BOONTON 4500B POWER ANALYZER *Call (760) 806-6600 to RENT this item* DESCRIPTION The Boonton 4500B Peak Power Analyzer is the ideal instrument for capturing, displaying, analyzing and characterizing RF power in both the time and statistical domains. It provides the flexibility to customize the display by allowing selection of the measurements or specific parametric settings and measurement indicators to be displayed and these measurements can be grouped to avoid clutter. The unique B trigger qualifier of the Boonton 4500B Peak Power Analyzer allows a user to qualify the trigger on a specific event or a specific delay time allowing a user-selected pulse to be captured, even when its timing is variable eliminating problematic synchronization issues associated with time jitter within pulse bursts. Features and Specifications of the Boonton 4500B Peak Power Analyzer include: 8.4” TFT color LCD display Displays up to 4 measurement channels, 2 memory channels and 1 math channel simultaneously Automatic peak-to-peak, delay-by-time and delay-by-events triggering Statistical analysis including gated CCDF and PDF with linear or log presentation (optional) Text view of up to 15 time and power measurements per channel Envelope, persistence and roll mode displays GPIB, USB and LAN Peak Power Sensors available with high video bandwidth, fast risetime, and wide dynamic range Applications include: Pulsed RF: RADAR, TDMA and GSM Pseudorandom or Noise-like Signals: CDMA and WLAN Modulated Time Slotted Signals: GSM-EDGE and TD-SCDMA Convenient I/O Windows based connectivity including USB ports for data storage directly to a flash drive Sensor Inputs: RF Frequency Range: 1 MHz to 40 GHz Pulse Measurement Range: -50 to +20 dBm Modulated Measurement Range: -60 to +20 dBm Relative Offset Range: ±100.00 dB Video Bandwidth: 65 MHz Rise Time: <7 nsec Single-Shot Bandwidth: 5 MHz (based on 10 samples per pulse) Pulse Repetition Rate: 50 MHz max Minimum Pulse Width: 6 nsec Time Base: Time Base Range: 5 nsec/div to 1 hr/div Time Base Accuracy: 0.01% Time Base Resolution: 100 psec Time Base Display: Sweeping or roll mode Trigger: Trigger Source: Channel 1 (internal), Channel 2 (internal, with optional channel 2) External trigger 1 External trigger 2 (with optional channel 2) Trigger Slope: + or – Trigger Delay Range: Time base setting Delay range; pre trig(-), post trig(+) 5 nsec to 500 nsec -4 msec to +100 msec 1 usec to 10 msec ±4000 divisions 20 msec to 3600 sec -40 to +100 sec Trigger Delay Resolution: 0.02 divisions Trigger Hold-off Resolution: 10 nsec Trigger Mode: Normal, auto, auto peak-to-peak, free Run B Trigger Mode: A only, B delay-by-time, B delayby-events specs B Trigger Source: Chan 1, chan 2, ext trig 1, ext trig 2 B Trigger Slope: + or – B Trigger Events Counter Range: 1 to 999,999 events B Trigger Time Delay Range: 0.0 – 1.0 sec B Trigger Time Delay Resolution: 10 nsec Internal Trigger Level Range: -40 to +20 dBm (sensor-dependent) External Trigger Level Range: ±5 volts, ±50 volts External Trigger Input: 1M or 50 ohm, DC Coupled Measurement System Sensor Inputs: One or two sensor measurement channels Measurement Technique: Random repetitive sampling system that provides pre and post trigger data as well as statistical histogram accumulation Maximum Sampling Rate: 50 Mega-samples/second on up to four channels simultaneously (Equivalent effective sampling rate of 10 Giga-samples/second) Memory Depth: 256K samples per channel at max sampling rate Vertical Resolution: 14-bit A/D Converter Waveform Averaging: 1 to 16,384 samples per data point (time domain measurement) Number of Histogram Bins: 16,384 Size of Sample Bins: 32-bits (4,000 mega-samples) Bin Power Resolution: <0.02 dB Configuration Notes: Standard Configuration *All of our equipment has been tested. Additional Calibration may be available upon request! ~Items sold with shown accessories, a power cord and manual on CD (when available)~ WARRANTY, PAYMENT, AND SHIPPING TERMS Warranty Info & Return Policy We strive to exceed our customer's expectations and maintain 100% Positive Feedback. Although we do not use eBay's automated Return Policy, all goods or equipment sold by AxiomTest include a 30-Day Warranty which starts the day the equipment is shipped. So contact us immediately if there is a discrepancy with your order or an equipment malfunction so we can issue a repair, replacement, or refund. Returns must be shipped with all original packaging and accessories. We will not accept any items with obvious signs of additional wear and tear or internal component alterations. All of our items will ship with “Warranty Void” tamper resistant stickers. If any stickers have been removed or tampered with your refund will be canceled. Please include your RMA # on the packing slip, way bill, or package. *CUSTOMER RESPONSIBLE FOR ANY AND ALL RETURN SHIPPING COSTS* Payment Options Domestic Buyers - PayPal, Wire Transfer, Money Order, Company, Bank, or Personal Check. International Buyers: PayPal or Wire transfer only. All funds must be in US Dollars. Unsecured funds must clear prior to shipment. Wire Transfers subject to a $25 service fee. Shipping Unless noted otherwise, all shipments are done through FedEx. If you would like to utilize your ownshipping account please notify us PRIOR to checkout. Saturday and Residential delivery may be available at an additional third party charge depending on the shipping method you choose. We offer shipping outside of the United States. However, some international laws prohibit us from shipping certain items to certain countries. Additionally, not all countries are supported by our service provider. You may also elect to use your own carrier, but we'll be responsible for providing the correct documentation and scheduling the pickup. We are not set up to ship via USPS, and we will NOT falsify any import documents for international orders - no exceptions. Please note: In all sales where an item is prohibited to ship internationally to a successful buyer, that buyer will be notified of non-shipment and a full refund will be made. We reserve the right not to ship any item internationally that is controlled by the US Department of Commerce’s laws and regulations and deemed non-shippable to that region of the world or to listed individuals. eBay's International Shipping calculations do not include any additional duties, fees, or VAT that may be associated with importing this item into a foreign country - please bid accordingly Sales Tax California residents will be charged sales tax if no resale or tax exempt form is submitted prior to payment. TRIED, TESTED...ACCEPTED.
