Cannon Military Connector,plug Ms3116f18-11s Nsn 5935-00-013-9392

US $180

Brentwood, New York, United States
Oct 22nd

Open on mobile:
QR code

CANNON MILITARY CONNECTOR,PLUG MS3116F18-11S NSN 5935-00-013-9392 LOCKHEED MARTIN P/N 6094269NOS CONDITION. 14 DAY WARRANTY FOR COMPLETE REFUND Name Value III BODY STYLE STRAIGHT SHAPE, INTERNAL COUPLING W/STRAIN RELIEF BODY LENGTH 1.969 INCHES MAXIMUM OVERALL DIAMETER 1.391 INCHES MAXIMUM ENVIRONMENTAL PROTECTION MOISTURE RESISTANT AND SALT WATER RESISTANT AND VIBRATION RESISTANT CABLE ENTRANCE DIAMETER 0.734 INCHES MAXIMUM MATING END QUANTITY 1 CONTACT POSITION ARRANGEMENT STYLE 18-11 SINGLE MATING END CONTACT REMOVABILITY NONREMOVABLE SINGLE MATING END SINGLE CONTACT GROUPING CONTACT MAXIMUM AC VOLTAGE RATING IN VOLTS 1000.0 SINGLE MATING END SINGLE CONTACT GROUPING POLARIZATION METHOD KEY, MULTIPLE KEY GROOVE INSERT POSITION IN DEG 0.0 SHELL TYPE SOLID CONNECTOR LOCKING METHOD BAYONET LATCH CONNECTOR CABLE STRAIN RELIEF METHOD CABLE CLAMP TERMINAL LOCATION BACK SINGLE MATING END SINGLE CONTACT GROUPING CONTACT SURFACE TREATMENT GOLD SINGLE MATING END SINGLE CONTACT GROUPING AND NICKEL SINGLE MATING END SINGLE CONTACT GROUPING CONTACT SURFACE TREATMENT DOCUMENT AND CLASSIFICATION MIL-G-45204,TY 1,CL 1,GRADE C MIL SPEC 1ST TREATMENT RESPONSE SINGLE MATING END SINGLE CONTACT GROUPING AND QQ-N-290,GRADE E FED SPEC 2ND TREATMENT RESPONSE SINGLE MATING END SINGLE CONTACT GROUPING TERMINAL TYPE SOLDER WELL SINGLE MATING END SINGLE CONTACT GROUPING SHELL MATERIAL ALUMINUM ALLOY SHELL SURFACE TREATMENT CADMIUM AND CHROMATE SHELL SURFACE TREATMENT DOCUMENT AND CLASSIFICATION QQ-P-416,TY 2,CL 3 FED SPEC ALL TREATMENT RESPONSES INCLUDED CONTACT QUANTITY 11 SINGLE MATING END SINGLE CONTACT GROUPING INCLUDED CONTACT TYPE ROUND SOCKET SINGLE MATING END SINGLE CONTACT GROUPING PRECIOUS MATERIAL AND LOCATION CONTACT SURFACES GOLD III PRECIOUS MATERIAL AND WEIGHT 0.011 GOLD GRAINS, TROY PRECIOUS MATERIAL GOLD TEST DATA DOCUMENT 81349-MIL-C-26482 SPECIFICATION (INCLUDES ENGINEERING TYPE BULLETINS, BROCHURES,ETC., THAT REFLECT SPECIFICATION TYPE DATA IN SPECIFICATION FORMAT; EXCLUDES COMMERCIAL CATALOGS, INDUSTRY DIRECTORIES, AND SIMILAR TRADE PUBLICATIONS, REFLECTING GENERAL TYPE DATA ON CERTAIN ENVIRONMENTAL AND PERFORMANCE REQUIREMENTS AND TEST CONDITIONS THAT ARE SHOWN AS "TYPICAL", "AVERAGE", "NOMINAL", ETC.). SPECIFICATION/STANDARD DATA 96906-MS3116 GOVERNMENT STANDARD STYLE DESIGNATOR 17A SPLIT
