Attenuator/Switch, Coaxial, 50?, Bi-Phase, 1 to 200 MHz, BNC Connectors (ZAS-3), US $20.00 – Picture 0
Attenuator/Switch, Coaxial, 50?, Bi-Phase, 1 to 200 MHz, BNC Connectors (ZAS-3), US $20.00 – Picture 0

Attenuator/switch, Coaxial, 50?, Bi-phase, 1 To 200 Mhz, Bnc Connectors (zas-3)

US $20.00

  • Albuquerque, New Mexico, United States
  • Jan 29th
Open on mobile:
QR code
<table border="0" cellSpacing="0" cellPadding="0" width="100%"> <tbody> <tr> <td bgColor="#edfdd9" vAlign="top" align="left"> <table border="0" width="100%"> <tbody> <tr> <td> <table border="0" cellPadding="0" width="100%"> <tbody> <tr> <td bgColor="#edfdd9" align="left"><font size="2"><font face="Arial"><font color="#000000"> <!--— ----><!--— ----> <b>Attenuator/Switch, Coaxial, 50?, Bi-Phase, 1 to 200 MHz, BNC Connectors (ZAS-3)</b><br> <b>Mini-Circuits / MCL #ZAS-3</b><br><br>   <b>FEATURES</b> <li>Wideband, 1 to 200 MHz <li>Rugged Shielded Case <li>Excellent Phase and Amplitude Unbalance <li>Low Insertion Loss, 1.6 dB Typ.<br><br>   <b>APPLICATIONS</b> <li>Bi-Phase Modulator <li>Electronic Attenuator<br><br>   <b>MAXIMUM RATINGS</b> <li>Operating Temperature: -55°C to 100°C <li>Storage Temperature: -55°C to 100°C <li>Control Current: 30mA<br><br>   <b>COAXIAL CONNECTIONS</b> <li>Input: 3 <li>Output: 1 <li>Control: 2<br><br>   <b>ELECTRICAL SPECIFICATIONS</b><br> <li>FREQUENCY (MHz):<br> F<sub>L</sub>-f<sub>U</sub>: 1-200<br> Con: DC-0.05 <li>INSERTION LOSS (dB) ±20 mA<br> Mid-Band (m)<br> Typ.: 1.4<br> Max: 2<br> Total Range:<br> Typ: 1.6<br> Max: 2.5 <li>MAX. INPUT PWR (dBm) ±20mA:<br> 1 dB Compr.: 15<br> No Damage: 30 <li> IN-OUT ISOLATION (dB) 0 mA<br> L<br> Typ: 65<br> Min: 50<br> M<br> Typ: 50<br> Min: 40<br> U<br> Typ: 50<br> Min: 35<br> <li>BI-PHASE X (±20 mA) Typ.<br> ?Amp (dB):<br> m: 0.10<br> Total Range: 0.1<br> Phase (deg.) Deviation From 180°<br> m: 0.5<br> Total Range: 1.0<br><br> <b>LINKS RELATED TO THIS PRODUCT</b> <li>Manufacturer Product Datasheet:<br> <a href="http://www.minicircuits.com/pdfs/ZFSC-3-13.pdf">
Condition:
Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...
Brand Mini-Circuits / MCL
Country/Region of Manufacture United States
MPN ZAS-3
