Cnc Nema Stepper Motor Driver Controller 2m420 2.1a

US $42.49

Shanghai, China
Jan 29th

Open on mobile:
QR code

SKU:*flz-120514-011 2M420 is a cost effective, high performance bi-polar two phase micro-stepping drive applying pure-sinusoidal current control technique. It is best suited for the applications that desired extreme low noise and heat. It operates well in an environment, where electricity supply experience instability and fluctuation. The general pseudo-sinusoidal current control technology adopted by majority of the drive produced distorted sine wave, and current ripple, resulting in vibration, noise and motor heating. This results in motor degrading over time, reducing in motor performance and shortens the usage life. With an automatic optimization speed control technique, the PowerStep series drive output is very stable, with almost zero vibration and noise, performing close to a servo system, allowing the motor to operate smoothly. That helps to fulfill a design requirement of low noise, low heat and high performance. Features H-Bridge, 2 Phase Bi-polar Micro-stepping Drive Suitable for 2-phase, 4, 6 and 8 leads step motors, with Nema size 17 Output current selectable from 0.9 ~ 3.0A peak Current reduction by 50% automatically, when motor standstill mode is enabled Pulse Input frequency up to 200 kHz Optically isolated differential TTL inputs for Pulse, Direction and Enable signal inputs Selectable resolutions up to 25000 steps Over Voltage, Coil to Coil and Coil to Ground short circuit protection. Specifications: Parameters Min Typical Max Unit Output Current (Peak) 0.9 - 3.0 Amps Supply voltage 20 40 VDC Logic Input Current 7 10 16 mA Pulse input frequency 0 - 200 KHz Low Level Time 2.5 ?sec Cooling Natural Cooling or Forced Convection Environment Space Avoid dust, oil frost and corrosive gases Ambient Temperature 0°C-50°C Humidity 40-80%RH Vibration 5.9m/s? Max Storage Temp. -10°C -80°C Weight Approx150 gram Current Settings: Current Setting (A) SW1 SW2 SW3 0.9 ON ON ON 1.2 OFF ON ON 1.5 ON OFF ON 1.8 OFF OFF ON 2.1 ON ON OFF 2.4 OFF ON OFF 2.7 ON OFF OFF 3.0 OFF OFF OFF Microstep Settings: Step / Rev SW5 SW6 SW7 SW8 400 OFF ON ON ON 800 ON OFF ON ON 1600 OFF OFF ON ON 3200 ON ON OFF ON 6400 OFF ON OFF ON 12800 ON OFF OFF ON 25600 OFF OFF OFF ON 1000 ON ON ON OFF 2000 OFF ON ON OFF 4000 ON OFF ON OFF 5000 OFF OFF ON OFF 8000 ON ON OFF OFF 10000 OFF ON OFF OFF 20000 ON OFF OFF OFF 25000 OFF OFF OFF OFF SW4: ON=Full current, SW4 : OFF=Half current Please refer to pictures for P1 Pin Assignment, P2 Pin Assignment, Wiring and Dimensions.
