Ampire Am480234g1tmqwtb0 7.0” Tft-lcd Panel And Lcd Controller

US $30.00

Rialto, California, United States
Jan 29th

Open on mobile:
QR code

USED AMPIRE AM480234G1TMQWTB0 7.0” TFT-LCD panel, LCD controller, power driver circuit and backlight unit module. Units Salvaged from new unused wireless cash registers by School-Link Technologies Type-Mira. Double-sided tape adhesive residue on each side from mounting brackets. Units Original screen protector still in place. Unit is New, in excellent physical condition, Unable to test No guarantee on full or partial functionality. 7.0 inch Amorphous-TFT-LCD (Thin Film Transistor Liquid Crystal Display) module. This module is composed of a 7.0” TFT-LCD panel, LCD controller, power driver circuit and backlight unit. Features 1.1 TFT Panel Feature : Construction: 7.0” a-Si color TFT-LCD, White LED Backlight,Touch Panel and PCB. Resolution (pixel): 480(R.G.B) X234 Number of the Colors: 65K and 262K colors selectable. LCD type : Transmissive Color TFT LCD (normally White) Interface: 40 pin pitch 0.5 FFC Power Supply Voltage: 5.0V single power input. Built-in power supply circuit. Viewing Direction: 6 O’clock ( The direction it’s hard to be discolored ): 1.2 LCD Controller Feature: MCU interface 8/9/16/18 bit 80&68 series MCU interface selectable by hardware (Jumper). Display RAM size: 640x240x3x6 bits. Ex: 320x240 two frame buffer with 262K colors. Arbitrary display memory start position selection. MCU interface: 8 bit 80 MPU interface. 8 bit / 16 bit interface support 65K (R5G6B5) /262K (R6G6B6) colors 9 bit / 18 bit interface support 262K (R6G6B6) colors data format only. Physical specifications Item Specifications Unit Display resolution(dot) 1440 (W) x 234(H) dot Active area 154.08 (W) x 86.58 (H) mm Screen size 7.0(Diagonal) mm Dot pitch 0.107 (W) x 0.370 (H) mm Color configuration R.G.B stripe Overall dimension 164.9(W) x100.0(H)x9.23(D) mm Backlight unit LED Click Here. Double your traffic. Get Vendio Gallery - Now FREE! FREE! Sellers: Add a FREE map to your listings. FREE!

Condition

For parts or not working :

An item that does not function as intended and is not fully operational. This includes items that are defective in ways that render them difficult to use, items that require service or repair, or items missing essential components. See the seller’s listing for full details.

Seller Notes

“USED AMPIRE AM480234G1TMQWTB0 7.0” TFT-LCD panel, LCD controller, power driver circuit and backlight unit module. Units Salvaged from new unused wireless cash registers by School-Link Technologies Type-Mira. Double-sided tape adhesive residue on each side from mounting brackets. Units Original screen protector still in place. Unit is New, in excellent physical condition, Unable to test No guarantee on full or partial functionality.”
