Apm Power Module With Xt60 Connectors Ardupilot Apm 2.5.2 Trackingno

US $19.99

ShangHai, China
Jan 29th

Open on mobile:
QR code

the board is not soldered, you need to solder the 5V module by yourself if you are a Beginner ,please see the wiki http://code.google.com/p/ardupilot-mega/wiki/Voltage#APM_2.5:_Using_the_APM_2.5_Power_Module_to_measure_current_and_v The APM 2.5 Power Module is a simple way of providing your APM 2.5 with clean power from a LiPo battery as well as current consumption and battery voltage measurements, all through a 6-pos cable. The on-board switching regulator outputs 5.3V and a maximum of 2.25A from up to a 4S LiPo battery. The Power Module comes completely assembled with Deans connectors, and wrapped in shrink tubing for protection. Note: The Power Module is only designed to power APM, a RC receiver and APM accessories (GPS, 3DR radio). It is not designed to power servos. Use your aircraft's own ESC/BEC for that. Specifications: Max input voltage: 18V Max current sensing: 90A - Voltage and current measurement configured for 5V ADC Switching regulator outputs 5.3V and 2.25A max 6-pos DF13 cable plugs directly to APM 2.5's 'PM' connector We ship to PayPal's address ONLY. Please make sure your address in PayPal is matched with your shipping address before you pay. Please indicate your personal requirement, such as colors, packages, value of declaration etc, at paypal's message when you pay to us. Our price does not include taxes, VAT, or other hidden charges. We try our best to satisfy every buyer, so if you have any problem, please contact us , please believe in our strength solving the problem. ALL Items With Tracking Number!!!!!!!!!!!!!!
