Arduino Yun Compatible Internet Of Things Module

US $28.99

??, ???, China
Mar 4th

Open on mobile:
QR code

Arduino Yun compatible Internet of Things module M32 Internet of Things module is designed for the easy of programming and installation of IoT projects. It is a plug-in module for MS14-S and powered by an AVR ATmega32u4 micro-controller. M32 is Arduino Yun compatible, it communicates with MS14-S CPU via SPI and UART interface and provide the power / GPIOs via the 14 positions screw terminal on MS14-S. M32 can be programmed by the latest Arduino IDE. The board type in Arduino IDE is "Arduino Yun". With the combination of MS14-S, M32 and Arduino Yun software, users can install Internet of Things projects in easy / rapidly way. Features: Internet of Things Gateway module to connect sensor network to internet. Log sensor data and upload to remote server. Control switch/relay from Internet. Easy programming use Arduino IDE. Program/update/ debug via WiFi network. Summary BEE socket1 Microcontroller ATmega32u4 Operating Voltage 5V I/O voltage 5V 3.3V output channel 1 5V output channels 2 SRAM 2.5KB Flash Memory 32KB(of which 4KB used by bootloader) EEPROM 1KB Clock Speed 16Mhz Digital I/O pins 10 Analog input channels 8 PWM channels 4 ESD-protection(IEC 61000-4-2) Over Voltage Protect Power M32 uses 5v power from ms14. The mega32u4 avr is powered by 5v as well. M32 provides 5V or 3.3V output power. 5V: The 5V output power pin is 1+ and 6+ 3.3V: pin 6+ can be used for 3.3v power output, by using the VOUT_SEL jumper. GND: 2 GND pins are available in 1- and 6-. Input and Output Pins Each of the 10 digital i/o pins on the m32 can be used as an input or output, using pinMode(), digitalWrite(), and digitalRead() functions. They operate at 5 volts. Each pin can provide or receive a maximum of 40 mA and has an internal pull-up resistor (disconnected by default) of 20-50 kOhms. In addition, some pins have specialized functions: TWI: 2 (SDA) and 3 (SCL). Support I2C / TWI communication using the Wire library. External Interrupts: 3 (interrupt 0), 2 (interrupt 1). These pins can be configured to trigger an interrupt on a low value, a rising or falling edge, or a change in value. See the attachInterrupt() function for details. PWM: 3, 6, 9, 10. Provide 8-bit PWM output with the analogWrite() function. LED: 13. The "heart beat" LED is connected to digital pin 13. When the pin is HIGH value, the LED is on, when the pin is LOW, it's off. Analog Inputs: A0 - A3, [A6, A8, A10, A11 (on digital pins 4, 6, 9 and 10)]. The m32 has 8 analog inputs, all of which can also be used as digital i/o. Each analog input provide 10 bits of resolution (i.e. 1024 different values). The analog inputs measure from ground to 5 volts. RESET_MS14:11(PB7): Bring this line LOW to reset the AR9331 microprocessor on ms14. Resetting the AR9331 will cause the reboot of the ms14. All the data stored in RAM will be lost and all the programs that are running will be terminated. The reset feature is deactivate by default to avoid error program on 11. Solder a 0ohm capacitor on R14 or short the two ends of this resister will active this feature. ESD and Overvoltage Protection Except 7+ and 7- , all other pins are Overvoltage and ESD protected following the standard IEC 61000-4-2. Internal Connectors The M32 has two on board connectors which are reserve for further development. I2C Connector: This 1x4 (2.54mm) connector has SCL/SDA/5V/GND pin out, it can used to hook up a small I2C PCB and place into MS14. J2 Connector: This connector is reserved for further process the signal on 7+ and 7- pins. USB Connector M32 has a micro USB connector and can act as standard USB COM device. This USB connection can be used to upgrade firmware or debug the software via serial monitor on Arduino IDE. Package Includes M32 module x 1 Shipment & Delivery All items are shipped out within 1-3 business days ( except Holiday, Saturday and Sunday) after payments go clear. All items are packed carefully and originally to avoid damage, shipped out via China or Hongkong Post ePacket (USPS First-Class Mail International) for US destination, Post Airmail(Economy Int'l Shipping without Tracking number) or Registered mail (Standard Int'l Shipping with Tracking number) for other countries, and will take 5-35 business days for delivery depending on your location. It maybe delay due to post office issues, customs issues & holidays or free days. We offer 30 business days warranty for delviery. Please contact us first - Moneyback or Exchange- to get resolved if not. 5-25 business days to Most of Asia countries 7-30 business days to USA, Canada, Australia, UK, Europe countries 14-35 business days to Brazil, Other countries We usually aim to despatch items on the next working day after payment is processed. So please contact us at the same day of payment if you want to cancel orders. Even during busy postage season such as Christmas & New year, we try to despatch items within three working days. We do not despatch on Saturdays, Sundays, Bank or POST Holidays. -NOTE : In case of France, Malta, New Caledonia, Mexico, Argentina, It normally take 4~5 weeks for delivery. Germany, Brazil, Russia buyer allow up to 5~7 weeks for delivery, because of strict customs. Items' delivery ratio Country Delivery Time Working Days (not including holiday) 5-7 8-11 12-14 15-19 20-30 Working Days + Saturday + Sunday 5-12 13-16 17-20 21-25 26-37 United States Rate (item arrived) 5.1% 50.1% 29.6% 10.5% 4.7% United Kingdom Rate (item arrived) 9.9% 63.2% 19.1% 3.4% 4.4% Australia Rate (item arrived) 21.4% 50.0% 14.3% 7.2% 7.1% France Rate (item arrived) 10.5% 28.6% 43.8% 10.1% 7.0% Germany Rate (item arrived) 11.1% 22.2% 30.3% 20.9% 15.5% Canada Rate (item arrived) 0.0% 47.1 31.4% 17.6% 3.9% Other Countries Rate (item arrived) 3.5% 25.0% 47.9% 12.9% 10.7% A mail will be sent to you as soon as items are shipped out, informing you about shipping information. Please wait 2-3 business days or check it in your local post office if items don't reach you as provided. We offer 35 business days shipping warranty for Moneyback or Exchange. Please contact us immediately in ebay messages, if not. Payment & Tax Payments via PayPal only and we only ship to the addreees registered on your ebay account. Please note that eCheck via PayPal takes around 3-7 business days to go clear. All payments must be completed within 7 business days after the auction ends. If not, we preserve the right to cancel orders and open unpaid case. If some question about products or bidding, please contact us immediately in ebay messages . Items are marked as Gift and with lower clearance Value, for shipment. Seller will not be responsible for any taxes or duties. For international shipment, please note as follow, Import duties, taxes, and charges are not included in the item price or shipping charges. These charges are the buyer's responsibilities. Please check with your country's customs office to determine what these additional costs will be prior to buying. Warranty & Return We warrant that the products sold in our website are 100% brand new and free from defects in material and workmanship - We never sell used or refurbished products. We provide 30 days quality guarantee since original purchasing date. If quality problems happen within 5 days after you recieve your item, please contact us immediately. A replacement or refund will be arranged for all defective products returned, subject to verification of defect. Returned item must be in original packaging and box in case of any return issues. Please contact us to get right return address before you send it back. Feedback & Comments We strive to keep all our customers satisfied with great customer service. So please contact us first to get resolved if you encounter any issue. Good feedback and 5 ????? means great rating on ebay. So please leave us Good Feedback and 5 ????? when you receive items and they work okay. Your satisfaction is important to us. We strive to keep customers satisfied. So when you encounter unsatisfied cases, please contact us immediately in ebay messages and work together to resolve it before you leave negative Feedback and bad commends. Feedback with commends will be automatically left to you when we receive your feedback and commends. Contact US Welcome to Chinese Shopping. For the resellers and providers, we offer special extra mile services to you and to your direct clients! We can dropship your items direct to your costumers' door so you do not have to carry any inventory, and just reap the profits over and over again, all under your name and brand! Thank you for visiting our humble store. Please contact us first in ebay messages if you have some question or any issue.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Dragino
Country/Region of Manufacture	China
Model	m32
