Custom Rosette Shaper Router Moulder Cutter Machine Cnc Jig Molding Trim Frame

US $599.00

Mineral Ridge, Ohio, United States
Jan 30th

Open on mobile:
QR code

Here’s a very unique piece. This machine was built exclusively to make custom rosettes – FAST. It is surplus from a custom interior millwork shop that closed. Basically, a Porter Cable 1002 / 22,000 RPM Router is attached to a Thompson Linear Ball Bearing, vertical slide actuated by a Speedaire Air Cylinder to yield a smooth, regulated plunge. The workpiece is held to a 15” dia. rotating turntable with an adjustable, fast acting, clamping jig. The turntable is variable speed and driven by a Dayton Gearmotor and Speed Control. The whole cycle is automatic once the operator presses the “2” cycle start buttons - all motion stops and router returns “up” upon release of buttons. Very nicely made – definitely the work of a machine builder. I know cause I am one. Check out the picture of the “underneath” – The turntable is attached to a 1 1/2 ” dia. vertical shaft supported by two, big, pillow block bearings and driven by the variable speed gearmotor’s pulley at the bottom. The router “slide” assembly is adjustable horizontally to determine diameter of rosette produced and adjustable vertically to control the depth of cut / router plunge. Equipped with safety guards (removed for some pics.) and double operator push button cycle interlock. Tested as pictured You’ll be the only one – with one of these… See this machine in action in this youtube video- http://www.youtube.com/watch?v=NdDdVENy9sc · Porter Cable 1002 / 22,000 RPM Router · 120 Volt, Single Phase + Air Supply · O/A Dims: 24”W.x 56”D.x 72”H. · Net Weight: 300 lbs. (as pictured) Compare at $ MEGA $ to have one of these custom built… Free Loading For Buyer Pick Up! OR $49 for packing machine and on approx. 42”x 60” pallet at approx. 400 lbs. for pick-up by buyer’s common carrier from zip 44440 We do not arrange for common carrier shipping directly. I refer buyers to “Felix”(ext.#213) at Small Business Transport (888) 368-6022 or “Kam” (ext.# 727) at Freight Guru (877) 937-3734 for competitive motor freight rates. Give them our listed pallet size & weight (from our ad) & your zip & our (44440) zip code and they can advise their best deal. Many Thanks, Lloyd If you have any questions or want more pictures or information please call us at (330) 652-7535.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Model	Wood Rosette Maker
MPN	Oliver DeWalt Milwaukee Porter Cable Delta Rockwel
Brand	Oliver DeWalt Milwaukee Porter Cable Delta Rockwel
