Brother Hi-spin Orbital Riveter Machine Br1-104

US $2,500.00

Ortonville, Michigan, United States
Jan 30th

Open on mobile:
QR code

BROTHER HI SPIN ORBITAL RIVETER MACHINE WE HAVE 3-UNITS AVA! MODEL BR1-104 WORKS GREAT!!!! THIS CAN BE PUT BACK UNDER POWER IF NEEDED Brother Horizontal Model BR1-104 Automatic precision riveting machines BR1-104 Principle Of Brother Riveting Method This action eliminates twisting force on the rivet. As a result, no friction is created and no material "tearing" occurs. This method creates followings: >> No damage on riveting for small diameter or plated rivets. >> Riveted surface is clean, nearly polished. >> No fracturing of delicate parts such as ceramics, phenolics, plastic or carbon. >> Swing-joint riveting. Main Features 1. Fine and Correct finish A. Brother riveting motion bears a fine finish to the parts, without impact and friction by rubbing, even if plated pins and fragile substances such as plastics are used. B. Brother riveting mechanism is made up of pressure, stroke and timer time, fine and correct finish can be gained repeatedly, not only fixing joint but also swing-joint finish. 2. Fine stroke adjustable in 0.05 mm (0.002 inch) increments According to adopt stopper nut with micro scale, a small adjustment of stroke can be created precisely. So, there are no cases that riveting conditions are changed due to stroke unstability. 3. Noiseless operation gives quiet working circumstances. 4. Easy setting and simple operation It is very easy to set the jig and to set the stroke. Especially, model BRO machine has the manual change valve which can change the position of spindle to the lowest, so setting is easier. Operations of these machines are very simple (set parts and press foot switch), so skilled operators are not required. 5. Digital parts counter available In model BRO, this counter is standard and after models can be installed in control box. (Option) 6. Multiple spindle machine (Model BRM) and specialized machine to be used Horizontal one bear high efficiency. 7. Model BRO adopts oilless cylinder, easy to maintain. 8. Optional riser block available in model BRO and BRM. Specifications (All Metric equipment) Models Vert. (Net Weight) - Specifications Horiz. (Net Weight) BR1-104 (45kg/99lbs) Stroke of spin head 20(0.79")-40(1.57") Distance between punch and table 45(1.77")-165(6.50") Riveting capacity (Mild Steel Rivet) Under 5(0.20") Working cycle time 0.5-6 second Gauge pressure 2 kgs/cm2 (28.44 lbs/inch2)-5 kgs/cm2(71.10 lbs/inch2) Average air consumption in one cycle 5 N liters Working surface(Vert. Model L x W) 180(7.09") x 310(12.20") Motor rating AC 3 phases 4 pole 200W Occupied space (Vert. Model L x W x H) mm 515 x 395 x 1000 inch 20.28 x 15.55 x 39.37 AS ALWAYS IF YOU HAVE ANY QUESTIONS PLEASE FEEL FREE TO ASK AND I WILL DO MY BEST TO ANSWER. ENJOY BIDDING AND HAVE FUN WITH THE AUCTION!!!!!

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Country of Manufacture	Japan
Model	BR1-104
Brand	BROTHER
