BDR-999B 2.3" LED Display, US $349.00 – Picture 0
BDR-999B 2.3" LED Display, US $349.00 – Picture 0

Bdr-999b 2.3" Led Display

US $349.00

  • Portland, Oregon, United States
  • Jan 29th
Open on mobile:
QR code
? Replaces separate display and meter modules ?  Blue LED (Optional Red or Green also available, please ask seller)? Bezel-mount or 180? gimbal mounting in multiple planes - wall, bench, ceiling or panel mounting ? Resistant to RF and EMI? Rugged metal case ? 2.3" LED display visible from across the room? Multifunction loop, set-voltage, adjustable-voltage inputs, all included ? Isolated AC/DC supply works in many control applications    Display:  Digits: 3 1/2 digits (±1999 counts)   Type: 2.3" (58.4mm) - 7 segment BLUE LED   (Optional red or green also available, ask seller) Inputs:  Set Voltage Ranges: ±200mV, ± 2V, ±20VDC     Configuration:  bipolar differential     Protection:  ±350Vdc, (±100Vdc on 200mV Range)     Impedance:  >1M?, (>10M? on 200mV Range)   Adj. Voltage Ranges:  200mV, 5V, 10VDC     Offset Range:  1999 to +1999     Gain Range:  1 to 1000   4-20mA Loop Ranges:  4 to 20mA DC     Configuration:  bipolar differential     Protection:  ±30mA     Loop Impedance:  300? nominal Performance:  Accuracy:  ±0.1% fs + 1 count)   Conversion Rate:  3 per second   Normal Mode Rejection:  >30 dB @ 60 Hz   Common Mode Rej.:  >86 dB   Zero Adjustment:  automatic on set voltage ranges   Warmup:  10 minutes typical   Temperature Coeff.:  ± 100 ppm per °C typical Environment:  Operating Range:  -10 to 50 °C   Storage Range:  -40 to 75 °C Power Supply:  BDR-999: 90 to 250 VAC @ 12VA   BDR-924: 10.5 to 30 VAC/DC @ 6VA Mounting:   180° gimbal mounting with 30° stops, or bezel mount Connection:   screw terminals
