Aemc Pel 103 Power And Energy Logger

US $1,745.63

Phoenix, Arizona, United States
Jan 29th

Open on mobile:
QR code

AEMC PEL 103 Power and Energy Logger Features: Characteristics AEMC PEL 103 Power and Energy Logger Measurement of RMS voltages and currents at 128 times per cycle and stored every second Measurement of VA, W and var power values (total and per phase) stored every second Measurement of VAh, Wh and varh energy values (total and per phase) per second with source/load indication Calculation of the cos φ Displacement Power Factor (DPF) and the Power Factor (PF) stored every second Calculation of Total Harmonic Distortion (THD) Measurement, calculation and display of the harmonics up to the 50th order for 50/60 Hz and 7th order for 400Hz Measurement of the DC quantities (RMS calculation) Display Measurements Electrical network quantities are stored on a removable SD-Card Automatic recognition of the connected current sensors DataView software for configuration, data retrieval and real-time viewing of measurements with a PC Compact and rugged case Versatile communication interface choices built in (USB, Ethernet, Bluetooth Specifications AEMC PEL 103 Power and Energy Logger General Sampling Frequency 128 samples per cycle; 50/60Hz (16 samples/cycle 400Hz) Data Storage Rate 1 per second Demand Period Storage Rate User selectable (1,2,3,4,5,6,10,12,15,20,30 and 60 minutes) Recorded Parameters (Single- and Poly-Phase) V, I, W, VA, var, PF, Tan, Wh, Vah, varh, THD (V and I), Individual harmonics (from 1 through 50 per phase); Crest Factor (CF), Cos f / DPF Event Log Tracks and records status changes and error messages along with recorded data Front Panel Indicator LEDs Bluetooth active, recording in progress, phase connection reversal, overload, battery charging and SD Card status Storage Capacity 2GB SD card (included) is used for storage. SD cards (up to 2GB); SDHC cards (4 to 32GB) formatted FAT32 are supported Input - Voltage 3 voltage Input channels via 4mm safety banana jacks Input - Current 3 current Input channels via custom 4 pin jacks that accept AEMC probes and sensor Electrical Voltage Measurement Range Resolution Accuracy (% of Reading)* 50/60Hz 42.5 to 69Hz - ± 0.1Hz Single-Phase RMS Voltages 100 to 1000rms 0.1V ± 0.2% Reading ± 0.2V Phase-to-Phase RMS Voltages 100 to 2000Vrms 0.1 to 1V ± 0.2% Reading ± 0.4V 400Hz 340 to 460Hz - - Single-Phase RMS Voltages 100 to 600Vrms 0.1V ± 1% Reading ± 1V Phase-to-Phase RMS Voltages 200 to 1200Vrms 0.1 to 1V ± 1% Reading ± 1 V DC 100 to 1000V 0.1V ± 1% Reading ± 3V (typical) PT Ratios Programmable from 50V to 65,000V 0.01V to 0.1V - Current Measurement Current Probe: MiniFlex Sensor MA193*** 100mA to 100Arms 20 to 400Arms 100 to 2000Arms 500 to 10,000Arms 1 to 100mA 10 to 100mA 0.1 to 1A 0.1 to 1A ± 1% ± 50mA ± 1% ± 0.2A ± 1% ± 1A ± 1% CT Ratios Programmable from 1:1 to 25,000:1 (probe dependant) Power Measurements Active Power (P)* -2 to 2GW 0.001W ± 0.5% Reading ± 0.005% Pnom Reactive Power (Q)* -2 to 2Gvar 0.001var ± 1% Reading ± 0.01% Qnom Apparent Power (S)* 0 to 2GVA 0.001VA ± 0.5% Reading ± 0.005% Snom Power Factor -1 to +1 0.001 ± 0.05 Tangent Φ (active/reactive power ratio) -3.2 to +3.2 0.001 ± 0.02 Energy Measurements Active Energy (EP) 0 to 4x1018 1Wh ± 0.5% Reading Reactive Energy (EQ) 0 to 4x1018 1varh ± 2% Reading Apparent Energy (ES) 0 to 4x1018 1Vah ± 0.5% Reading THD ± 655% Individual Harmonics 1 to 50 displayed in percentage; 1 to 7 at 400Hz External Supply 11V/250V (10%) @ 50/60Hz; 400Hz Back-Up Power Source / Charge Time Rechargeable 8.4V NIMH battery pack / Approximately 5 hours Battery Life Provides up to 30 minute ride through upon power loss Mechanical Communication Ports USB 2.0, Ethernet (RJ45) Wireless Bluetooth Class 1 ** Dimension / Weight 10.08" x 4.92" x 1.46" (256 x 125 x 37mm) / < 2.2lbs (<1kg) Case / Index of Protection Double Insulated, rubber over-molded, polycarbonate UL94 V1 rated / IP54 non operating Mounting / Security Embedded magnets on back side, keyhole slot on back side / Kensington anti-theft system Display Display Type for Model PEL 103 2.63 x 2.16" (67 x 55mm), four line, monochrome, backlit LCD with adjustable brightness and contrast Environmental / Safety Operating Temperature/ Relative Humidity 32° to 122°F (0° to 50°C) / up to 85% Storage Temperature -4° to 122°F (-20° to 50°C) with batteries; -4°C to 158°F (-20°C to 70°C without batteries) Safety Rating / CE Rating Complies with IEC 61010-1: Ed3, and IEC 61010-2-030:Ed1 for 1000V CAT III / 600V CAT IV, Pollution Degree 2 / Yes * Maximum value is current probe dependant. ** Computers with Class II Bluetooth will restrict range to 40ft. Computers without Bluetooth will require a Class I or Class II Bluetooth radio adapter. *** Maximum current reduced by a factor of 2 for 400Hz fundamental frequency. eBay Sales – Terms and Conditions Product Condition: All listed products are brand new, and come in the original packaging with a complete manufacturer’s warranty. Warranty: All Brand New products are covered by the Manufacturer’s Standard Warranty. The Standard Warranty usually applies to a one-year period, although some products come with a longer warranty. Please consult our Customer Care for more information. Payment Terms: PayPal is the main payment method. We also accept all major credit cards (Visa, MasterCard, American Express and Discover) for orders shipped within US. International customers are encouraged to pay via bank wire transfer. If you have questions regarding payment methods, quotes or any other matter related to sales, please contact our Customer Care department. Value Testers charges 8.3% sales tax for all shipments to Arizona addresses. Shipping: We only ship to addresses verifiable by either PayPal or credit card issuing bank. Please note that we cannot alter the address once a purchase is made. In the case of PayPal payment, we will ship orders when the payment is marked “Eligible” for PayPal Seller’s protection. Orders normally ship within 1 to 2 business days, if placed before noon MST. Tracking numbers are provided automatically. We do inspect products before a shipment is made, and all shipments are insured. In case of international shipments, clients are responsible for any duties, import taxes and brokerage fees. Shipments to Alaska and Hawaii may carry higher rates. Please contact our Customer Care department for the detailed information on shipping to Alaska and Hawaii. Returns: Before returning product, please contact our Customer Care to receive RMA (return material authorization number). Returns without RMA will not be processed. Returns of non-defective items are subject to 15% restocking fee, if returned 14 days past the delivery date. The customer is responsible for the shipping charges of the returned products. All products must be returned in their original and undamaged manufacturer’s packaging with all accessories and product manual. Return may be voided, if product is returned damaged or marked, or if any accessories or parts are missing. Please make sure to insure the return shipment, as UPS only automatically insures shipments up to $100 value. Our Customer Care can answer your questions Monday – Friday, between 7:00AM and 5:00PM MST.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	AEMC
MPN	2137.52
Model	PEL 103
