Bird Technologies Tx/rx Tuned Bandpass Filter 450-470mhz -new

US $260

Irvine, California, United States
Jan 29th

Open on mobile:
QR code

BIRD TECHNOLOGIES TUNED BANDPASS FILTER 450-470MHZ -NEW MFG: BIRD TECHNOLOGIES - MFG P/N# 1P01-70-01460 DIMENSIONS (inches): 9" H x 4" W x 4" D ** WE ONLY SHIP TO AN USA ADDRESS. WILL NOT SHIP INTERNATIONALLY ** DESCRIPTIONS: 450-470 MHz, Bandpass Cavity Filters The Bandpass cavity passes one narrow band of frequencies and attenuates all others with increasing attenuation above and below the pass frequency. It is equivalent to a parallel-tuned circuit and is most often used for general transmitter spurious clean-up or a sharpening of a single receiver front end selectivity with or without amplification. TX RX bandpass cavities (4", 6", 8” and 10") have adjustable selectivity characteristics (rotatable loops) to allow a trade-off between insertion loss (0.5-3.0 dB) and selectivity. Maximum power handling is typically determined by insertion loss setting. Various Low-Loss High-Rejection Models to choose from. All Loop Plate/connector assemblies are silver-or Alballoy®-plated for low IM. Welded cavity construction and silver-plated tunable probe and loops give superior pass and reject characteristics. SPECIFICATIONS: Frequency Range (MHz) 450-470 Max. pwr., per cavity, @ 0.5 dB IL 100 W (Model 11-70-09) Max. pwr, per cavity, @ 3.0 dB IL 60 W (Model 11-70-09) Impedance (?) 50 VSWR 1.25:1 max. Cavity Length (Electrical) 1/4? Temperature Range (°C) -30 to +60 Cavity Diameter (inches) 4, 6.625 or 10 Number of Cavities 1 Connectors SMA

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Bird Technologies
Country of Manufacture	United States
MPN	1P11-70-01460 -2.5DB
