Altera De2-115 Development & Education Board W/ Complete Design Suite V 14 Dvd

US $525.00

Rialto, California, United States
Feb 27th

Open on mobile:
QR code

Condition: The kit was opened to take picture List Price: $595 1. Description The DE2 series has consistently been at the forefront of educational development boards by distinguishing itself with an abundance of interfaces to accommodate various application needs. Extending its leadership and success, Terasic announces the latest DE2-115 that features the Cyclone IV E device. Responding to increased versatile low-cost spectrum needs driven by the demand for mobile video, voice, data access, and the hunger for high-quality images, the new DE2-115 offers an optimal balance of low cost, low power and a rich supply of logic, memory and DSP capabilities. The Cyclone EP4CE115 device equipped on the DE2-115 features 114,480 logic elements (LEs), the largest offered in the Cyclone IV E series, up to 3.9-Mbits of RAM, and 266 multipliers. In addition, it delivers an unprecedented combination of low cost and functionality, and lower power compared to previous generation Cyclone devices. The DE2-115 adopts similar features from the earlier DE2 series primarily the DE2-70, as well as additional interfaces to support mainstream protocols including Gigabit Ethernet (GbE). A High-Speed Mezzanine Card (HSMC) connector is provided to support additional functionality and connectivity via HSMC daughter cards and cables. For large-scale ASIC prototype development, a connection can be made with two or more FPGA-based boards by means of a HSMC cable through the HSMC connector. 2. Specification The DE2-115 Board Cyclone® IV EP4CE115 114,480 logic elements (LEs) 3,888 Embedded memory (Kbits) 266 Embedded 18 x 18 multipliers 4 General-purpose PLLs 528 User I/Os Configuration Device and USB-Blaster Circuit EPCS64 serial configuration device On-board USB-Blaster circuitry JTAG and AS mode configuration supported Memory Devices 128MB (32Mx32bit) SDRAM 2MB (1Mx16) SRAM 8MB (4Mx16) Flash with 8-bit mode 32Kbit EEPROM Switches and Indicators 18 switches and 4 push-buttons 18 red and 9 green LEDs Eight 7-segment displays Audio 24-bit encoder/decoder(CODEC) line-in, line-out, and microphone-in jacks Display 16x2 LCD module On-Board Clocking Circuitry Three 50MHz oscillator clock inputs SMA connectors (external clock input/output) SD Card Socket Provides SPI and 4-bit SD mode for SD Card access Two Gigabit Ethernet Ports Integrated 10/100/1000 Gigabit Ethernet Supports Industrial Ethernet IP cores 172-pin High Speed Mezzanine Card (HSMC) Configurable I/O standards (voltage levels: 3.3/2.5/1.8/1.5V) USB Type A and B Provide host and device controller compliant with USB 2.0 Support data transfer at full-speed and low-speed PC driver available 40-pin Expansion Port Configurable I/O standards (voltage levels: 3.3/2.5/1.8/1.5V) VGA-out Connector VGA DAC (high speed triple DACs) DB-9 Serial Connector RS232 port with flow control PS/2 Connector PS/2 connector for connecting a PS2 mouse or keyboard to the DE2-115 Remote Control Infrared receiver module TV-in Connector TV decoder (NTSC/PAL/SECAM) Power Desktop DC input Switching and step-down regulators LM3150MH Connectivity Connect D5M Connect D5M with DE2-115 Connect LTM Connect LTM with DE2-115 Connect DVI-HSMC Connect DVI-HSMC with DE2-115 Connect ADA-HSMC Connect ADA-HSMC with DE2-115 Connect DCC-HSMC Connect DCC-HSMC with DE2-115 Connect HTG (M) Connect HTG(M) with DE2-115 Connect COMM Connect COMM with DE2-115 3. Layout Size:210.8*156 mm 4. Kit Contents The DE2-115 package includes: Note: 1. Complete Design Suite Version 10.0 DVD is provided by manufacturer 2. DE2-115 System CD includes Tools Tutorials Lab Exercises and User Manual 5. Bonus Items(Seller Provided) Optional Complete Design Suite Version 14 DVD (Specify when purchase your choice of version 10.0 or 14.0) FPGA/CPLD Tutorials Digital Design Overview 6. Applications Pac-Man is not a dream, someone actually tried Pac-Man Using Xilinx Spartan-3E Starter Kit Here is the video. “Pac-Man” by Xilinx Spartan-3E Starter Kit And Altera is not far behind Xilinx in developing Pac-Man applications...Watch “Pac-Man” by Altera DE2 Development and Education board Other people tried Super Mario Bros, too. “Super Mario Bros” by Altera DE2 Development and Education board The moral of the story: If someone else can do it on YouTube, so can you in the privacy of your home! Let's have fun!!!

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	Altera
MPN	P0059
Model	DE2-115
Country/Region of Manufacture	Taiwan
