Arduino Poe Wiznet W5500 Ethernet Shield

US $92

Sydney, Australia
Jun 17th

Open on mobile:
QR code

We do not charge extra for shipping, what customers pay is the exact amount that we pay to Australia Post. Australia Post charges in block of 500 gram, and often electronic products that we sell are just around 50-100g. Therefore we encourage customers to combine multiple items and utilise the automatically calculated combined shipping in order to save shipping fees. Select multiple products required, add them into the shopping cart and checkout in one single payment. Total shipping fees will be calculated accordingly. Overview W5500 Ethernet shield is a WIZnet W5500 breakout board with POE and Micro-SD designed for Arduino platform. 5V/3.3V compatible operation voltage level makes it compatible with Arduino boards, leafmaple, and other Arduino compatible board. DESCRIPTIONW5500 Ethernet shield is a WIZnet W5500 breakout board with POE and Micro-SD designed for Arduino platform. 5V/3.3V compatible operation voltage level makes it compatible with Arduino boards, leafmaple, and other Arduino compatible board. WIZnet„s Hardwired TCP/IP is the market-proven technology that supports TCP, UDP, IPv4, ICMP, ARP, IGMP, and PPPoE protocols. W5500 embeds the 32Kbyte internal memory buffer for the Ethernet packet processing. If you use W5500, you can implement the Ethernet application just by adding the simple socket program. It’s faster and easier way rather than using any other Embedded Ethernet solution. Users can use 8 independent hardware sockets simultaneously. Features 3.3/5V level On-board micro SD card slot Support Endspan and Midspan Modes POE by adding SPD8001 PD module to this shield Supports following Hardwired TCP/IP Protocols: TCP, UDP, ICMP, IPv4, ARP, IGMP, PPPoE Supports 8 independent sockets simultaneously Supports Power down mode Supports Wake on LAN over UDP Supports High Speed Serial Peripheral Interface (SPI MODE 0, 3) Internal 32Kbytes Memory for Tx/Rx Buffers 10BaseT/100BaseTX Ethernet PHY embedded Support Auto Negotiation (Full and half duplex, 10 and 100-based) Not support IP Fragmentation PCB size 83.82mm X 57.91mm X 1.6mm Power supply 5V DC Indicator SPD,LINK,DUP,ACT Communication Protocol SPI Electronic Characteristics Parameter Min. Typical Max. Unit Power supply 4.5 5 5.5 VDC Input voltage VinH(Target voltage=3.3V) 3 3.3 3.6 V Input voltage VinH(Target voltage=5V) 4.5 5 5.5 V Input voltage VinL -0.3 0 0.5 V Current Consumption - - 150 mA Specification Link Wiki N/A Version 1.1 Compatible Mainboard Arduino Deumlanove/UNO Arduino MEGA Iteaduino Iteaduino ADK Iteaduino BT Iteaduino MEGA 2560 Seeeduino Seeduino MEGA Shield Functions Ethernet Board Size 83.82mm X 57.91mm X 1.6mm Operation Level Digital 3.3V Digital 5V Stackable No Model IM140725005 Accessories No Weight 50.0000 Documents Please visit Itead's wiki page for more info about this product.
