Content on this page requires a newer version of Adobe Flash Player. The Following Items Are Included: CXR Telecom Halcyon 704A-410 Basic Handheld Transmission Set w/ Option: (BC# 25262) Option B: 1.5MHz KHz Frequency Band for ADSL, HDSL, & ISDN Facility Testing (2) Bantam Cables A Adapter/Charger User Manual On CD-ROM Carrying Case (G) BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! CXR Telecom Halcyon 704A-400 Basic Handheld Transmission Set w/ Option B: 1.5MHz KHz Frequency Band for ADSL, HDSL, & ISDN Facility Testing The 704A-400 has 400 KHz range The hand-held 704A-400 Series is the complete test solution for installation and maintenance of analog voice and data circuits. Includes Carrying Case & Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 90 Day Exchange Warranty 704A-400 Basic hand-held transmission set with 400 KHz range CXR Halcyon's 704A-400 Series are hand-held transmission and signalling wideband test sets optimized for installation and maintenance of analog voice and data services including Class Services and circuits utilzing DIDSignaling (E911). When equipped with 400 kHz Option, it is ideally suit- ed for ADSL, HDSL, ISDN and DDS Facility Testing. Designed with state-of-the-art technology and engineered for ease of operation, the 704A-400 Series provides users with single-button test execution allowing quick circuit diag- nosis and repair without extensive training. The internal NiCAD battery pack provides up to 4-hours of continuous operation. The hand-held 704A-400 Series is the complete test solution for installation and maintenance of analog voice and data circuits. Features: Rugged, Lightweight & Hand-Held RJ 11 Modular Jack Dual Mini-Phone Jacks (Bantam) 2-Wire and 4-Wire Interface 135, 600, 900, 1200 Ohm and Bridged Measure Line Voltages and Polarity Monitoring RINGING Voltage Generate and Measure: - Frequency and Level - 3-Tone Slope & 2713Hz Lpbk - Peak to Average Ratio (PAR) Noise Measurements: - Filtered and Notched - Signal to Noise - Impulse Noise Power Influence: - Stress Noise - Noise to Ground Filter Selections: - C-Message, 3 KHz Flat - Program-Weighted - 15 KHz and 50 KHz Specifications: General Physical 9.5”L x 6.33”W x 1.4”H, 2.2 pounds. Operating Environment: 0 to 50 ° C, 0 to 95% R.H. (Non-Condensing). Power 5W at 115VAC, 60 Hz nom. from 9VDC external power supply. Battery 4 hours continuous operation from internal 7.2 VDC NiCad Pack. Charge time: 14 hours. 2W/4W Interface: RJ 11C or Dual Bantam (210) jacks. Impedance 135/600/900, 1200 Ohms Terminated, >30K 2W- Bridged. Longitudinal Balance: >60dB from 200 to 4 KHz. Audio Internal speaker with volume control. Display 4-line by 20-character LCD and status LEDs. Line Hold: Electronic Internal current limited to 24mA when Off Hook. Dial Mode: 16 character DTMF generator. 12 character MF generator, 10 digit dial pulse gen. Generator Frequency 50 Hz to 25 KHz in 1 Hz steps (Optional) 50 Hz to 400 KHz in 1 Hz steps Accuracy + 0.5 Hz Level: +7 to -40 dBm in 0.1 dB steps Accuracy: +0.2 dB 50 Hz - 200 Hz +0.1 dB 200 Hz - 15 KHz +0.2 dB 15 KHz - 400 KHz 3-Tone Slope: 404, 1004, 2804 ± .5 Hz. Level adjustable in 4 steps of 0, -10, -13, and -16 dBm ± 0.2dB. 2713Hz Loopback: Generated at ± 0.5Hz. Level adjustable as in 3 tone slope P/AR: Continuous ANSI 743-1984 P/AR signal at -6dBm Return Loss: Continuous filtered noise signal at -6 ±1dBm for ERL, SRL-L and SRL-H. DTMF Generator: -7±0.2dBm, 1.5dB twist, frequency accurate to ±.5 Hz. 75 mS on 75 mS off. Receiver Level +7 dBm to -70dBm, 0.1 dBm resolution; 135/600/900 ohm 4-Wire mode: 0 dB to -60 dBm; 0.1 dBm re Accuracy: 1200 ohm - 2-Wire mode +0.2 dB - 50 Hz to 200 Hz +0.1 dB 200 Hz to 15 KHz +0.2 dB 15 KHz to 400 KHz (Opt.) Frequency 50 Hz to 25 KHz with 1 Hz res. (Optional 50 Hz to 400 KHz) Accuracy +0.1 dB 50 Hz to 200 Hz +0.1 dB 200 Hz to 15 KHz +0.2 dB 15 KHz to 400 KHz (Opt.) Noise 15 to 95 dBrn with 1 dB resolution and ±1 dB accuracy from 20 to 90 dBrn. Notched Noise: 1010Hz notch, with a minimum of 50 dB attenuation in the band of 995 to 1025 Hz. Signal to Noise Ratio: Holding tone (1004Hz) must be in range of +6 to -45 dB; measured S/N ratio range from 10 to 55 dB with 1 dB resolution and ±2 dB accuracy. 3-Level Impulse Noise: Threshold can be set from 30 to 90dBrn; 3 level differ- ence fixed at 4 dB with a measurement accuracy of +1 dB. Blanking interval fixed at 125mSec; with 3 independent counters. P/AR: Measured from 30 to 180 units with a 1 unit resolution. Accuracy is ±2 units from 40 to 120. Received P/AR signal must be greater than -45 dBm. Return Loss: Three bands: ERL,SRL LO, SRL HI range of 0 to -30dB with .1 dB resolution and ±1 dB accuracy. Line Voltage Measurement: 2 to 85VDC; 0.1 Volt resolution and ±1 Volt accuracy. Line Current Measurement 5 to 35mA; 0.1 mA resolution and ±1 mA accuracy. Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! Contact: Test Equipment Store eBay Sales Phone: 1-419-517-6681 Toll Free : 1-800-548-2381 We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. UPS Ground United States USD 0.00 USPS Express Mail International (EMS) Worldwide USD 0.00 We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Put your auctions on autopilot with Kyozou eBay Auction Tools
