Cummins Onan, 3.2 Hdzaa-6508a, Rv Diesel Generator 120v / 60hz

US $6,468.00

Minneapolis, Minnesota, United States
Jan 30th

Open on mobile:
QR code

Features and benefits Weight, size and sound level • Computer-controlled constant speed operation - quiet diesel performance for smaller RVs. • Special sound-controlling housing encloses cooling system and muffler. • Double isolation mounting system reduces vibration. • Easy, accessible maintenance points. • Runs one rooftop air conditioner with power to spare. • Integrated start/stop control with hour meter. Weight, size and sound level Weight 205 lb (93 kg) Length 30.2 in (766 mm) Width 17.3 in (439 mm) Height 18 in (453 mm) Sound 68 dB(A) (readings at 10 ft (3 m) half load) - Meets National Park Service sound level requirements (60 dB(A) @ 50 ft) for national park use. - Typical installation will further reduce sound level. Models and ratings Model Fan Hz Watts Voltage Amps Phase Circuit protector 3 .2 HDZAA-6508A Internal 60 3200 120 26.7 1 1 pole, 30 A Ambient conditions for rated power output with muffler and RV enclosure, per ISO 8528-1: - Temperature: 77° F (25° C) - Altitude: 500 ft (152.4 m), (99 kPa dry) Typical power output change based on ambient conditions: - Temperature: Power output decreases 1% for every 10° F (5.5° C) increase - Altitude: Power output decreases 3.5% for every 1000 ft (305 m) increase Ratings represent minimums. Actual performance may be significantly higher based on installation and operating conditions. Standard features • 1 cylinder diesel engine • Permanent magnet alternator • Digital voltage regulation w/no adjustments required • Integral enclosed muffler with stationary exhaust pipe connection point • USDA-approved spark arrestor • Sound insulated cover with cooling air inlet and outlet ducts • Heavy-duty air cleaner • Automotive type starter • Hour meter • Meets applicable U.S. EPA and California emissions standards • Connector for remote operation • Double Isolation mounting system • Terminal block connection for AC output • Electric fuel pump • Fuel filter • Cleanable oil screen filter • Service and maintenance through service doors • Pure Sine Control system Microprocessor control User and service personnel accessible diagnostics Over voltage, over speed and overload safety Low oil pressure safety AC alternator over temp safety Automatic timed glow plugs One touch stop Integrated display with start/stop switches and LCD Engine details Design: 4-cycle, air-cooled diesel engine Cylinders: 1, vertical Bore: 3.15 in (80.0 mm) Stroke: 2.72 in (69 mm) Displacement: 21.16 in3 (347 cm3) Compression ratio: 22 to 1 Lube oil capacity: 1.2 qt (1.1 L) Average fuel consumption: Diesel No load Half load Full load 3.2 HDZAA 0.2 Gal/h (0.7 L/h) 0.3 Gal/h (1.0 L/h) 0.4 Gal/h (1.4 L/h) Alternator details Design: Permanent magnet Brushes: None Exciter system: None Cooling: Direct drive centrifugal blower; cast aluminum housing for excellent heat transfer Generator set performance Voltage regulation no load to full load: ± 8% Frequency regulation no load to full load: ± 0.1% THD: <5% Air conditioner operation: Will operate with one 13500 Btu air conditioner and an additional load up to 1000 W at 100° F and 500 ft (152.4 m) altitude For more information and or full specs call EmPower Generators (954)922-3800 or visit empowergenerators . com

Condition:	New	Country/Region of Manufacture	United States
Part Type	Generators
