Anritsu S331d Sitemaster Cable & Antenna Analyzer Opt3 Color Screen 7/16 Din Kit

US $2,395.00

Toledo, Ohio, United States
Aug 31st

Open on mobile:
QR code

The Following Items Are Included: Anritsu SiteMaster S331D Cable & Antenna Analyzer Option 3: Color 7 Piece 7/16 DIN Adapter Kit: 7/16 DIN Male To 7/16 DIN Male Adapter 7/16 DIN Female To 7/16 DIN Female Adapter 7/16 Male To N Male Adapter 7/16 DIN Male To N Female Adapter 7/16 DIN Female To N Male Adapter 7/16 DIN Female To N Female Adapter 7/16 DIN Male To 7/17 DIN Female Adapter Eagle CKT-050A OSL Calibration Kit Armored Test Port Cable Tripp-Lite USB To Serial Adapter Cable AC Adapter/Charger Power Cord RS232 PC Interface Cable DC Car Charger User Manual On CD-ROM Carrying Case (G) BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! Anritsu SiteMaster S331D Cable & Antenna Analyzer ( Handheld ) 25MHz - 4000Mhz Installed Options: Option 3: Color Includes 7 Piece 7/16 DIN Adapter Kit, Eagle CKT-050A Open/Short/Load, Carrying Case & Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 1 YEAR WARRANTY Site Master™ Handheld Cable and Antenna Analyzer Model S331D covering the 25 MHz to 4000 MHz spectrum is the de facto industry standard for installing, provisioning, maintaining, and troubleshooting wireless base station cable and antenna systems. Option 2 and Option 16 extend the lower and upper frequency ranges to 2 MHz and 6 GHz respectively. Accurate, versatile, affordable, rugged and a true handheld at under 5 pounds (including battery), Site Master is ideally suited for field technicians of any experience level working with VHF, broadcasting, paging, cellular, PCS/GSM, 3G, ISM, WLAN and WLL applications. S331D measurement capability includes precision Return Loss/SWR, Cable Loss and optional T1/E1 and power meter measurements. Frequency Domain Reflectometry (FDR) provides superior Distance to Fault (DTF) analysis to locate faults accurately. Patented RF interference rejection enables accurate, repeatable measurements in the presence of high RF activity. Data analysis software enables assessment of system trends, problems, and performance in addition to professional report generation. <3.5 msec Sweep Speed Per Data Point saves the technician time and enables easier identification of intermittent problems in real time. FlexCal broadband calibration 25 MHz to 4 GHz allows troubleshooting cable and antenna systems without multiple calibrations and calibration setups. Built-In Worldwide Signal Standards eliminates the need to remember system frequencies and manually input the start and stop frequency values. Built-In Average Cable Loss eliminates the need to calculate a measured cable loss value. Built-In Power Meter Option measures the base station transmitter power accurately. The High Accuracy Power Meter (option 19) provides true RMS measurements from 50 MHz to 6 GHz. The S331D model Site Master Handheld Cable and Antenna analyzer includes data analysis software, soft carrying case, rechargeable/field-replaceable battery, AC/DC power supply, 12V automobile cigarette lighter adapter and users guide. Features Handheld, battery-operated design Weighs less than 5 lbs. (including battery) Built-in worldwide signal standards and frequency channels TFT daylight viewable display Superior Immunity to RF interference Locate long range problems with 517 data points Variety of Power Measurement solutions Built-in and editable Signal Standard and Cable Standard lists Multilingual User Interface; English, French, Chinese, Japanese, Spanish, German Intuitive and easy to use with On-Screen Test Set-Ups Saves 10 to 30 Measurement Test Set-Ups (10 VNA, 5 T1, 5 E1, Power Meter, 5 High Accuracy Power Meter) Saves up to 300 Measurement Traces Alphanumeric Labeling of Saved Measurements Automatic Time and Date Stamp of Saved Data Rechargeable, Field Replaceable Battery Distance Measurement in Feet and Meters Information Screens Provide Cable Attenuation and Velocity of Propagation values 6 Markers, Limit Lines, and Segmented Limit Lines RS232 Interface Applications Cable and antenna testing for VHF, broadcasting, paging, cellular, PCS/GSM, 3G, ISM, WLAN and WLL applications Return Loss measurement Distance-To-Fault measurement Cable loss measurement Channel power Specifications Frequency Range: 25 MHz to 4.0 GHz Frequency Accuracy: ±50 ppm @ +25 °C Frequency Resolution: 1 kHz (CW On) 100 kHz (CW Off) Output Power: 0 dBm typical Immunity to Interfering Signals: On-channel: +17 dBm On-frequency: –5 dBm Measurement Speed: 2.5 msec / data point (CW ON) Number of Data Points: 130, 259, 517 Return Loss: Range: 0.00 to 60.00 dB Resolution: 0.01 dB VSWR: Range: 1.00 to 65.00 Resolutio: 0.01 Cable Loss: Range: 0.00 to 30.00 dB Resolution: 0.01 dB Measurement Accuracy: > 42 dB corrected directivity after calibration Distance-to-Fault: Vertical Range: Return Loss: 0.00 to 60.00 dB VSWR 1.00 to 65.00 Horizontal Range: 0 to (# of data pts –1) x Resolution to a maximum of 1497m (4912 ft), # of data pts = 130, 259 or 517 Horizontal Re solution (Rectangular Windowing): Resolution (meter) = (1.5 x 10 8) x (Vp)/DF Where Vp is the cable's relative propagation velocity and where DF is the stop frequency minus the start Anritsu 7/16 DIN Adapter Kit Set Impedance 50 Body Silver / Nickel Plated Brass Contact Silver Plated Brass Insulator PTFE Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Sell Smarter with Kyozou. Inventory and Ecommerce Management

Condition:	Seller refurbished: The item has been restored to working order by the eBay seller or a third party. This means the item was inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See seller’s listing for full details. ...	Brand	Anritsu
Model	S331D
MPN	S331D
