Clear-com Plpro Mr-202 | 2 Channel Flush Mount Headset Station | !free Shipping!

US $1000

Dallas, Texas, United States
May 25th

Open on mobile:
QR code

This Clear-Com PL pro MR-202 was removed from a full functioning system as part of an upgrade. Though the equipment was tested and functioning, it is surplus, so no returns are accepted. Comes as-shown, and as-is. Thank you. --- The following is provided for information purposes, and not necessarily a guarantee of what is included in purchase. ---Wall-Mount Remote Intercom Stations MR-202 FEATURES • Selectable two- or four-channel, full-duplex communication • Microprocessor controlled logic and switching • Momentary/latching talk switch with LED • Visual call signaling with bright LED indicator • Headset connector with volume control and sidetone adjust • Use with optional TW or 4-wire circuit boards • Easy installation and connection DESCRIPTION The MR-202 is a two-channel-selectable, full-duplex headset station, able to be mounted into a wall or other surface. The MR-204 is identical, but can access four channels of intercom. These headset stations are ideal for installation in theatrical, performance, broadcast, and industrial facilities – wherever a multi-channel, full-duplex headset communications panel is desired. Both units mount in a standard U.S. two-gang outlet box. The stations offer excellent speech intelligibility even in high noise environments. Microprocessor-controlled logic plus a set of internal and external controls allow the features of these stations to be tailored to the needs of the user. Electronic switching for the talk button, with mic-on LED indicator, permits momentary or latching operation. A remote mic kill (RMK) signal on the intercom line will turn off the talk function if it is accidentally left on. A bright call-signal LED tracks the incoming call signal, so it can be used for visual cueing. An associated call button allows the user to place a call signal on the selected intercom line. The standard 4-pin XLR headset jack accommodates Clear-Com and compatible dynamic headsets. A sidetone level control adjusts the amount of the user’s voice heard in the headset. An automatic limiter circuit adjusts and limits the microphone output to the intercom line. A two-position switch on the MR-202, and a four-position switch on the MR-204, allow the user to select from the attached intercom channels. Connections to the intercom lines are made via a screw-terminal block, using standard two-wire shielded mic cable. Either of the stations may be used with the optional TW (two channels on a single mic cable) daughter board. With the TW board, the stations become plug-in compatible with a Clear-Com TW system. The MR-202 may be used with the optional 4-wire board, which creates separate send and receive circuits so that the station may be attached to fiber-optic lines or other audio routing systems with 4-wire connections. The MR-202 and MR-204 are housed in a durable package with a 5/32" aluminum front panel. SPECIFICATIONS HEADSET MICROPHONE PREAMP Input Type: Dynamic Impedance: 1,000 Ohms Input Level: -55 dBV nominal; -10 dBV max. Gain from headset mic to intercom line: +41 dB PRE-AMP RESPONSE CURVE Frequency Response: 250 Hz - 12 kHz, contoured for intelligibility Limiter Range: 20 dB HEADPHONE AMPLIFIER Load Impedance Range: 50 - 2,000 Ohms Output Level: +20 dBV across 600 Ohms, minimum Distortion: < 0.2% THD @ 1 KHz Frequency Response: 200 Hz - 15 KHz, +/-3 dB Gain from intercom line: +37 dB POWER REQUIREMENTS Voltage: 30 volts DC for standard unit; 16 - 18 VAC with 4-Wire Option Module Current: 30 mA, average INTERNAL CONNECTORS Intercom: 5-position plug-on screw terminals AC Power (4-Wire Option Module): 2-position plug-on screw terminals INTERNAL CONTROLS (2) Option jumpers FRONT PANEL CONNECTORS Headset: (1) XLR-4M FRONT PANEL CONTROLS & INDICATORS (1) Intercom volume control (1) Sidetone Null control (1) Talk button (1) Call button (1) Channel selector (1) Talk LED (1) Call LED ENVIRONMENTAL 32 - 122o F (0 - 50o C) DIMENSIONS 4.625" W x 4.5" H x 1.75" D 117 mm x 114 mm x 44 mm WEIGHT 0.52 lbs. (0.23 kg)
