Afl Noyes Smlp5-5 Sm Mm Fiber Optic Loss Test Set Ols4 Ols-4 Opm5-2c Smlp 5-5

US $1,995.00

Toledo, Ohio, United States
Jan 29th

Open on mobile:
QR code

Content on this page requires a newer version of Adobe Flash Player. The Following Items Are Included: Noyes OPM5-2C Optical Power Meter (BC# 16459) Power Meter: 850nm 1300nm 1310nm 1550nm SC Conenctor For Power Meter Noyes OLS 4 Optical Light Source (BC# 17286) MM Source: 850nm 1300nm SM Source: 1310nm 1550nm (2) SC Connectors For Light Source Noyes 5400-00-0201 Mandrel Noyes 5400-00-0202 Mandrel w/ Instructions Noyes OLS OPM User's Guide (2) SM SC-SC Fiber Cables (2) MM SC-SC Fiber Cables Noyes WinTest V1.24.18 Software (4) Fiber Optic Wipes Carrying Case BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! AFL Noyes SMLP5-5 OPM5 / OLS4 SM MM Fiber Optic Loss Test Set OLS4 Source: - 850nm - 1300nm - 1310nm - 1550nm OPM5 Power Meter: - 850nm - 1300nm - 1310nm - 1550nm Includes Carrying Case & Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Warranty: 90 Day Exchange Warranty Noyes SMLP5-5 Fiber Optic Test Kit Features Handheld, rugged, lightweight Wave ID (auto identification & switching) Dual or single Wave ID, CW, Tone 270 Hz, 330 Hz, 1 kHz, 2 kHz Tone Large LCD with backlight (OPM5-2D) Power measurements in dBm or µW, insertion loss in dB Reference power level storage Up to 500 records per wavelength storage USB port for download of stored records Windows® compatible software to view, print, and archive stored records Low battery indicator Long battery life with 2 x AA alkaline, optional AC adapter Free 50 µm and 62.5 µm mandrels Cost-effective, easy to use N.I.S.T traceable The SMLP5-5 test kit combines the OPM5 optical power meter and OLS4 integrated LED and LASER light source and is ideally suited for testing fiber optic networks with hybrid (single-mode and multimode) cables. The OLS4 features 850/1300 nm LED output from a multimode output port and 1310/1550 nm LASER output from a single-mode output port. Each wavelength may be transmitted individually at CW or with user selectable modulated Tone (SM output). Also, each wavelength may be transmitted with Wave ID. When transmitting with Wave ID, the OLS4 supports transmitting pairs of wavelengths in an alternating pattern. Associated with each operating condition, the designated LED indicator will illuminate to identify the currently enabled operating mode and emitted wavelength(s) along with battery charge status and external power presence. Both output ports are equipped with UCI based removable adapters to allow the output connectors to be inspected and cleaned. The OPM5 features automatic wavelength identification and switching (Wave ID) when used with the OLS4, multiple test Tone detection for fiber identification, and stores optical references for each calibrated wavelength and up to 500 records per wavelength of power or insertion loss measurements. Using the supplied Windows® compatible software and USB connection, test records are transferred to a PC for analysis, printing, and storage. A large dual-wavelength LCD display with backlight shows measured power [dBm or µW] or insertion loss [dB], calibrated wavelengths [nm], tone signal [Hz], wavelength ID, and estimated remaining battery life. The OPM5 optical input port accepts a variety of Noyes thread-on style adapter caps (ordered separately) to meet a wide range of testing requirements. The OPM5 or OLS4 offer long battery life from common AA alkaline batteries with external AC adapter available as an option. The SMLP5-5 test kit is fully N.I.S.T. traceable. OLS4 Light Source specifications Optical MM Optical Port SM Optical Port Wavelength 850 ± 30 nm 1300 -10/+50 nm 1310 ± 20 nm 1550 ± 20 nm Emitter type LED Laser Class I FDA 21 CFR 1040.10 and 1040.11, IEC 60825-1: 2007-03 Spectral width 40 nm (typ) 120 nm (typ) 5 nm (max) 5 nm (max) Output power > - 20 dBm, 62.5 µm multimode* 0 dBm, 9 µm single-mode Output Stability ± 0.1 dB over 8 hours (after 5 min. warm-up) ± 0.05 dB over 1 hour (after 15 min. warm-up) ± 0.1 dB over 8 hours (after 15 min. warm-up) General Power 2 x AA batteries, optional AC adapter Battery life Typical 30 hours, minimum 20 hours Typical 72 hours, minimum 40 hours Available adapters SC FC, ST, LC Operating temperature -10 to 50°C, 90% RH (non-condensing) Storage temperature -30 to 60°C, 90% RH (non-condensing) Size (H x W x D) 14.0 x 8.1 x 3.8 cm (5.5 x 3.2 x 1.5 in) Weight 0.29 kg (0.65 lb) OPM 5 The OPM 5 is used to perform diagnostic and evaluation measurements associated with fiber optic transmission systems and cable plant. Applications for the OPM 5 will be found within the telecommunication, cable television, data network, and industrial control industries. The OPM 5 measures absolute power (in dBm or µW ) and loss (dB). Absolute power expressed in dBm is the amount of optical power received by the detector as compared to 1mW (0dBm=1mW). Measuring dBm is useful for verifying the output power of a transmitter and determining system losses. Loss is the difference in optical power from a known input (the reference level) and the output power at the opposite end of the fiber under test. The OPM 5 can display dB loss directly after a reference level has been set. Loss measurements are used to qualify cable plant links and fiber optic jumpers. Microwatts is also a way to measure absolute power. Some manufacturers specify their transmission equipment in watts instead of dBm. The OPM 5 offers the ability to measure watts for convenience when verifying output power of transmitters. For accurate results, always be sure to set the OPM 5 to measure the same wavelength as the output of the optical light source. Specifications: Calibration Wavelength (nm) 850 1300, 1310, 1550 Tone Detection Range (dBm) +6 to - 30 +6 to - 35 Tone Detection Frequency (Hz) 270 ± 13.5 1000 ± 50 2000 ± 300 Detector Type Germanium (Ge) Display Range (dBm) +6 to -60 dBm Accuracy (@ 25°C & -10.0dBm) ±0.25 dB Resolution 0.01 dB (.1 dB selectable) Battery Life >30 hrs. typical operation with 9V Alkaline Adapter Caps Order Separately Size (H x W x H) 5.5 x 3.2 x 1.5 in (14.0 x 8.1 x 3.8 cm) Weight 0.56 lb (0.26 kg) Operating Temp. 0° to 50° C Storage Temp. -30° to 60° C Relative Humidity 0 to 95% (non-condensing) Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! Contact: Test Equipment Store eBay Sales Phone: 1-419-517-6681 Toll Free : 1-800-548-2381 We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. UPS Ground United States USD 0.00 USPS Express Mail International (EMS) Worldwide USD 0.00 We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Put your auctions on autopilot with Kyozou eBay Auction Tools

Condition:	Seller refurbished: An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details. ...	Model	SMLP5-5
Manufacturer	AFL Noyes
