Arduino Shield Ekg Emg Board, Electrocardiography Electromyography, New!

US $790

Midland, Ontario, Canada
Jan 29th

Open on mobile:
QR code

Arduino Shield EKG EMG, New Electrocardiography, Electromyography You will receive the exact product displayed in the picture. I will include a supersized picture for you to examine the unit. Included in this sale: Quantity. 1 Arduino Shield EKG EMG board (for EKG EMG PA electrodes please see my other sale online, this auction is for the board only) This is EKG/EMG shield which allow Arduino like boards to capture Electrocardiography Electromyography signals. The shield opens new possibilities to experiment with bio feedback. You can monitor your heartbeat and log your pulse, recognize gestures by monitoring and analysing the muscle activity as done in this project. FEATURES stackable headers up to 6 channel may be stack and wired to A0-A6 analog inputs calibration signal generation by D4/D9 digital output precise Trimmer potentiometer for calibration (all boards are shipped fully assembled, tested and calibrated) input connector for normal or active electrodes works with both 3.3V and 5V Arduino boards DOCUMENTS SHIELD-EKG-EMG Users manual Revision-C HARDWARE SHIELD-EKG-EMG schematic in PDF format released under Creative Commons Attribution-Share Alike 3.0 United States License SHIELD-EKG-EMG schematic and board in Eagle format released under Creative Commons Attribution-Share Alike 3.0 United States License SOFTWARE Electric guru monitoring software, created by Rob Sacks Arduino example for EKG capture and interface to Electric Guru for OLIMEXINO-328/Arduino boards Maple example for EKG capture and interface to Electric Guru for OLIMEXINO-STM32 Pinguino example for EKG capture and interface to Electric Guru for PIC32-PINGUINO/OTG/MX220 (refer to the readme and the comments in the code for more info) WARNING: EKG DEVICE DISCLAIMER IEC601 is a standard that specifies tests and requirements that medical devices must pass before they can be used on humans. However, none of the devices built from these designs have been tested according to these guidelines because of the costs involved. Therefore, a device based on any of these designs may not be used for medical purposes as no medical claims are made. NOTE THAT CONNECTING A DEVICE VIA ELECTRODES TO HUMANS OR ANIMALS IS POTENTIALLY HAZARDOUS AND MAY RESULT IN ELECTRIC SHOCK AND/OR SEIZURE. *Taxes charged on this sale for Canadian residents based on the province you reside. *Please verify shipping options and costs before bidding on this auction if you have any doubts. I only charge the actual shipping costs involved. I charge the Standard CanadaPost shipping rate but I will upgrade to Expedited Shipping at no additional cost. *This item is in stock (in Canada) and will ship the same business day or next business day depending on when it is purchased. *I will ship in a cardboard box to ensure the product reaches you in perfect condition, no worries. Email me with any questions. Thanks. Good Luck on this auction ! Powered by eBay Turbo Lister
