Automatic For Voltage Avr Generator Regulator Sx440

US $47.78

Shanghai, China
Jan 30th

Open on mobile:
QR code

AUTOMATIC FOR VOLTAGE AVR GENERATOR REGULATOR SX440 PLASTIC MACHINE BAG SEMI-AUTO SEALING FR-900 VERTICAL SEALER BAND H180 FLAME POLISHER WELDER OXYGEN W/ CE HYDROGEN POLISHING 95L WATER MACHINE PUSH SINGLE N PULL POINTER FORCE 5 TENSION METER DIAL GAUGE WATER-COOLED VFD 220V 2.2KW INVERTER MOTOR WITH SPINDLE Description: 1. SX440 is a two phase sensed Automatic Voltage Regulator (AVR) and forms part of the excitation system for a brush-less generator. 2. The AVR senses the voltage in the main generator winding and control the power fed to the exciter stator and hence the main rotor to maintain the generator output voltage within the specified limits, compensating for load spry, temperature and power factor of the generator. 3. Excitation power is derived from a three-phase permanent magnet generator (PMG), to isolate the AVR control circuits from the effects of nonlinear loads and to reduce radio frequency interference on the generator terminals. Sustained generator short circuit current is another feature of the PMG system. 4. The AVR has the facility for droop CT connection, to allow parallel running with other similarly equipped generators. Specification. Sensing Input. Voltage: 190-264V ac max, 1 phase 2 wire. Frequency: 50-60HZ nominal. Power input. Voltage: 140-220 V ac max, 3 phase,3 wire. Current: 3A/phase. Frequency: 100-120HZ nominal. Out put. Voltage: max 120V/DC. Current: continuous 2.7A/DC. Intermittent 6A for 10 sacs. Resistance: 15 ohms minimum. Regulation: +/-1%. Thermal drift: 0.03% per deck change in AVR ambient. Soft start pump time: 3 sec. Typical system response. AVR response: 10ms. Filed current to 90%: 80ms. Machine Volts to 97%: 300ms. External voltage adjustment: +/-10% with 1k ohm 1W trimmer. Under frequency protection. Set point: 95%HZ. Slope: 170% down to 30HZ. Unit power dissipation: 12 watts maximum. Analogue input. Maximum input: +/-5V/DC. Sensitivity 1V for 5% Generator Volts (adjustable). Input resistance 1k ohm. Quadrature droop input. 10 ohms burden. Max.sensitivity:0.07A for 5% droop OPF. Max.input:0.33A. Over excitation protection. Set point: 75V/DC. Time relay: 10 sec. Environmental. Vibration: 20 -100HZ (50mm/sec), 100Hz 2 kHz. Operating temperature: -40?C to +70 ?C. Relative Humidity: 95%. Storage temperature: -55?C to +80?C. ocsx uwhu kbwl UAC Buyer should pay within 7 days after purchase. We only accept payment via PayPal. Our team focuses on providing high quality products with reasonable price and tries its best to keep transactions as simple as possible. Please be confident of and enjoy your shopping here! Please feel free to contact us via eBay message system or email.
