Arrow Hart Non-nema Twist Locking Connector Female Plug 30a 120/208v 3y 3433n

US $21.99

Jamestown, New York, United States
Sep 1st

Open on mobile:
QR code

Fruit Ridge Tools, LLC Our eBay Store Contact Us Add to Favorite Sellers Arrow Hart Non-NEMA Twist Locking Connector Female Plug 30A 120/208V 3Y 3433N Product Details Quantity in Lot: 1 Brand: Leviton Part Number: 3433N Color: Gray Type: Locking Connector Phase (if applicable) : 3 Phase Y Poles: 4 Wires: 4 NEMA Number: Non-NEMA Amperage: 30A Voltage: 120/208V Grade: Industrial Specification Grade Ground: Non-Grounding Arrow Hart 3433N locking connector. Industrial Specification Grade, Non-NEMA, 4-pole, 4-wire, non-grounding, rated 30A 120/280V 3-phase Y. Cord grip range: .590"-1.150". Terminals accommodate #18-#10 AWG. Non-UL listed - for replacement use only. Each is individually packaged; packaging may differ from photo. Features include:One-piece, rivetless, .035" thick brass contacts offer enlarged contact surface area, low heat, and long life Cleat on contacts cuts oxidation when plug blade enter contact surfaceInternal wiring chambers isolate individual conductors to prevent flashover, arcing, and stray strands of wire Deep-funnelled, large rectangular-shaped chamfered wire wells guide conductors into termination position Transparent wiring chambers provide a means of visual inspection of conductors and terminals Wire clamps move within individual chambers to provide positive crimp lock without cutting wire strands Color-coded terminal screws Molded-in strip gage provides correct measurement for proper strip length of conductorCaptive terminal screws eliminate nuisance dropping and searching for missing screws Positive crimp contact plate bundles stranded wire maximizing wire/clamp surface contact Combination #10-32 deep slotted/ Phillips brass screws easily torque to 10-14 in.-lbs. Super tough nylon body resists damage from severe impact, abrasion, and chemical attack Wiring module keyed to body for easy assembly. Deep slotted/Phillips steel screws secure wiring module (12-14 in.-lbs.) to bodyErgonomically designed fluted body with radial gripping ridge creates an ideal surface for gripping, turning, and pullingNEMA configuration, agency certifications, and device rating are molded on front of device to assist with identificationExternal cord clamp utilizes deep slotted/Phillips steel screws that are backed out and positioned inside shrouded pockets to prevent slippage of screwdriver blade when tightening cord clamp screws External clamp accepts wire mesh grips. Strain relief insert is easily removed without removing cord clamp to accommodate larger cords. Cable gage identifies maximum cord size allowed with strain relief insert This is New Old Stock and is returnable for any reason. (SKU # AH3433N-EA; Weight: 0.55 lbs.)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Leviton
Phase	3 Phase Y
Type	Electrical Plug
Poles	4
Number of Outlets	1
Wires	4
Features	Locking Plug
Model	Hart-Lock
Output Voltage	125 V
Interchange Number	3433-C (Leviton)
Input Voltage	120 V
Number of Outputs	1
Maximum Input Current	30 A
Non-Domestic Product	No
MPN	3433N
Termination Type	Clamp
Color	Gray
Interchange Number (4)	3433-SS (Pass and Seymour)
Recommended Environment	Indoor
Interchange Number (6)	HBL3433C (Hubbell)
Resistance Properties	Impact Resistant
Interchange Number (5)	3433C (Marinco)
Material	Nylon
Style	Traditional
Country/Region of Manufacture	Unknown
Number of Gangs	1
Custom Bundle	No
Quantity	1
Bundle Description	Does Not Apply
Gender	Female
Condition Description	New (Old Stock)
Installation Area	Indoor
Voltage	120/208V
Current Type	AC
Amperage	30A
Connection Type	Turn Locking
Device Type	Locking Connector
Current Rating	30 A
Grade	Industrial Specification Grade
Mounting Style	Cable
Ground	Non-Grounding
Number of Poles	4
Lot Quantity	1
Warranty	60 Day
NEMA Number	Non-NEMA
UPC	040893680118
