Crydom Solid State Relay Model D2425

US $150

Henderson, Nevada, United States
Jan 29th

Open on mobile:
QR code

Model: D2425 Item specifications: Brand Crydom Model D2425 Control Voltage Range 3 VDC to 32 VDC Load Voltage Rating 24 VAC to 280 VAC Load Current Rating 25 A Input Current 3.4 mA Output Device SCR Mounting Style Panel Product Type Industrial Mount Series Series 1 Termination Style Screw Manufacturer specs: Series 1 240 VAC • Crydom's signature family of solid-state relays. Ratings from 10A to 125A @ 24-280 VAC • SCR output for heavy industrial loads • AC or DC control • Zero-crossing (resistive loads) or random-fire (inductive loads) output • UL/CSA/VDE Approved, CE Compliant to EN60950-1 PRODUCT SELECTION Control Voltage 10A 25A 50A 75A 90A 110A 125A 3-32 VDC D2410 D2425 D2450 D2475 D2490 D21110 D24125 90-280 VAC A2410 A2425 A2450 A2475 A2490 A24110 A24125 18-36 VAC A2410E A2425E A2450E A2475E A2490E A24110E A24125E AVAILABLE OPTIONS OUTPUT SPECIFICATIONS (1) Description 10A 25A 50A 75A 90A 110A 125A Operating Voltage (47-63Hz) [Vrms] 24-280 24-280 24-280 24-280 24-280 24-280 24-280 Transient Overvoltage [Vpk] 600 600 600 600 600 600 600 Maximum Off-State Leakage Current @ Rated Voltage [mArms] 10 10 10 10 10 10 10 Minimum Off-State dv/dt @ Maximum Rated Voltage [V/?sec] (2) 500 500 500 500 500 500 500 Maximum Load Current (3) [Arms] 10 25 50 75 90 110 125 Minimum Load Current [mArms] 40 40 40 40 40 150 150 Maximum 1 Cycle Surge Current (60Hz) [Apk] 120 250 625 1000 1200 1500 1750 Maximum 1 Cycle Surge Current (50Hz) [Apk] 115 239 597 954 1145 1432 1670 Maximum On-State Voltage Drop @ Rated Current [Vpk] 1.6 1.6 1.6 1.6 1.6 1.7 1.7 Thermal Resistance Junction to Case (Rjc) [°C/W] 1.48 1.02 0.63 0.31 0.28 0.25 0.22 Maximum 1/2 Cycle I? t for Fusing (60Hz) [A2 sec] 60 259 1621 4150 5976 9338 12709 Maximum 1/2 Cycle I? t for Fusing (50Hz) [A2 sec] 66 285 1779 4555 6560 10249 13950 Minimum Power Factor (with Maximum Load) 0.5 0.5 0.5 0.5 0.5 0.5 0.5 onlinecomponents.com INPUT SPECIFICATIONS (1) Description ( D PREFIX) ( A PREFIX) ( E SUFFIX) Control Voltage Range 3-32 VDC 90-280 Vrms 18-36 Vrms Maximum Reverse Voltage -32 - - Maximum Turn-On Voltage 3.0 VDC (5) 90 Vrms 18 Vrms Minimum Turn-Off Voltage 1.0 VDC 10 Vrms 4.0 Vrms Typical Input Current 3.4-20 mA 2.0-4.0 mA 3 mA Nominal Input Impedance [Ohms] 1500 Ohm 60 K Ohm 9.0 K Ohm Maximum Turn-On Time [msec] (4) 1/2 Cycle 10 10 Maximum Turn-Off Time [msec] 1/2 Cycle 40 40 GENERAL SPECIFICATIONS Description Parameters Dielectric Strength, Input/Output/Base (50/60Hz) 4000 Vrms Minimum Insulation Resistance (@ 500 V DC) 109 Ohm Maximum Capacitance, Input/Output 8 pF Ambient Operating Temperature Range -40 to 80 °C Ambient Storage Temperature Range -40 to 125 °C Weight (typical) 3 oz (86.5g) Encapsulation Thermally conductive Epoxy Terminals Screw and saddle Clamps Furnished, mounted Recommended Terminal Screw Torque Range: 6-32 Screws - 10 in/lbs. 8-32 & 10-32 Screws - 20 in. lbs. Fastons: Single pair (up to 25A) Double pair* (50A model only) *Caution: User must connect to both pairs GENERAL NOTES 1) All parameters at 25°C unless otherwise specified. 2) Off-State dv/dt test method per EIA/NARM standard RS-443, paragraph 13.11.1 3) Heat sinking required, for derating curves see page 3. 4) Turn-on time for Random turn-on versions is 0.02 msec (DC Control Models) 5) For relays with option ”G” minimum control voltage is 4.5VDC onlinecomponents.com WIRING DIAGRAM MECHANICAL SPECIFICATIONS onlinecomponents.com THERMAL DERATE INFORMATION AGENCY APPROVALS EN60950 : Meets the requirements of sections1.5: 1,7: 2.9: 2.10.5.3: 4.2: 4.5: 4.7: E116949 LR81689 10143 UG (Not Applicable: -B and 4D) Rev. 062211 onlinecomponents.com

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	CRYDOM
Model	D2425
