Andrew Commscope L4pnm-rc Ringflare N Type Male Connector Ldf4-50a

US $13.00

Atlanta, Georgia, United States
Jun 9th

Open on mobile:
QR code

New L4PNM-RC connector n type male connector for use with LDF4-50A cable. General Specifications Interface N Male Body Style Straight Brand HELIAX® | RingFlare™ Mounting Angle Straight Electrical Specifications Connector Impedance 50 ohm Operating Frequency Band 0 – 8800 MHz Cable Impedance 50 ohm 3rd Order IMD, typical -120 dBm @ 910 MHz 3rd Order IMD Test Method Two +43 dBm carriers RF Operating Voltage, maximum (vrms) 707.00 V dc Test Voltage 2000 V Outer Contact Resistance, maximum 0.30 mOhm Inner Contact Resistance, maximum 2.00 mOhm Insulation Resistance, minimum 5000 MOhm Average Power 0.6 kW @ 900 MHz Peak Power, maximum 10.00 kW Insertion Loss, typical 0.05 dB Shielding Effectiveness -130 dB Mechanical Specifications Outer Contact Attachment Method Ring-flare Inner Contact Attachment Method Captivated Outer Contact Plating Trimetal Inner Contact Plating Gold Attachment Durability 25 cycles Interface Durability 500 cycles Interface Durability Method IEC 61169-16:9.5 Connector Retention Tensile Force 890 N | 200 lbf Connector Retention Torque 5.42 N-m | 48.00 in lb Insertion Force 66.72 N | 15.00 lbf Insertion Force Method MIL-C-39012C-3.12, 4.6.9 Pressurizable No Coupling Nut Proof Torque 19.91 N-m | 176.25 in lb Coupling Nut Retention Force 444.82 N | 100.00 lbf Coupling Nut Retention Force Method MIL-C-39012C-3.25, 4.6.22 Dimensions Nominal Size 1/2 in Diameter 22.00 mm | 0.87 in Length 76.00 mm | 2.99 in Weight 242.00 g | 0.53 lb Environmental Specifications Operating Temperature -55 °C to +150 °C (-67 °F to +302 °F) Storage Temperature -55 °C to +85 °C (-67 °F to +185 °F) Immersion Depth 1 m Immersion Test Mating Mated Immersion Test Method IEC 60529:2001, IP68 Water Jetting Test Mating Mated Water Jetting Test Method IEC 60529:2001, IP66 Moisture Resistance Test Method MIL-STD-202F, Method 106F Mechanical Shock Test Method MIL-STD-202, Method 213, Test Condition I Thermal Shock Test Method MIL-STD-202F, Method 107G, Test Condition A-1, Low Temperature -55 °C Vibration Test Method MIL-STD-202F, Method 204D, Test Condition B Corrosion Test Method MIL-STD-1344A, Method 1001.1, Test Condition A Standard Conditions Attenuation, Ambient Temperature 20 °C | 68 °F Average Power, Ambient Temperature 40 °C | 104 °F Return Loss/VSWRFrequency Band VSWR Return Loss (dB) 0–1000 MHz 1.03 36.00 1000–2000 MHz 1.07 29.00

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	Andrew
MPN	L4PNM-RC
Model	L4PNM-RC
