) or USB A comprehensive printed 64 pages Assembly and Operation Manual is included (in english, german and english manuals in PDF format also available on the enclosed CD). The manual covers all the techniques needed including soldering. All SMD parts are pre-assembled, only through-hole components have to be soldered! The kit contains all necessary parts, the programmed and tested microcontroller, the high quality, E-Tested PCB with gold finish and a 2x16 LCD with backlight. No additional parts or components are required! Yellow-green or blue backlight is selectable at no additional cost. A machined enclosure is also available (see below). This kit is also suitable for beginners in electronics. We provide continuous support before and after you buy. Please contact us if you have any questions. Also if you need a modification or a device custom built to your needs. OPTIONS: Channel B (70 MHz - 5.8 GHz): The module AE204017 adds the Channel B to the Frequency Counter, ranging from 70 MHz to 5.8 GHz - this extends the scope of application to the microwave band. Modes: Frequency, Period Offset and Smooth function Sensitivity: from 20mV rms (frequency dependent) The module is also available separately in the shop. The module is fully assembled and individually tested! Power Meter: The modules AE204015 and AE204014 add a full-featured Power Meter to the Frequency Counter turning it into an essential tool especially for radio amateurs and everyone who needs to measure power of RF signals. Resolution: 0.1 dBm Display in: dBm, mW, Vrms, Vp, Vpp External attenuators can be automatically included in the displayed value. The modules are also available separately in the shop. The modules are fully assembled and individually tested! AE204015: Frequency Range: DC - 500 MHz Input Range: -55 dBm - +30 dBm (3 Nanowatt - 1 Watt) AE204014: Frequency Range: 10 MHz - 8 GHz Input Range: -55 dBm to -5 dBm 1ppm TCXO Time Base: Replaces the standard time base with the TCXO module AE204011 with 1ppm frequency tolerance - this greatly improves the accuracy of the measurements. The module is also available separately in the shop. The module is fully assembled and individually tested! USB Interface: The USB option is available for only $7. It provides an USB 1.1/2.0 interface that allows reading out the values and full software control of all functions. The software is included. It also allows firmware updates, which will add new features in the future. Screenshot of the included software. The plain text data format is fully documented in the included documentation to allow simple integration with external tools and systems. Display: Two displays with backlight are available for no extra charge: yellow-green (-YG) and blue (-BL). Case Enclosure: A machined enclosure with all needed cut-outs and labeling is available for $16. Size: (WxHxL) 110x60x107mm (4.33"x2.36"x4.21"). Accessories: Mains Adapter (220V Euro plug): $7 SPECIFICATIONS: (Summary) Channel A: Frequency Range: 2 Hz - 80 MHz Modes: Frequency, Period, RPM Functions: Offset, Smooth, Trigger Edge Sensitivity: from 50mV rms (frequency dependent) Sensitivity/Attenuation adjustable Number of pulses per revolution for RPM Mode: adjustable Coupling: AC Impedance: 1 MOhm Input: BNC Channel B: Frequency Range: 70 MHz - 5.8 GHz Modes: Frequency, Period Functions: Offset, Smooth Sensitivity: from 20mV rms (frequency dependent) Coupling: AC Impedance: 50 Ohm Input: SMA Channel C (Pulse Counter): Frequency Range: 2 Hz - 5 MHz Number of pulses per Count: adjustable Control: local, external Gate Input, USB Power Meter: Frequency Range: DC - 500 MHz or 10 MHz - 8 GHz Input Range: -55 dBm - +30 dBm or -55 dBm to -5 dBm Resolution: 0.1 dBm Functions: external attenuator Impedance: 50 Ohm Input: SMA Calibratable: yes Time Base: Standard: 50ppm max. TCXO option: 1ppm Calibratable: yes (manual or automatically with an 10 MHz reference signal) General: Decimal Point and Thousands Separator selectable for different regions Display: 2x16 characters dot matrix LCD with backlight PC Interface: USB 1.1/2.0 (optional) Supply Voltage: 8-12V DC Power Consumption: 3W max. Payments: PayPal or Bank Transfer (SEPA). We ship worldwide! Shipping and handling: $13 registered with tracking number. We ship within 24 hours of receiving cleared payment! No shipping costs for additional items. Check out the Ascel Electronic Shop for additional kits (LC Meter, 10 MHz Function Generator), Kelvin(Four Wire) and SMD Test Clips, Breadboard Jumper Wires etc. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Ascel Electronic
MPN	AE20401
Model	AE20401
Country/Region of Manufacture	Germany
