Arduino 2 Channel Relay Shield

AU $10.90

Sydney, Australia
Jun 9th

Open on mobile:
QR code

Overview 2 channel relay shield for Arduino, with 2 mechanical relays and 2 MOS switch, providing an easy way for low voltage application to control high voltage device. DESCRIPTIONIS Shield with 2 channels mechanical relays and 2 channels MOS switch, providing an easy way for applications of voltage controlling from low to high. The 3Pins breakout make it easy to build a project or prototyping quickly, by using many existing sensor modules (Electronic Brick). And there are some wireless interface breakout on board, you can use it to connect with many wireless module. Features 2 mechanical relays with photo-coupled circuit 2 MOS switch with internal power supply Xbee, nRF24l02, RF315/433M module wireless interface Arduino AD pins 3 PINs interface breakout for Sensor module (Electronic Brick) Equipped with screw holes for easy installation Native Arduino/Iteaduino compatibility Hardware Interface Pin Description UART 1 Ground 2 5V supply 3 Tx 4 Rx AD0/1/2 1 AD0/1/2 2 5V supply 3 Ground IIC 1 Ground 2 5V supply 3 Data wire of IIC 4 Clock wire of IIC nRF24L01+ Socket 1 GND 2 VCC33 3 CE(Chip Enable) 4 SPI_CS 5 SPI_SCK 6 SPI_MOSI 7 SPI_MISO 8 nRF24L01+ IRQ Output XBee Socket 1 VCC33 2 Dout 3 Din 10 GNF 4,5,6,7,8,9,11,12,13,14,15,16,17,18,19,20 No Connect 315/433MHz RF module socket 1 GND 2 VCC 3 D0 4 D1 5 D2 6 D3 7 VT Specification Version 1.0 Compatible Mainboard Arduino Deumlanove/UNO Arduino MEGA Arduino Nano Freeduino Iteaduino Iteaduino ADK Iteaduino BT Iteaduino MEGA 2560 Seeeduino Seeduino MEGA Shield Functions Control Board Size 60mm x 68mm Operation Level Digital 5V Stackable No Model IM120417022 Accessories No Weight 50.00g Download Demo Code DC_IM120417022_ISShield Datasheet DS_IM120417022_ISShield Schematic SCH_IM120417022_ISShield
