Cnc 400w Brushless Spindle Motor Er11 & Mach3 Pwm Speed Controller & Mount + Ps

US $2800

Guangzhou , China
Jan 30th

Open on mobile:
QR code

CNC 400W Brushless Spindle Motor ER11 & Mach3 PWM speed controller & Mount + PS 1.Work voltage: 48VDC 2.Rotation speed: 12000r/min 3.Power: 400W(pick power:500W) 4.Torque:530mN.m 5.Insulation resistance:>2Megohm 6.Dielectric strength:400V 7.Diameter:57mm 8.Axis collet Length: 43mm 9.Diameter of Axis collect holder:16mm 10.Repeat accuracy: 0.01-0.03mm 11.ER11 collect: 3.175mm 12.Net weight:1.1KG Brushless DC speed driver controller: 1.Working voltage: DC12-52V 2.Drive current: Rated current 10A, Peak current 15A. 3.the drive power: ≤ 500w (up to working voltage) 4.Speed/Current alike close loop technology, smooth rotation 5.Pure hardware design, high-speed, high noise immunity 6.Speed regulation: external potentiometer adjust, 0-5V analog voltage , PWM speed control (MACH3 control) 7.F/R(forward / reverse control) Rotation, soft shift function 8.Over current, short circuit protection (red LED indicator) 9.EN( enable control) function DC + DC- DC voltage input DC12-52V U V W motor phase HALL + Hall positive power supply HALL- Hall negative power HA HB HC Hall signal line +5 V +5 V power supply control signal VR speed control signal input terminal GND common control signal power ground F / R forward / reverse control signal terminal PWM PWM frequency (MACH3) EN Enable control input Function description: Speed regulation choice 1, Potentiometer speed regulation: You can control speed directly through potentiometer ) 2, Analog control:VR connect to voltage signal input.GND connect to ground (voltage range of 0-5V) (Notice. When you use external PWM signal speed control, you must be remove the potentiometer control. Otherwise, it will not working) 3. PWM signal control: you can input an external PWM signal to speed control. it requires external PWM: level 3.5-12V VPP, frequency 1K-10KHZ, which suitable for MACH3 spindle speed control.(Notice: external PWM signal control necessary to remove the potentiometer , or it can not control). Motor Run/Stop(ENBL): EN terminal is applied to control motor Run / Stop. Motor is running When EN is floating. Motor stop running when EN connect to GND terminal. Motor forward / reverse control (F / R) : F/R terminal is applied to control motor rotate direction. motor run clockwise when F/R is connecting +5V,otherwise motor will reverse. Power supply Specification 480W(enough power for motor): 1.Input:AC110V/AC220V±10% 50/60Hz 2.Output: DC48V 10A 3. Power:480W 4.Dimension: L130mm * W98mm * H38mm Package Content: •1 * 400W spindle motor with with ER11 3.175 collet •1 * Mach3 PWM speed controller(BLDC brushless motor driver controller) •1 * Mount bracket with screws •1 * Power supply 48V10A
