AGILENT 86142B SPECTRUM ANALYZER ******CALL (760) 806-6600 TO RENT THIS ITEM****** DESCRIPTION The Agilent 86142B Optical Spectrum Analyzer (OSA) is best suited for WDM component and system test applications where power and wavelength accuracy, dynamic range and low polarization dependency are key. The high performance capability of the Agilent 86142B OSA combined with the advanced feature set and on board measurement applications enables you to make highly accurate measurements quickly and easily. These advanced features have been tailored towards increasing your product yields, maximizing manufacturing capacity and minimizing costs. The on-board measurement applications have been designed for ease of use requiring minimal training while retaining flexibility to customize measurements for individual needs. Features and specifications of the Agilent 86142B Optical Spectrum Analyzer include: Wavelength: 600 nm to 1700 nm Reproducibility: ±0.002 nm (With applied input fiber 9/125 µm; = 1min) Span Range: 0.2 nm to full range and zero span Accuracy After calibration with internal source and with enhanced wavelength calibration for specified range: 1480-1570 nm: Typ ±0.01 nm (At room temp; with applied input fiber 9/125 µm) 1570-1620 nm: Typ ±0.025 nm (At room temp; with applied input fiber 9/125 µm) After calibration with external reference source(s) ±10 nm of calibration reference point(s): Typ ±0.01 nm (At room temp, with applied input fiber 9/125 µm) After user calibration over full wavelength range (600-1700 nm): ±0.2 nm (T(20-30°C), with applied input fiber 9/125 µm)) Absolute Accuracy: ±0.5 nm (Factory cal. 2 yr. cycle; T(20-30°C); with applied input fiber 9/125 µm) Tuning Repeatability: ±0.002 nm (With applied input fiber 9/125 µm; = 1min) Resolution Bandwidth (RBW) FWHM (3 dB Bandwidth): 0.06, 0.1, 0.2, 0.5, 1, 2, 5, 10 nm Noise Marker Bandwidth Accuracy using noise markers 1525-1610 nm =0.5 nm: ±2% 0.2 nm: ±3% 0.1 nm: ±7% 0.06 nm: ±12% Amplitude: Sensitivity: 600-750 nm: -60dBm (T(0-30°C), 2nd order) 750-900 nm: -75dBm (T(0-30°C), 2nd order) 900-1250 nm: -75 dBm (T(0-30°C) 1250-1610 nm: -90 dBm (T(0-30°C) 1610-1700 nm: -80 dBm (T(20-30°C) Maximum Measurement Power: 1525-1700 nm: Typ +15 dBm per channel, +30 dBm total 600-1000 nm: Typ +15 dBm per channel, +30 dBm total 1000-1525 nm: Typ +12 dBm per channel, +30 dBm total Maximum Safe Power: Total Safe Power: +30 dBm Total power within any 10 nm portion of the spectrum: +23 dBm Absolute Accuracy: at –20dBm, 1310 nm/1550 nm: ± 0.5 dB (For resolution = 0.1 nm, with applied input fiber 9/125 µm) Scale Fidelity: Autorange off: ± 0.05 dB: T(20-30°C), with applied input fiber 9/125 µm Autorange on: ± 0.07 dB: T(20-30°C), with applied input fiber 9/125 µm Display Scale (log scale): 0.01-20 dB/DIV, -120 to +90 dBm Amplitude Stability (1310 nm, 1550 nm), 1 minute: ±0.01 dB (For signals within 8 dB of top of screen, with applied input fiber 9/125 µm) 15 minutes: ±0.02 dB (Typ., with applied input fiber 9/125 µm) Flatness: 1525-1610 nm: ±0.2 dB 1250-1610 nm: ±0.7 dB Polarization Dependence: 1310 nm: ±0.25 dB 1530 nm, 1565 nm: ±0.2 dB 1600 nm: ±0.25 dB 1250-1650 nm: ±0.3 dB Dynamic Range (In 0.1 nm Resolution Bandwidth): 1250-1610 nm (chop mode on) ±0.5 nm, ± 1nm, ±5 nm: Typ -70 dB 1550 nm at ±0.8 nm (±100 GHz at 1550 nm): -60 dB at ±0.5 nm (±62.5 GHz at 1550 nm): -58 dB at ±0.4 nm (±50 GHz at 1550 nm): -55 dB at ±0.2 nm (±25 GHz at 1550 nm): Typ -40 dB Monochormator Input Input Return Loss: Straight Connector (9/125 µm): > 35 dB Sweep: Max. Sweep Rate: Typ 40 nm/56.3 ms Max. Sampling Rate in Zero Span: Typ 50 µs/trace point Sweep Cycle Time: 50 nm span, auto zero off: Typ < 180 ms 50 nm span, auto zero on: Typ < 340 ms 100 nm span: Typ < 400 ms 500 nm span: Typ < 650 ms ADC Trigger Accuracy: Jitter (distributed uniformly): Typ < ± 0.5 µs Trigger delay range: Typ 2 µs-6.5 ms Pulse Mode Accuracy: Turn On (=2 µs after rising edge): Typ <±0.2 dB Turn Off (=10 µs after falling edge): <±0.2 dB (30 dB extinction) Computer Interfacing Remote Control: Web enabled controls Compatibility: IEEE-488.1, IEEE-488-2 (100%) Interfaces: LAN, GPIB, Parallel Printer Port, External VGA Monitor, Keyboard and Mouse (PS/2) Floppy Disk Instrument Drivers: Universal Instrument Drivers (PNP), Compatible with VEE, Labview, Visual Basic and C++ Configuration Notes / Options: 006 - Internal wavelength calibrator *All of our equipment has been tested. Additional calibration may be available upon request! ~This sale includes all items shown. No unseen parts or accessories will be included~ PAYMENT AND SHIPPING INFO Warranty Info & Return Policy We strive to exceed our customer's expectations and maintain 100% Positive Feedback. Although we do not use eBay's automated Return Policy, all goods or equipment sold by AxiomTest include a 30-Day Warranty which starts the day the equipment is shipped. So contact us immediately if there is a discrepancy with your order or an equipment malfunction so we can issue a repair, replacement, or refund. Returns must be shipped with all original packaging and accessories. We will not accept any items with obvious signs of additional wear and tear or internal component alterations. All of our items will ship with “Warranty Void” tamper resistant stickers. If any stickers have been removed or tampered with your refund will be canceled. Please include your RMA # on the packing slip, way bill, or package. *CUSTOMER RESPONSIBLE FOR ANY AND ALL RETURN SHIPPING COSTS Payment Options Domestic Buyers - PayPal, Wire Transfer, Money Order, Company, Bank, or Personal Check. International Buyers: PayPal or Wire transfer only. All funds must be in US Dollars. Unsecured funds must clear prior to shipment. Wire Transfers subject to a $25 service fee. Shipping Unless noted otherwise, all shipments are done through FedEx. If you would like to utilize your own shipping account please notify us PRIOR to checkout. Saturday and Residential delivery may be available at an additional third party charge depending on the shipping method you choose. We offer shipping outside of the United States. However, some international laws prohibit us from shipping certain items to certain countries. Additionally, not all countries are supported by our service provider. You may also elect to use your own carrier, but we'll be responsible for providing the correct documentation and scheduling the pickup. We are not set up to ship via USPS, and we will NOT falsify any import documents for international orders - no exceptions. Please note: In all sales where an item is prohibited to ship internationally to a successful buyer, that buyer will be notified of non-shipment and a full refund will be made. We reserve the right not to ship any item internationally that is controlled by the US Department of Commerce’s laws and regulations and deemed non-shippable to that region of the world or to listed individuals. eBay's International Shipping calculations do not include any additional duties, fees, or VAT that may be associated with importing this item into a foreign country - please bid accordingly Sales Tax California residents will be charged sales tax if no resale or tax exempt form is submitted prior to payment. TRIED, TESTED...ACCEPTED.
