Dayton 1tmv1 Pump, Centrifugal, 5 Hp, 13.7/6.80 Amps

US $800.00

Joliet, Illinois, United States
Jan 30th

Open on mobile:
QR code

Item Description: Pump, Straight Centrifugal, 5 HP, 3 Phase, Voltage 230/460, 13.7/6.80 Amps, 60 Hz, Inlet 2 In., Outlet 1 1/2 In., Motor Enclosure TEFC, Motor RPM 3500, Service Factor 1.0, Impeller Material Stainless Steel, Housing Material Stainless Steel, Seal Type Mechanical, Max. Head 111.0 Ft., Inlet Pressure 100 PSI, Impeller Type Enclosed, Max. Dia. Solids 0.51 In., Length 21.5 In., Width 11.14 In., Height 12 In. High-Volume, Straight Center-Discharge PumpsPumps feature continuous-duty motors with enclosed impellers, 4-position port rotation, replaceable case ring, and easy-access housing drain plugs. 3-phase units do not have overload protection and require a pump control box, sold separately on page 3824. Ideal for OEM equipment, boosting, water transfer, and heating and cooling recirculation. Replacement seals available on Grainger.com®.3450 rpm motors with TEFC motor enclosuresMax. temp.: 180°F (Nos. 4ZA35 to 4ZA48, 1TMU5 to 1TMU9); 200°F (Nos. 4ZA49 to 4ZA58, 1TMV1, 5ULN9 to 5ULP4)Max. case pressure: 100 psiWetted MaterialsStainless SteelStainless steel housing and impeller. Seals are made from Viton®, stainless steel, carbon, and ceramic. Technical Specs ItemPump Housing MaterialStainless Steel HP5 Phase3 Voltage230/460 Amps14.0/7.0 Hz60 Motor EnclosureTEFC NEMA/IEC Frame184JM Motor RPM3500 Motor Type3-Phase Service Factor1.15 Impeller TypeEnclosed Impeller MaterialStainless Steel Volute MaterialStainless Steel Shaft Material410 Stainless Steel Screw MaterialStainless Steel Seal TypeMechanical Seal MaterialCarbon Ceramic, NBR Elastomer, 304 Stainless Steel GPM of Water @ 40 Ft. of Head207 GPM of Water @ 50 Ft. of Head196 GPM of Water @ 60 Ft. of Head183 GPM of Water @ 70 Ft. of Head164 GPM of Water @ 80 Ft. of Head138 GPM of Water @ 90 Ft. of Head105 GPM of Water @ 100 Ft. of Head66 Max. Specific Gravity1.0 Wetted MaterialsSS, Carbon, Ceramic, Buna N Max. Fluid Viscosity100 SSU Bearing TypeDouble Sealed Ball Bearing #1tmv1ofr2fl

Condition	New other (see details) : A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Brand new unit with dents and scratches. Please check picture for dents.”
