CONNOR WINFIELD Crystal Oscillator 20.48MHz SMD 8-Pin DIP HCMOS *NEW* 5/PKG, US $3.99 – Picture 0
CONNOR WINFIELD Crystal Oscillator 20.48MHz SMD 8-Pin DIP HCMOS *NEW* 5/PKG, US $3.99 – Picture 1
CONNOR WINFIELD Crystal Oscillator 20.48MHz SMD 8-Pin DIP HCMOS *NEW* 5/PKG, US $3.99 – Picture 2
CONNOR WINFIELD Crystal Oscillator 20.48MHz SMD 8-Pin DIP HCMOS *NEW* 5/PKG, US $3.99 – Picture 0
CONNOR WINFIELD Crystal Oscillator 20.48MHz SMD 8-Pin DIP HCMOS *NEW* 5/PKG, US $3.99 – Picture 1
CONNOR WINFIELD Crystal Oscillator 20.48MHz SMD 8-Pin DIP HCMOS *NEW* 5/PKG, US $3.99 – Picture 2

Connor Winfield Crystal Oscillator 20.48mhz Smd 8-pin Dip Hcmos *new* 5/pkg

US $3.99

  • Edinburg, Texas, United States
  • Jan 29th
Open on mobile:
QR code
 *** NEW & ORIGINAL ***  5/PKG Part #: JH56R-1MHZ Category: Oscillators Manufacturer: Connor-Winfield Corporation (The) Description: CRYSTAL OSCILLATOR, CLOCK, 20.48MHz, HCMOS/TTL OUTPUT     SPECIFICATIONS: Mfr Package Description HERMETIC SEALED, METAL, WELDED, DIP-8/4 Status ACTIVE Operating Temperature-Max 70 Cel Operating Temperature-Min 0.0 Cel Mounting Feature SURFACE MOUNT Physical Dimension L12.7XB12.7XH5.08 (mm)/L0.5XB0.5XH0.2 (inch) Supply Voltage-Max 5.25 V Supply Voltage-Min 4.75 V Supply Voltage-Nom 5 V Fall Time-Max 5 ns Frequency Adjustment-Mechanical 0 Manufacturer Series JH56R Operating Frequency-Nom 20.48 MHz Oscillator Type HCMOS/TTL Output Load 10 TTL, 50 pF Rise Time-Max 5 ns Symmetry-Max 0.8182 %
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Connor Winfield
MPN JH56R-20.48MHz
