Cnc Stepper Motor Driver 50v /4a / 128 Microstep Stepper Motor Driver

US $29.99

???, ???, China
Jan 29th

Open on mobile:
QR code

Package include: 1 x FMD2740A stepper motor driver English user manual for breakout board and stepper motor driver will send by email. FMD2740A stepper motor driver FMD2740A stepper motor driver 1,Brief introduction FMD2740A FMD2740A driven by Japanese sanyo's chip,After multiple optimize R & D and production of high-subdivision 2-phase stepper motor drives, suitable for driving small and medium-sized phase current is less than 4A 2-phase or 4-phase hybrid stepping motor. Due to the adoption of the new bipolar constant current chopper drive technology, using the same motor can output more speed and power than other drivers. Segments stepper motor running accuracy improved, reduces vibrations and noise reduction. 2,Features 1. High-performance, low price 2. Bipolar constant current chopping mode 3. Power supply voltage 12 to 50VDC 4. High-speed optocoupler signal isolation input 5. 20kHz chopping frequency 6. Subdivision precision 2\8\16\32\64\128\10\20 optional 7. Electrical input signal is TTL compatible 8. Stationary current is automatically reduced by half 9. Shape design is convenient for installation 10.Maximum drive current is 4A 11.Drive any 4A phase current of 2-phase or 4-phase hybrid stepping motor 3,Applications Suitable for a variety of small and medium-sized automation equipment and instruments,for example: Small engraving machine, SMT machine, etc. 4,wiring defined Weak signal interface Signal Function SP+ Pulse signal + end SP- Pulse signal - end DIR+ Direction signal +end DIR- Direction signal-end EN+ Enable signal +end EN- Enable signal -end Strengths connection port Signal Function VIN+ 12to50 v dc power supply input +end,it is recommended to use 36V3A GND DC power supply connection ground A+ Stepper motor A + Phase terminal A- Stepper motor A - Phase terminal B+ Stepper motor B+ Phase terminal B- Stepper motor B - Phase terminal NOTE: This drive does not contain anti-anti-interpolation circuit so non-input positive and negative power supply upside down! Otherwise it will damage the drive! 5,The electrical characteristics 6,The use of the environment and parameters Cooling method Natural cooling or forced air cooling Use of the environment Occasions Avoid dust, oil mist and corrosive gases Temperature 0°C-+50°C Humidity 40-90%RH Vibration 6m/s2 MAX Storage temperature -20°C-+65°C Weight 250g 7,Mechanical installation size 8, Power supply The supply voltage can work normally in between DC12V-50V, FMD2740A driver can use ordinary switch DC power supply, can also be used for transformer and the bridge rectifier and filter capacitor, capacitance desirable 2000U to 5000U. Note rectified voltage ripple crest does not exceed 50V.Recommended the user to use the 24V-32V DC supply , avoid the grid fluctuations over drive voltage operating range. Note: 1, Wiring should pay attention to the power of positive and negative Do not be reversed; 2, In order to reduce costs, multiple drives can share a power supply. But it should improve the rated power and rated output current of the power and attention to cooling. 9,Attenuation of the DIP switch settings Decay mode SW1 SW2 Slow decay OFF OFF Mixed decay ON OFF Fast decay OFF ON 10,Subdivision DIP switch settings 11,Current DIP switch settings 12,Drive motor controller wiring diagram 13,Electrical wiring The FMD2740A driver can drive all current 4A 4-wire, 6-wire or 8-wire 2-phase / 4-phase motors, are detailed below 4-wire, 6-wire, 8 wire stepper motor connection: 14,Matching of the drive and motor FMD2740A driver can drive the domestic and foreign manufacturers of 2-phase or 4-phase motor, in order to obtain the most satisfactory driving, you need to choose a reasonable supply voltage and current setting. Supply voltage determines the level of the high-speed performance of the motor, and the current set value determines the output torque of the motor. Supply voltage selected Generally speaking, the higher the supply voltage, the greater the torque motor at high speed, the more it can avoid the high speed out. But another aspect, the voltage is too high will lead to over-voltage protection, and can even damage the drive, but also in the high-pressure work, low speed vibrations. The output current is set For the same motor, the greater the current setting, the higher speed, the current motor and drive more heat. So under normal circumstances the current setting into a powered machine warm but not too hot long-term value. Note: the current settings after you run the motor for 15-30 minutes, if the motor temperature is too high, you should reduce the current settings. If the motor current setting, the motor output torque is not enough to improve heat dissipation conditions to ensure that the motor and drive are not hot. Shipping Please open the package and check if there are some damages before sign, if there are some damages , please do not sign and contact us immediately We ship to USA,United Kingdom,Canada,Australia,New Zealand,Belgium,Netherlands,Luxembourg,Italy,Germany,France,San Marino,Austria,Denmark,Finland,Greece,Ireland,Guernsey Island, Jersey Island,Norway, Portugal,Spain,Sweden,Switzerland,Poland,Bulgaria,Slovenia,Slovakia,Czech Republic,Hungary,Roumania,Lithuania,Hongkong,Taiwan,Janpa,Korea,Singapore,Tailand, Malaysia,Philippines, Indonesia,if your country not in this range please contact us before you bid to check detail and confirmed for the shipping cost! Delievry time( Airmail Packets) USA round 7-10 business days UK,Candana,Australia,New Zealand,Asia 15-25 business days EU(Germany,France,Spain,etc) 15-25 business days South America,other countries 20-35 business days DHL 5-8 business days EMS 4-10 business days When weight less than 2kgs,we usually ship by post air mail which will take round 10-15 business days. some areas may be later due to variation of postal service in different areas,if above 2kgs we can ship by DHL/UPS/EMS which need confirm by us All items will be shipped within 1-3 business days upon receipt of payment Payment We only accept paypal payment,all Paypal must be confirmed(shipping and billing address must match and correct) Payment must be made within 48hours of the auction end time Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer responsibility. Problem&Feedback Please give us the opportunityto resolve any problem when you have,we concern your problem and we will try our best to resolve it. We are a new member in ebay now,and need understand both of sides Pls email us before you want to leave any negative feedback Refund When you have the parcel,and not satisfied the goods or it is other problem like as broken,pls tell us the detail reason and provide the photos Any reason refund:10% restocking fee required for all refund. Item must be in it's original condition and no physical damage. Buyer responsible for all shipping cost Contact us Email:sale1@rattmotor.com ;TradeManager:ali900111342 Welcome worldwide customer inquire and questions,we will try to do our best to feedback customer’s email within 1-2 business days,if not pls check the mail box again Customer’s satisfaction is very important to us.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	RATTM MOTOR
Country of Manufacture	China
Model	FMD2740A
Driver current	4A
MPN	http://hgauto.en.alibaba.com/
Driver input voltage	12-50V
Country/Region of Manufacture	China
Driver microstep	128 microstep
