Av5105 Survailance Ip Camera Arecont Vision 5mp

US $224

Sherman Oaks, California, United States
Jan 30th

Open on mobile:
QR code

5 Megapixel H.264/MJPEG Color Camera, 2592x1944 Resolution 5.00 MP Full Field of View (FOV) Resolutions 2592(H)x1944(V) 5 megapixel 1296(H)x968(V) 1/4 resolution Frame Rate 9.0 Mechanical 3"W (76 mm) x 2.5"H (63.5 mm) x 2.25"D (57mm) (w/o lens) 8.6 oz (243 grams) (w/o lens) C/CS lens mount Cropped Resolution 2560x1600 WQXGA 2048x1536 3MP 1920x1200 WUXGA 1920x1080 HDTV-1080p 1600x1200 2 MP 1280x1024 1.3 MP 1280x720 HDTV-720p 1024x768 XGA 800x600 SVGA 704x570 PAL 704x480 NTSC 640x480 VGA 352x288 CIF 320x240 SIF Data Transmission Video frame rate up to - 9fps @ 2592x1944 - 12fps @ 2560x1600 - 15fps @ 2048x1536 - 24fpsfps @ 1600x1200 - 30fps @ 1280x1024 Compression type - H.264 (MPEG4, Part 10) - Motion JPEG 21 levels of quality TFTP, HTTP, RTSP, RTP over TCP, RTP over UDP image transmission protocols 100Base-T Ethernet Network Interface Bit rate control from 100Kbps to 10Mbps Multi-streaming: 4 non-identical streams Electrical General purpose opto-coupled input and output Power over Ethernet (PoE): PoE 802.3af for camera Auxiliary power 12-48V DC, 24V AC Power consumption: 4.5 Watts maximum Optional DC AI connection Regulatory FCC, CE, RoHS, UL Standard N/A Programmability Auto Exposure (AE) and Gain Control (AGC) >120dB On-camera real-time motion detection with 64 detection zones Auto backlight compensation Auto multi-matrix white balance 50/60Hz selectable flicker control Electronic pan, tilt, zoom (PTZ) Electronic image flip - 180 degree rotation Resolution windowing down to 32x32 pixel Programmable shutter speed to help control motion blur MoonLight™ mode - extended exposure and proprietary noise cancellation Programmable resolution, brightness, saturation, gamma, sharpness, tint Simultaneous delivery of full field of view and zoomed images Bandwidth & storage savings by running at 1/4 resolution Environment Operating temperature 0°C (32 °F) to +50°C (122 °F) Storage temperature -20°C (-4 °F) to +60°C (140 °F) Humidity 0% to 90% (non-condensing) Product Imaging 5 megapixel CMOS image sensor 2592(H) x 1944(V) pixel array 1/2.5” optical format 2.2 µm pixel pitch Bayer mosaic RGB filter Minimum illumination of: Color: 0.3 Lux @ F1.4 Day/Night: 0 Lux, IR sensitive Dynamic range 70.1 dB Maximum SNR 44.1 dB

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Type	Bullet
Model	AV5105
Connectivity	IP/Network - Wired
Features	Power over Ethernet (PoE)
Color Mode	Color
Country/Region of Manufacture	United States
Brand	Arecont Vision
