Btpro-1000 Qam/8vsb/analog Signal Analyzer

US $650.00

New York, New York, United States
Jan 29th

Open on mobile:
QR code

The BTPRO-1000 is a versatile CATV test instrument for measuring both digital and analog CATV and Broadcast TV signals. Robust and easy to use, BTPRO-1000 provides hours of operating time from its high capacity battery. The instrument comes complete with a soft carrying case, AC main and automotive chargers. An optional Pro:Idiom Key Recovery feature is available for Hospitality applications that employ Pro:Idiom television sets. The option consists of a built-in frequency agile QAM modulator that connects directly to an affected Pro:Idiom TV to provide new encryption key information. Features: QAM/8VSB/NTSC Measurements Extended frequency range of 4-1000 MHz MER, aBER, bBER, Noise Margin and Level/Power measurements plus Spectrum Analysis Automatic quality analysis: FAIL-MARGINAL-PASS Auto Seek & Store Function - an essential feature for creating custom memory channel plans. Scans receivable signals, determines signal type (QAM,8VSB or analog) and stores only those channels having signal levels above user defined values Ingress and Leakage Modes Data Logger Function: Steps through each channel in the "Active" memory plan and stores all related measurements Graphics Display Alpha-numeric keypad Optional TV Key Recovery for Hospitality Pro:Idiom systems SPECIFICATIONS: Level Measurement & Spectrum Analysis Frequency Range: TV, CATV & Radio 4-1000 Mhz Frequency Resolution: 25 kHz RF Input Impedance: 75O(interchangeable "F" connector) Dynamic Range: -59 to +65 dBmV Measurement Resolution: 0.1 dB Level Measurement Accuracy: 1 dB typ. (2 dB max) A/V Ratio: up to 22 dB, +/-1.5 dB (2 dB max) C/N Ratio: up to 45 dB +/-1.5 dB Max; 45-50 dB +/- 2 dB Resolution Filter Bandwidth: 100 kHz @ -3 dB Custom Channel Plans: 25 (199 ch. per plan) Power & Digital Measurements Frequency Band: 4-1000 Mhz Power Measurement: -45 to 65 dBmV BER Measurement: (pre) bBER up to 1 x 10-9 (post) aBER up to 1 x 10-9 MER Measurement: up to 40 dB (1dB typ., 2dB max) Constellation Display: 16-32-64-128-256 QAM Ingress & Spectrum Measurements Frequency: 5 - 65 MHz Level: -55 dBmV to 65 dBmV Accuracy: +/- 2 dB BW: 100 kHz @ -3dB Leakage Measurements Frequency Range: 115 -140 MHz Resolution: 25 kHz Antenna Type:: selectable General: Power Supply: Built in NiMh rechargeable battery, external power supply Battery Duration at 25°: 4 hours Size: 8.5" x 5.0" x 2.4" (215 x 125 x 60 mm) PC Interface: USB Front Panel: Alpha numeric keypad Power Save: TFT backlight timer, brightness
