Visit Our Store Payment Shipping Refunds & Returns Contact Us About Us Autoquip Super Titan Lift Table, Model 24K18 Model Number For This Listing: 24K18 (Click to Enlarge) The Super Titan scissors lift family of hydraulic scissors lifts is designed for those applications that require the highest lifting capacity and/or highest side and end load capacities. With capacities from 6,000 lbs. to 68,000 lbs. and travel from 24" to 120", this family is the heavy weight of hydraulic scissors lifts. Typical industrial applications would include handling heavy eccentric loads such as steel coils, paper rolls, sheet metal stampings, and dies. The large axle or edge loading capacities allow movement of heavy loads with the stability otherwise impossible with "beefed-up" smaller lift tables. Features Benefits Lubricated-for-life composite bearings on all pivot points • Maintenance free bearings, no greasing required Solid one-piece steel legs with stiffener bars • Minimal platform deflection Turned, ground, polished and hard-chromed axle pins • Extended bearing life Direct thrust cylinders • Provides the lowest collapsed height Chrome plated cylinder rods • Corrosion resistance adds to life of cylinder Double wire braided hydraulic hoses • Extended hose life for added safety Velocity fuses on cylinders • Controlled descent in case of severed hose Maintenance (safety) devices • Easy servicing of hydraulic components Polyethylene fluid reservoir • Easy inspection for fluid level, condensation and pollutants Factory tested to 110% of capacity • Exacting standards means it works the first time, every time Built and designed in accordance with ANSI HM29.1 • Designed to meet and exceed all industry standards Safety labels comply with ANSI Z535 • Adds to employee's safety as the lift meets all industry standards for labeling One year warranty • Built to last with the best warranty in the industry Compare with other available Autoquip Super Titan Scissor Lift Tables (Standard Models): CALL FOR FREE QUOTE (630) 340-4887 or Toll Free (877) 424-4908 AUTOQUIP SUPER TITAN LIFT TABLES AVAILABLE IN OUR EBAY STORE: [24" Travel to 120" Travel] Model Travel (inches) Capacity (lbs#) Lowered Height (inches) Raised Height (inches) Base Frame Width (inches) Base Frame Length (inches) Minimum Platform Width (inches) Minimum Platform Length (inches) Maximum Platform Width (inches) Maximum Platform Length (inches) Raising or Lowering Time Loaded (seconds) Shipping Weight Approx# (lbs#) 24K18 24 18000 12 1/2 36.25 42 60 42 60 72 96 12 3000 24L20 24 20000 15 1/2 39.25 42 60 42 60 72 96 15 3150 24M23 24 23000 18 3/4 42 1/2 42 60 42 60 72 96 17 3300 24K27 24 27000 12 5/8 36 3/8 42 60 42 60 72 96 18 3200 24L31 36 31000 15 5/8 39 3/8 42 60 42 60 72 96 22 3350 24M35 36 35000 18 7/8 42 5/8 42 60 42 60 72 96 25 3500 36C8F100 36 10000 18 3/4 54 3/4 24 36 24 36 48 120 39 1080 36C8F120 36 12000 18 3/4 54 3/4 24 64 24 64 48 120 39 1080 36KK15 36 15000 12 /12 48 /12 42 84 42 84 72 120 21 3750 36LL21 36 21000 16 52 42 84 42 84 72 120 23 4000 36KK24 36 24000 12 1/2 60 1/2 42 84 42 84 72 120 32 4050 36LL24 36 32000 16 52 42 84 42 84 72 120 37 4300 36MM40 36 40000 19 3/8 55 3/8 42 84 42 84 72 120 41 4450 48C8F100 48 10000 12 1/2 60 1/2 24 64 24 64 48 96 52 1200 48KK15 48 15000 12 1/2 60 1/2 42 84 42 84 72 96 29 3750 48LL21 48 21000 16 64 42 84 42 84 72 96 33 4000 48KK24 48 24000 12 1/2 60 1/2 42 84 42 84 72 96 44 4050 48LL24 48 32000 16 64 42 84 42 84 72 96 49 4300 48MM40 48 40000 19 3/8 67 3/8 42 84 42 84 72 96 44 4450 60KK14 60 14000 12 1/2 72 1/2 42 84 42 84 60 96 36 3750 60KK24 60 24000 12 1/2 72 1/2 42 112 42 112 60 96 55 4050 60R28 60 28000 18 3/4 78 3/4 42 112 42 112 72 144 57 5450 72O10 72 10000 12 1/2 84 1/2 42 112 42 112 72 144 38 4600 72LL15 72 15000 15 1/2 87 1/2 42 112 42 112 72 144 39 4900 72LL24 72 24000 15 1/2 87 1/2 42 112 42 112 72 144 56 5200 84LL12 84 12000 15 1/2 96 1/2 42 132 42 132 72 168 37 5600 84LL20 84 20000 15 1/2 96 1/2 42 132 42 132 72 168 55 5900 96LL11 96 11000 15 1/2 111 1/2 42 150 24 64 72 180 42 6200 96LL18 96 18000 15 1/2 111 1/2 42 150 24 64 72 180 58 6500 120LL6 120 6000 15 1/2 135 1/2 24 64 24 64 48 96 40 7500 120LL11 120 11000 15 1/2 135 1/2 32 87 32 87 60 120 45 7800 SHIPPING INFO: U.S. and International Buyers NOTE:This item requires shipping via freight carrier - not included in price. You may use your own carrier or pick up your item. Please call Toll Free 1-877-424-4908 or Direct at 630-340-4887 or email quote_request@hayestrading.com to request a freight quote and production lead time. Lead times vary for each product and for multiple item orders. More Material Handling & Industrial Selections: Box Dumpers Drum Handling Gantry Cranes Scissor Lift Tables Trolleys Double Scissor Lift Forklift Ramps Jib Cranes Stackers Trash Can Dumper Drill Sharpeners Hoists Lift Trucks Strapping Machines Yard Ramps Docklevelers Hoppers Pallet Servers Stretch Wrap Machines Skid Steer Equip. Drum Crusher Hydraulic Stackers Scissor Carts Tote Dumpers Loading Dock Eq. About Us Our Business-Industrial division offers Material Handling Equipment, including Yard Ramps, Dumpers, Scissor Lifts, Drum Handling Equipment, Dock Levelers and other industrial equipment. We are authorized distributors for Arrow Material Handling, Autoquip Corporation, Bluff Manufacturing, Darex Industrial Drill Sharpeners, Dearborn Crane, Gorbel, Genie Industries, Handling Systems International, Southworth, Spanco,Vestil Manufacturing and dozens more. . Policies PAYMENT OPTIONS: We accept 1) PayPal, 2) Company Checks, 3) Cashiers Checks, 4) All major credit cards, 5) Wire Transfers, Electric Checks and Transfers, and 6) Financing for purchases over $2,000 - Request Application Payment arrangements can be made by calling Toll Free 1-877-424-4908 or Direct at (630) 340-4887. We can set terms based upon credit. Credit Options: 30% Due at time of order, remainder due prior to shipping; For any questions regarding payment or to process a direct credit card purchase, please call Toll Free 1-877-424-4908 or Direct at (630) 340-4887 or email us at sales@hayestrading.com. TAXES & FEES: ILLINOIS SALES TAX: Hayes Trading Co is an Illinois corporation. Orders within the state of Illinois are charged a 7.75% sales tax. HANDLING: There are NO additional handling charges added to your stated shipping cost. Your total cost is the price of your item plus the stated shipping charge and insurance, if applicable. SHIPPING: U.S. and International Buyers NOTE: This item is shipped via freight, fully insured. You may also use your own carrier or arrange for pick up. Please call Toll Free 1-877-424-4908 or Direct at (630) 340-4887 or email quote_request@hayestrading.com to request a Freight Quote. Shipping lead times vary based upon production schedules & multiple item orders (from 2-6 weeks). We can provide current production lead times upon request. INTERNATIONAL SHIPMENTS: We ship worldwide for most items. International shipping charges vary due to weight, size and destination. All customs and other country specific charges are the responsibility of the buyer. We reserve the right to request additional information from international buyers or to reject buyers with negative feedback history or zero feedback. DAILY OPERATIONS: M-F 8am-5pm CST. Shipping timeframes do not include Saturday, Sunday, or Holidays. REFUNDS & RETURNS: We accept returns 14 days following delivery of your order (20 days for international buyers). Any merchandise authorized for return must be new, complete, and in saleable condition. A copy of our original receipt and the Return Authorization number (provided by us) must be included, call Toll Free 1-877-424-4908 or Direct at (630) 340-4887 or email us at returns@hayestrading.com. All returns must be shipped prepaid. All industrial equipment returns are subject to a 20% restocking fee plus any refurbishing cost, if necessary. PRIVACY POLICY:ALL information on our customers is absolutely confidential and may only be shared with our suppliers as necessary to process and ship your order. We do not sell or distribute names, email addresses, phone numbers or addresses for any reason. CONTACT US: EMAIL: Send an email to sales@hayestrading.com CLICK: Click on "Ask the seller a question" CALL US: Toll Free 1-877-424-4908 or Direct at (630) 340-4887 FAX: (630) 240-255-7731 We will respond within 24 Hours (Usually much less!) All other trademarks, logos, service marks, product names, and company names in this listing are the property of their respective owners. Hayes Trading Co 2320 Sans Souci, Aurora, IL 60506 Toll Free 1-877-424-4908 or Direct at (630) 340-4887 Incorporated In The State Of Illinois CCR CAGE CODE: 339U3; Certified NMSDC Supplier #CH2622 PRIMARY NAICS CODES: 423830, 423840 PRIMARY SIC CODES: 5085, 5084 Be sure to add us to your favorites list!
