BS-1 semi-universal quick dividing head+6" 160 3-jaw chuck for gear cutting U, US $705.00 – Picture 0
BS-1 semi-universal quick dividing head+6" 160 3-jaw chuck for gear cutting U, US $705.00 – Picture 0

Bs-1 Semi-universal Quick Dividing Head+6" 160 3-jaw Chuck For Gear Cutting U

US $705.00

  • China, China
  • Aug 31st
Open on mobile:
QR code
BS-1 semi-universal dividing head with 6" 3-jaw chuck Description 1.Dividing Head can divide in any angle by the direct,indirect,or diffrenet methods.The ratio between the warm and the warm gear is 40:1. 2.Hardened and ground spindle is rigidly held in a taper roller bearings.Worm is hardened and ground also. 3.The swivel head can be locked of any angle from below 10x horizontal to 90X vertical-precision fitting to base assures smooth rotation. 4.All models have threaded spindle nose and 24 hole dividing plate with easy conversion to fast direct indexing on numbers 2,3,4,6,8,12 and 24. 5.Easy indexing of all numbers from 2 to 380. 6.Accurate precision,little backlash,fine appearance and strong structure so can assure smooth rotation. 7.The center cutting/milling can be implemented with the help of the 3-jaw chuck. Specifications Semi-universal dividing head (head stock) Unit: mm A B H h a b g Center taper Diameter of spindle hole N.W(kg) 293 156 220 128 207 114 16 No. 9 20 36 Semi-universal dividing head (tail stock) A1 B1 H1 h a1 b1 g1 191 80 137 128 150 106 16 Holes Numbers of the dividing plate (worm gear reduction ratio 1:40,) Plate A 15 16 17 18 19 20 Plate B 21 23 27 29 31 33 Plate C 37 39 41 43 47 49 There is a 6" 3-jaw chuck(diameter 160mm) coming with this dividing head,the centering hole is 128mm in height. It includes such parts: 1pcs head stock; 1pcs tail stock; 1pcs 3-Jaw chuck(install on the head stock); 2pcs dividing plate. On Aug-31-21 at 02:44:24 PDT, seller added the following information:
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Unbranded/Generic
MPN Does Not Apply
UPC Does not apply
