Atten At5011+ Spectrum Analyzer 150khz To 1ghz Tracking

US $1,069.00

Hong Kong Taxe free, Hong Kong
Jan 29th

Open on mobile:
QR code

We ship to you via EMS and will take about 5-7 working days only, 1 year warranty Product Description: AT5010 /AT5011 is the perfect instrument for analyzing any kind of signal within the frequency range of 0.15 to 1050 MHz, and is best suited for meeting the RF measurement needs of education and industry. Features: •Frequency Range: 150KHz to 500MHz •4 1/2 Digit Display: Centre & Marker Frequency, •0.1MHz Resolution •Amplitude Range: -100dBm to +13dBm •Filters: 20KHz, 250KHz & Video Filter. •Output Power: +1dBm to -50dBm (50 ohms) •Built-in Tracking Generator: 0.15MHz to 1050MHz (Only for Model AT5011+) Models: •AT5010 1GHz Standard Model •AT5011+ 1GHz with Tracking Generator Technical Specifications: Frequency: Frequency range 150 KHz to 1050MHz (-3dB) Center Frequency +/-100KHz Resolution of frequency display Resolution 100KHz, ( 4 1/2 digit ) Marker Accuracy 0.1% Span +100KHz Frequency Stability (Drift) <150 KHz / hr Frequency Span Zero span 0Hz/div, and 100 KHz/div to 100MHz/div in 1-2-5 sequence Accuracy +/-10% RBW (-3dB) Resolution 20 KHz & 250KHz Video Bandwidth, VBW 400 KHz Sweep Time (Fixed) 23ms Amplitude: Amplitude Range -100dBm to +13dBm Screen Display Range 80dB (10dB/div)., 8 div Reference Level -27dBm to +13dBm (in 10dB steps), -27,-17,-7,+3 and +13dBm Accuracy (Ref. Level) +/-2dB Average Noise Level -103dBm (25 0KHz RBW) Frequency Response (Relative to 250MHz, ATTN 10dB) +/-2dB Inter-modulation (3rd order) (Spurious Response) <-75dBc (2 signals, -27dBm each, Freq. Distance >3MHz) Harmonic Distortion (2nd, 3rd) <-75dB Absolute Amplitude Accuracy +/-2.5dB Input Input Impedance 50 ohms Input Connector BNC Input Attenuator 0 to 40 dB (4 x 10 dB steps) Input Attenuator Accuracy +/-2dB / 10dB step Max. Input Level +10dBm, (0dB attenuation), DC : +/-25V AT5011+ Tracking Generator Specifications: •Output Frequency Range: 150KHz to 1050MHz. •Output Power Level: -50dBm to +1dBm (in 10dB steps & Variable). •Output Attenuator: 0 to 40 dB (4 x 10 dB steps). •Output Attenuator Accuracy: +/-1dB. •Output Flatness (150KHz to 1050MHz): +/-1.5dB. •Spurious Outputs: Harmonic Spurs & Non harmonic Spurs( RFI): <20dBc. •Output Impedance: 50 ohms (BNC female).
