B&b Electronics 485drc Rs-422/485 Converter

US $59.95

New Haven, Michigan, United States
Jan 29th

Open on mobile:
QR code

Models 485DRC and 485LDRC Industrial DIN Rail Mounted Optically Isolated RS-232 to RS-422/485 Converters With Surge Suppression Introduction The DIN Rail mountable Models 485DRC and 485LDRC optically isolate and convert unbalanced, full or half-duplex RS-232 signals to optically isolated, balanced, full or half-duplex RS-422 or RS-485 signals at baud rates up to 115.2 kbps. These units also surge suppress the RS-422/485 lines. They feature Send Data Control circuitry so no software control of handshake lines is required in RS-485 mode. LEDs The 485LDRC includes all the above features plus 3 LED’s: one indicating RS-485 Transmit Data, one for RS-485 Receive Data, and one for power. Description The 485DRC/485LDRC has screw down terminal blocks on the RS-232 side and the RS-422/RS-485 side. Transmit (TD), Receive (RD) and Ground are supported on the RS-232 side. The unit is powered by a supply voltage of 10 to 30VDC on the RS-232 side, useful where 24VDC is commonly found. Transmit Data A (-), Transmit Data B (+), Receive Data A (-), Receive Data B (+), and Ground are supported on the RS-422/RS-485 side. Communication features on the 485DRC/485LDRC are dipswitch selectable on the unit. RS-485 Mode with Send Data Control Send Data Control recognizes the first bit of data from the RS-232 side, enables the transmitter and disables the receiver. After the last bit of data is sent from the RS-232 side, the timeout waits one character length, then disables the transmitter and enables the receiver. The timeout can be selected with dipswitches or by changing the value of R11 (see Table 2). If the system requires the line to be "turned around" faster, i.e. the slave device starts responding before the transmitter of the 485DRC/485LDRC is disabled, R11 can be changed to meet the specific baud rate. Termination resistance can be selected with Switch 5 for high baud rates and long cable distances. See B&B Electronics’ RS-422/485 Application Note available on the website or by mail. Factory setting: 9600 baud.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	B&B Electronics
Model	485DRC
