Barber Colman 16-36 16" X 36" Hobber Mechanical

US $30000

Machesney Park, Illinois, United States
Nov 12th

Open on mobile:
QR code

Offered by Machine Tool Builders Machesney Park, IL. Please note: Buyer is responsible for rigging and shipping from our facility to yours. Machine Tool Builders (MTB) can assist with logistics if needed. We also offer a Recertification Program as stated below for an additional fee. Please contact Anne at MTB for questions, arrangements or additional services.(815) 636-7502 Learn more about MTB on our website. machinetoolbuilders dot com Description Model Manufacturer Barber Colman Model 16-36 Serial Number 4618 Year of manufacture 1978 Mechanical Specifications Pitch rating (Ideal Conditions) 6 DP 4.233333 Mod Maximum workpiece diameter 16.000 in 406.4 mm Maximum facewidth 13.000 in 330.2 mm Maximum radial center distance 9.500 in 241.3 mm Minimum radial center distance 1.250 in 31.75 mm Maximum axial travel 15.000 in 381 mm Maximum distance table face to tail center 60.000 in 1524 mm Maximum distance table face to C/L of hob 39.500 in 1003.3 mm Minimum distance table face to C/L of hob 3.500 in 88.9 mm Worktable diameter 7.250 in 184.15 mm Workhead spindle bore 4.188 in 106.3625 mm Index worm gear diameter 12.700 in 322.58 mm Worktable Starts 2 Threads Maximum hob diameter 5.000 in 127 mm Maximum hob length 5.000 in 127 mm Maximum hob shift travel 3.500 in 88.9 mm Maximum number of teeth 300 Teeth Minimum number of teeth 5 Teeth Maximum swivel angle -45 deg 45 deg Length 109.250 in 2774.95 mm Width 31.875 in 809.625 mm Height 72.500 in 1841.5 mm Main Motor Power 2 HP 1.5 kW Machine Weight 9300 lbs 4218 kg Plant power 480 VAC 60 Hz Features Air operated tail center Automatic hob shift Double Thread Index Worm (Standard Accuracy) Controls Relay Logic Optional Machine Recertification Program All broken electrical wires and cables will be repaired All cycles will be tested and verified as fully functional All defective controls will be replaced or repaired All defective sensors will be replaced All features will be tested and verified as fully functional All filters will be changed All worn hoses will be replaced Coolant system checked for problems Coolant tank and chip collection system cleaned Hob head will be checked for problems Hydraulic system drained and cleaned Machine will be thoroughly cleaned Ways and gibs checked for problems Work table drive system checked for problems Machine Includes Integral coolant tank, no conveyor No hob arbor. (One can be quoted additionally) Assortment of change gears Two copies of the operations manuals Two copies of the maintenance documentation 30 Day return warranty on the machine The aforementioned description and listing of specifications and accessory equipment is correct and accurate to the best of our knowledge. However, it should not be considered binding in any regard, as we reserve the right to change and/or alter same without prior notice. Consequently the buyer is responsible for confirming same, upon physical inspection and inventory of the machine(s) and all related accessory equipment.
