Ando AQ6317B Optical Spectrum Analyzer - Yellow Bezel Faceplate - CALIBRATED *Buy it Now only* The Ando AQ6317B Optical Spectrum Analyzer has been the benchmark for Optical Spectrum Analysis for many years. The Ando AQ6317B covers a wide range of applications, including light source evaluation, measurement of loss wavelength characteristics in optical devices, and waveform analysis of WDM (Wavelength Division Multiplexing) systems. The Ando AQ6317B is well suited for C-band and L-band measurements. The Ando AQ6317B achieves high wavelength accuracy and wavelength linearity, and can evaluate optical devices for WDM. Built in analysis functions make operation and expandability simple. The Ando AQ6317B is the predecessor of the AQ6370 series which offers a faster processor but which is built on a very similar Mono-Chromator so the AQ6317B offers great optical spectrum analysis capabilities at a much lower price. In comparison with the former Ando AQ6317 model, the wavelength accuracy of the AQ6317B has been improved to ±20 pm mostly through modifications of the Mono-Chromator which is now cast instead of plate assembly. It also offers specifications for the L-band. WDM analysis function and notch width analysis function were also improved, and multi-channel NF analysis function and optical filter analysis function were also added. It has become much easier to use with other improvements, such as sweep speed-up. This is a working, fully functional unit, has sign of use and yellow front faceplate, Possibility of missing feets and bumpers. Specifications for the AQ6317B: Wavelength Range: 600 to 1750 nm Dynamic Range: 60 dB (1523nm, peak ±0.2nm, resolution: 0.01nm) Wavelength Accuracy: 0.5 nm (600 to 1750nm) Wavelength Linearity: +/- 0.01nm (1520 to 1580nm) Wavelength Repeatability: +/- 0.005 nm (1 min) Polarization Dependency: +/- 0.05 dB (1550/1600nm), ±0.05 dB typ. (1310nm) Additional Information Wavelength Resolution: Resolution setting: 0.01, 0.02, 0.05, 0.1, 0.2, 0.5, 1.0, 2.0nm Resolution Accuracy: ± 5 % Level Accuracy: ± 0.3 dB Level Linearity: ± 0.05 dB Sweep Time: Approx. 500 ms Contact us about the specifications to be calibrated by AssetRelay. The AssetRelay difference? Our Laboratory! UPGRADE TESTING SERVICES AVAILABLE for this AQ6317B: Included Basic Calibration : This calibration is performed to ensure the functionality of the equipment and to verify that the "key features" meet the manufacturer's published specifications, wherever possible, at the points tested. The "key features" are the most important parameters of the equipment (i.e. for an attenuator the "key feature" is the attenuation accuracy). This calibration will assure confidence in the equipment; it comes with calibration label and a certificate of calibration. Optional ($) Premium Calibration: This calibration is performed using manufacturer's performance tests procedure, where available. It is designed to assure that the equipment meets or exceeds manufacturer's published specifications. Since we have extended knowledge and experience within the fiber optics field, in many instances our procedures surpass the manufacturer's calibration procedures (i.e. given that we have a lot of repair experience with these types of equipment, we perform additional tests that are not verified by the manufacturer's procedures and that we consider as very important.). Instrumentation used during this calibration is traceable to N.I.S.T. (National Institute of Standards and Technology) or C.N.R.C. (Canadian National Research Council). The equipment would be shipped with a calibration label, a certificate of premium calibration and calibration data. We only ship working units in perfect condition. This AQ6317B will be packaged using our 'box in a box' systems: To make sure that a product sold to you will arrive safely at your place in top shape,one must have among other things, a good knowledge in packaging and shipping methods. Most telecom test equipment is highly precise and sensitive and some of them simply do not travel well. What good will it do you if your unit is destroyed in transport? Over the years, we have developed a great deal of expertise in shipping orders locally and internationally. We have learned, sometimes the hard way, that Optical Test Equipment requires extra packaging care. In some cases, we will only offer specific models for sale on the local market knowing that the item would not be received in perfect working order if it has to make too many hops along the way.That is why, we standardized the following precautions: All orders are granted the same quality packaging regardless of size, value or quantity to be sent out. To prevent water and dust damage, equipment is encased in a large transparent bag. Box edges are taped Double wall corrugated shipping box for measurement equipment and always strapped. We always write clearly on the box the customers’ address as well as sales order number so that it is easy for you to identify in case the shipping documentation is lost in transit or on arrival. All orders are shipped in double wall boxes with a minimum thickness of 2 inches of shock absorbing material around the contents. We package medium and large orders with the ‘Instapak’ Foam Packaging system. Although costly, this method helps us ensure that the equipment arrives at your establishment safe thus minimizing returns and frustration. Some equipment is shipped in a custom made ‘Box in a box’ system. We use this method primarily when shipping heavy equipment such as OSAs. Large and heavy items have a tendency to crush the packaging foam. This phenomenon can result in damaged boxes, particularly on the corners if the box gets dropped. Our heavy duty boxes are also equipped with handles for proper and easy handling by the transporters and also the receiver. Seller's Payment Instructions All orders are prepaid. Wire transfer is our preferred method of payment. Add $ 20.00 USD for wire transfer fees. Instructions included with our quotes and invoices. For this item, no credit card accepted Payment must be received in full prior to being shipped out unless otherwise noted. International shipment buyers assume all responsibilities for customs, duties & taxes as additional fees which ARE NOT included and/or associated within the sales price. Shipping Details Buyer to pay all shipping costs. International shipping will be via Fed Ex, Shipping on your carrier account, contact us before bidding for quote on shipping. You need to email us to get a quote on shipping and handling Contact us Asset Relay's logistics team will also assist you with any documentation required to have your order cleared through customs. Over the years, we've learned that specific documents are required for each country so orders can clear customs swiftly. Our logistics employees will help make the import and export of products as easy as possible for you. Sending the right documents with precise information along with your order will guarantee that you receive the goods promptly and help prevent any additional costs or delays. Warranty Policy 30 DAYS WARRANTY* Right of Return shall become null and void should it be determined that the equipment was subjected to undue abuse, involved in any type of mishap, incorrectly wired and/or used/maintained in a manner contrary to the manufacturer's published instructions All products must be returned prepaid to our lab in accordance with the return instructions. Questions? We are here to answers them! Please call us if you need more information on equipment. We will do our best to answer any question you may have. If we can't answer you straight away over the phone we will take down your e-mail address so we can make the proper research on the unit(s) and get back to you as soon as we can. We can provide you with additional pictures, we can make physical checks on the unit since it is on site in our warehouse, and we can even send you a spec sheet if we have it on file! Contact us if you have any questions!
