Carroll & Meynell 3300/2 Twin Outlet Transformer 3.3 Kva C/m33002

US $250

Portland, Oregon, United States
Jun 9th

Open on mobile:
QR code

Carroll & Meynell 3300/2 Twin Outlet Transformer 3.3 Kva C/M33002 Carroll & Meynell transformers are primarily for use when using portable electric tools on outdoor sites. They are manufactured to BS EN61558 and have thermal overload protection and withBS EN60309 output sockets as standard. They have a glass reinforced polyester case andinput flex and 13 amp plug. The 5Kva model is without a fitted plug, max input current 23amp. TheCarroll & Meynell transformers are completely encapsulated for extra weatherproofing . These transformers are rated for intermittent operation at their maximum listed power capability for a duty cycle of 25%. I.e. 5 minutes ON 15 minutes OFF. They may be used in a continuous operation mode at a rating of 50% of their maximum capability. E.g. a 3.3Kva unit may be operated continuously at 1.65Kva Tool Rating 3.3Kva Output Sockets. 2 x 16amp. Transformer Specifications Input 240 volts 50Hz single phase. Complete with 2 metres of 3-core flexible cable to BS6500 for connection to mains supply and a 13 amp plug. Output 110 volts. Centre tapped and earth screen between primary and secondary windings which is bonded to the centre tap of the secondary winding, the earth pin on each output socket and earth core of the mains input plugs and sockets. BS4343 flush type sockets with spring flap covers fitted as standard. Units are protected by suitably rated thermal overload cut-outs. Portable Tool Transformer – Safety Instructions 1. The transformer will get warm in normal use, make sure that the heat will not damage any floor covering that it is standing on. It is not advisable to place the transformer onto carpet, vinyl floor covering, etc., and use at continuous rating for any length of time. 4. Although the transformer may be of insulated construction, it is not double insulated (class 2) and the earth pin of the output socket must be connected to the center Product code CM3300/200/PT/C&M Input Voltage 230V Output Voltage 110V CTE Intermittent Rating 3.3kva Continuous Rating 1.65kVA Input Connection Input plug, 13A UK domestic (BS1363) Output Connection 2 No. 16A IEC 60309 (BS4343) Sockets Dimensions (mm) w205 x d195 x h265 Protection Thermal Cut Out

“no box”

Brand	Carroll & Meynell
MPN	Does Not Apply
Model	C/M33002
Country/Region of Manufacture	United Kingdom
