Agilent Hewlett Packard 3325a W/ Option 01 Synthesizer Function Generator

US $650.00

San Jose, California, United States
Jan 29th

Open on mobile:
QR code

Hewlett Packard / Agilent 3325A Synthesizer Function Generator Manufacturer: HP / Agilent Model: 3325A / 01 Unit comes with items shown in pictures. Accessories: None The HP 3325A Synthesizer Function Generator generates signals with minimum frequency of 1µHz and the following maximum frequencies: Sine Wave 20 MHz Square Wave 10 MHz Triangle 10 kHz Positive slope ramp 10 kHz Negative slope ramp 10 kHz The frequency can be selected from 11 digits. Output amplitude can be adjusted from 1mV to 10V peak peak and can be selected and displayed either in V rms or dBm (50 ohms). Possible also an DC offset of +/-4.5 V. The high output voltage option 002 (like the shown device) can supply a 40 Vpp in to >=500 ohms load. Also very usefull the option 001 a High Stability Frequency Reference a quartz inside a temperature controlled oven. Of course the instrument has an HP-bus interface and analogue and digital outputs for many applications. The HP3325A instrument is a nice general purpose generator leaving not many wishes open, ideally for electronic development. Testing slew rate of an audio amplifier by using the clean steep sqaure wave signal. The high voltage option is very usefull to test power amplifier without the need of a preamplifier. No circiut designer want's to miss the instrument - really. HP 3325A simplified specification (taken from a 1984 manual): Frequency Resolution: 1µHz for frequencies below 100 kHz and 1mHz for frequencies 100 kHz and higher Frequency Accuracy standard instrument: +/-5 * 10 exp -6 of selected value (20°C to 30°C) Frequency Stability standard instrument: +/-5 * 10 exp -6 per year (20°C to 30°C) Signal Characteristics: Sine Wave and harmonics: 0.1 Hz to 50 kHZ: no harmonic greater than -65dB 50 kHz to 200 kHz: -60dB 200 kHz to 2 MHz: -40dB 2 MHz to 15 MHz: -30dB 15 MHz to 20 MHz: -25dB Square Wave: Rise and Fall TIme: <= 20 nanoseconds, 10% to 90% at full output Triangle: Linearity, 10% to 90%, best fit straight line: +/-0.05% of full p-p output for each range Ramps (positive or negative): Linearity, 10% to 90%, best fit straight line: +/-0.05% of full p-p output for each range Amplitude Accuracy [no Attenuator (in Range 1) in 50 ohms and no DC offset]: Sine Wave 0.001 Hz to 100 kHz accuracy relative to programmed amplitude +/-0.1dB Square Wave 0.001 Hz to 100 kHz accuracy relative to programmed amplitude +/-1.0% Triangle 0.001 Hz to 2 kHz accuracy relative to programmed amplitude +/-1.5% (+/-5% for 2 kHz to 10 kHz) Ramps 0.001 Hz to 500 Hz accuracy relative to programmed amplitude +/-1.5% (+/-10% for 500 Hz to 10 kHz) Amplitude Flatness [no Attenuator (in Range 1) in 50 ohms and no DC offset]: Sine Wave 100 kHz to 20 MHz accuracy relative to programmed amplitude at 1 kHz +/-0.3dB Square Wave 100 kHz to 20 MHz accuracy relative to programmed amplitude at 1 kHz +/-10% Amplitude Modulation: Sine Wave only, Modulation Envelope Distortion: -30 dB to 80% modulation at 1 kHz, 0V DC offset Phase Offset: Range: +/-719.9° with respect to arbitrary starting phase. or assigned zero phase. Resolution: 0.1° Stability: +/-1° phase/°C Phase Modulation: Linearity (Sine Function): +/-0.5%, best fit straight line Synch Out (into 50 ohms): X-Drive Output: Amplitude 0 to dc 10V linear ramp proportional to sweep frequency (sweep up only) Option 001 High Stability Frequency Reference: Ambient Stability: +/-5 * 10exp-8 (0° to 55°C referenced to +30°C) Aging Rate: +/-5 * 10exp-8 per week (after 72 hours continuous operation) Aging Rate: +/-1 * 10exp-7 per month (after 15 days continuous operation) Terms and conditions: Buyer is responsible for all applicable CA sales tax, shipping (includes returns), and handling costs. Paypal is the preferred method of payment. Other forms of payment may require additional time to clear or additional fees (for wire transfers.) Shipping: Shipment by UPS, FedEx, or USPS ground. Extra shipping charges for expedited services. International shipment cost is an estimate. Please contact us for actual international shipping cost. Insurance cost will be added to all shipments. Return Policy: 7 Day return period (from date of receipt) applies if product does not power on (if applicable or unless otherwise stated in listing) or if product is not as described in eBay listing. Returned unit must be received by Spectra Test Equipment in the same condition as that was received by the buyer (including intact waranty stickers, if shown in listing. Customer is responsible for return shipping + insurance fees and proper packaging of unit. . View our other auctions | Add me to your favorite sellers | View our eBay Store About us | Email me with any questions © 2003-2007 Spectra Test Equipment, Inc. All rights reserved. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Manufacturer	HP / Agilent
Model	3325A
