Closed Loop Stepper Drive Hbs86 Nema23 Motor 24-70v 8a Leadshine Dhl Free Ship

US $120.00

shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

DSP Closed Loop stepper drive NEMA23 NEMA24 NEMA34 motor Hybrid servo HBS806 Update HBS86 24-70VDC 8A Leadshine New HBS806 HBS806 Lemire company is based on ten years of research and development experience stepper and servo, the successful development of innovative simple servo drive products. Dedicated motor control using the latest DSP chip and vector closed-loop control technology, completely overcome the open loop stepper motor lost step problems, while significantly improved motor speed performance, reduce fever and reduce motor vibration motor, improve the speed and precision machining, reduce machine energy consumption. When the motor continuous overload, the drive will output an alarm signal in time, with the same reliability and AC servo system. HBS806 adaptive motor mounting dimensions are fully compatible 57/60/86 series stepper motors, stepper drives programs to facilitate upgrading of traditional cost equivalent to only half of the AC servo system. Features Be simple servo motor drive Lemire supporting 57,60,86 machine seat Voltage input range: 18 ~ 80 VDC Maximum peak current: 8A Subdivision range: 200 ~ 51200ppr Signal Input: Differential / Single-Ended, pulse / direction or double pulse, the signal level 5 ~ 24V compatible Optically isolated inputs, strong anti-jamming capability Impulse Response Frequency: 200KHz Serial communication function, current, breakdown can be adjusted, signal edge, adjustable alarm output logic functions Closed-loop vector control, ensure the motor speed high torque output, while ensuring that the motor is not lost step Variable current control, motor heating greatly reduced Ultra low noise and vibration Overvoltage, overcurrent, tracking error ultra poor protection Specifications model Number of phase Peak current (A) Working voltage (V) Adaptation motor Weight (kg) Overall dimensions (mm) Control signal HBS507 three-phase 7 18 to 50 DC 57 0.28 116 * 69.2 * 26.5 The differential/single-ended HBS806 Two phase 8 18-80. DC 57,60,86 0.57 151 * 97 * 52 The differential/single-ended HBS806ac Two phase 8 24-75 - AC 86 0.60 151 * 97 * 52 The differential/single-ended HBS758ac Two phase 8 50-80. AC 86 1.20 158 * 130 * 54 The differential/single-ended HBS1108ac Two phase 8 90-90. AC 86 1.60 180 * 140 * 70 The differential/single-ended HBS2206ac three-phase 6 150-150. AC 86110 1.80 180 * 140 * 70 The differential/single-ended Electrical indicators And the number HBS806 The minimum value Typical values The maximum unit The largest peakcurrent - - 8 A The input power supply voltage 18 70 80 Vdc Logic input current 7 10 16 mA Pulse frequency - 200 - kHz Insulation resistance 500 M omega. Applications For a variety of small and medium sized automation equipment and instruments, such as: engraving machine, stripping machine, marking machine, cutting machine, laser machines, plotters, medical equipment, machine tools, automatic assembly equipment, electronic processing equipment. In user expectations low noise, high speed device applications particularly good effect.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Leadshine
MPN	HBS86
Model	HBS86
