California Instruments 5001ix Series Ii Ac And Dc Source / Power Analyzer, 5kva

US $16,100.00

Oceanside, California, United States
Jan 29th

Open on mobile:
QR code

CALIFORNIA INSTRUMENTS MODEL 5001IX *Call (760) 806-6600 to RENT this item* DESCRIPTION The California Instruments 5001iX is a combination of AC Source, DC Source and Power Analyzer and is designed for use in a wide variety of applications. The 5001iX provides high load current capability, multi or single phase output modes and built-in power analyzer measurements. Additional features like line distortion simulation (LDS), arbitrary waveform generation and programmable output impedance address requirements for product quality and regulatory compliance. The built-in output transient generation and read back measurement capability offers the convenience of an easy to use and integrated test system, allowing manufacturers of electronic equipment to evaluate and test their products over a wide range of input conditions. The California Instruments 5001iX, with an output frequency range up to 500 Hz, is well suited for aerospace applications. Precise frequency control and accurate load regulation are key requirements in these applications. The standard IEEE-488 control interface and SCPI command language provide for easy integration into existing ATE systems. The 5001iX is designed to meet AC source requirements for use in Euronorm EN 61000 compliance testing. For flicker testing, the programmable output impedance capability of the 5001iX can be used to create the required IEC 725 reference impedance. With a crest factor of up to 5:1, the 5001iX AC source can drive difficult nonlinear loads with ease. Since many modern products use switching power supplies, they have a tendency to pull high repetitive peak currents. The 5001iX can deliver up to 110 Amps of repetitive peak current (low range) to handle such loads. Windows application software is included and provides easy access to the units capabilities, including: Steady state output control (all parameters) Create, run, save, reload and print transient programs Generate and save harmonic waveforms Generate and save arbitrary waveforms Download data from a digital storage oscilloscope Measure and log standard measurements Capture and display output voltage and current waveforms Measure, display, print and log harmonic voltage and current measurements Run IEC61000-4-11, IEC61000-4-14 and IEC61000- 4-28 test programs Display IEEE-488 or RS232C bus traffic to and from the AC Source to help you develop your own test Other features, functions of the 5001iX include: Harmonic Waveform Generation: Define harmonic waveforms by specifying amplitude and phase for up to 50 harmonics. Up to 200 waveforms can be stored and given a user defined name for easy recall. Arbitrary Waveform Generation: Provides an alternative method of specifying AC anomalies by providing specific waveform data points. The GUI program provides a catalog of custom waveforms and also allows real-world waveforms captured on a digital oscilloscope to be downloaded to one of the many AC sourceaЂ™s waveform memories. Simulates the effect of real-world AC power line conditions on a unit under test in both engineering and production environments. AC and DC Transient Generation: Allows complex sequences of voltage, frequency and waveshapes to be generated. This further enhances the 5001iX's capability to simulate AC line conditions or DC disturbances. When combined with the multi phase arbitrary waveform capabilities, the AC and DC output possibilities are truly exceptional. Measurement and Analysis: Built-in data acquisition system that continuously monitors all AC source and load parameters. Conventional Measurements such as Common AC and DC measurement parameters are automatically provided and displayed in numeric form on the front panel LCD display. The following measurements are available: Frequency, Vrms, Irms,, Ipk, Crest Factor, Real Power (Watts), Apparent Power (VA) and Power Factor. Harmonic Analysis: Provides detailed amplitude and phase information on up to 50 harmonics of the fundamental voltage and current for either one or three phases. Harmonic content can be displayed in both tabular and graphical formats on the front panel LCD for immediate feedback to the operator. Alternatively, the included GUI program can be used to display, print and save harmonic measurement data. Total harmonic distortion of both voltage and current is calculated from the harmonic data. Waveform Acquisition: Based on real-time digitization of the voltage and current waveforms using a 4K deep sample buffer. This time domain information provides detailed information on both voltage and current waveshapes. Waveform acquisitions can be triggered at a specific phase angle or from a transient program to allow precise positioning of the captured waveform with respect to the AC source output. Notes / Included Options: 704 - MIL-STD 704D/E Test Firmware Sequence / A, B, C, & F Software *All of our equipment has been tested. Additional Calibration may be available upon request! ~Item sold with shown accessories, a power cord and manual on CD (when available)~ PAYMENT AND SHIPPING INFO Warranty Info & Return Policy We strive to exceed our customer's expectations and maintain 100% Positive Feedback. And although we do not use eBay's automated Return Policy, all goods or equipment sold by AxiomTest include a 30-Day Warranty which starts the day the equipment is shipped. So contact us immediately if there is a discrepancy with your order or an equipment malfunction so we can issue a repair, replacement, or refund. All orders also come with a limited 5-day ROR (Right of Return). This ROR is limited to goods found to be non-acceptable due to cosmetic defect (not previously disclosed) or an item not meeting manufacturer's spec as advertised. ROR does not apply to wrong item(s) ordered by customer, equipment that has been misused or damaged by customer's misuse (intentional or unintentional), or any orders damaged in transit. Returns must be shipped with all original packaging and accessories. We will not accept any items with obvious signs of additional wear and tear or internal component alterations. All of our items will ship with “Warranty Void” tamper resistant stickers. If any stickers have been removed or tampered with your refund will be canceled. Please include your RMA # on the packing slip, way bill, or package. *CUSTOMER RESPONSIBLE FOR ANY AND ALL RETURN SHIPPING COSTS* Payment Options Domestic Buyers - PayPal, Wire Transfer, Money Order, Company, Bank, or Personal Check. International Buyers: PayPal or Wire transfer only. All funds must be in US Dollars. Unsecured funds must clear prior to shipment. Wire Transfers subject to a $25 service fee. Shipping Unless noted otherwise, all shipments are done through FedEx. If you would like to utilize your ownshipping account please notify us PRIOR to checkout. Saturday and Residential delivery may be available at an additional third party charge depending on the shipping method you choose. We offer shipping outside of the United States. However, some international laws prohibit us from shipping certain items to certain countries. Additionally, not all countries are supported by our service provider. You may also elect to use your own carrier, but we'll be responsible for providing the correct documentation and scheduling the pickup. We are not set up to ship via USPS, and we will NOT falsify any import documents for international orders - no exceptions. Please note: In all sales where an item is prohibited to ship internationally to a successful buyer, that buyer will be notified of non-shipment and a full refund will be made. We reserve the right not to ship any item internationally that is controlled by the US Department of Commerce’s laws and regulations and deemed non-shippable to that region of the world or to listed individuals. eBay's International Shipping calculations do not include any additional duties, fees, or VAT that may be associated with importing this item into a foreign country - please bid accordingly Sales Tax California residents will be charged sales tax if no resale or tax exempt form is submitted prior to payment. TRIED, TESTED...ACCEPTED.

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Equipment has been tested and is fully functional with a 30-day Warranty”
