Dc 12v Plc Relay Multifunction Self-lock Cycle Timer Module Delay Time Switch Us

US $3.99

ShenZhen, China
May 22nd

Open on mobile:
QR code

DC 12V PLC Relay Multifunction Self-lock Cycle Timer Module Delay Time Switch US Description: User can select from below eight functions, by using the key buttons onboard. User can select and save the set parameters. The set time is 1 second at minimum, and precision is better than 0.1 second. The eight functions are as follows: 1)Close upon the set time: after power one, the delay time T1 reaches, and the relay closes. T1 is adjustable between 0 second to 270 hours. When we feed CH1 a high level pulse signal, the cycle repeats itself (the high level time lasts longer or equal to 20ms. Same applies to below). 2)Disconnect upon the set time: when the relay closes, the delay time T1 reaches, and the relay opens. T1 is adjustable between 0 second to 270 hours. When we feed CH1 a high level pulse signal, the cycle repeats itself. 3)Cycle Mode 1: after power on, the relay does not close at first. When T1 reaches, the relay closes. When T2 reaches, the relay opens. And the cycle goes on. T1 and T2 adjustable between 0 second to 270 hours. When we feed CH1 a high level pulse signal, the cycle repeats itself. 4)Cycle Mode 2: after power on, the relay immediately closes. When T1 reaches, relay opens; when T2 reaches, the relay closes again, and the cycle goes on. When we feed CH1 a high level pulse signal, the cycle repeats itself. 5)Self-lock relay mode: we feed CH1 a high level pulse signal, relay closes. When we again feed a high level pulse signal, the relay opens. 6)Trigger relay mode: we feed CH1 a high level signal, relay closes. When the high level finishes, the relay opens. 7)Limited cycle mode 1: on basis of function 3, we increase the cycles. Under this mode, T1 and T2 are adjustable between 0 second to 9999 second, the cycle is selectable between 1 to 9999 times. 8)Limited cycle mode 2: on basis of function 4, we increase the cycles. Under this mode, T1 and T2 are adjustable between 0 second to 9999 second, the cycle is selectable between 1 to 9999 times. Connections: Module control side: there are 3-wire interface, all interfaces are terminal 1, DC +:12V positive 2, DC-: power in negative 3, CH1: Input Detection Interface Relay outputs: a 3-wire interface, all interfaces are terminal 1, NO: normal open (before relay closes, this pin is not connected. after relay closes, the pin short-connects with COM) 2, COM: Relay Common Interface 3, NC: Normal closed (before relay closes, this pin short-connect with COM. after relay closes, the pin is not connected ) Specification: Size:66x40x1.5mm(approx) Color: as the photos show. Package Included: 1PC*DC 12V PLC Relay Shipping Feedback Payment Return/Refund Shipping We will ship to worldwide by 1) Standard Economy Airmail , or 2) Registered Airmail with Tracking. It takes approximately 18 to 35 working days for delivery (business days – excluding holidays), kindly be patient. If you do not receive your delivery within the specified time frame, please contact us via eBay message for assistance. Kindly ensure that your delivery address in eBay & Paypal are the same to avoid delivery failure. Any non-received item caused by invalid address is not eligible for refund or replacement. Please ensure your purchased item(s) can be lawfully imported into and complies with all laws and regulations of the destination country. IMPORTANT NOTE: Custom duty is obligation and liability. Buyers are responsible for import duties, custom fees and taxes, if any. Kindly check with your country’s custom office to determine the additional costs impose on the item prior to purchase. We are NOT responsible for the additional costs incurred related to import duties, custom fees and taxes. Please leave a note in eBay ONLY if you got special request (e.g. colour). Kindly note that special request is subject to availability; we does NOT guarantee for random ship items. Feedback We will greatly appreciate your positive feedback and all 5-star DSRs. If we have not given you reason enough for 5-star grades on each DSR, please let us know how we can earn your 5 star rating before submitting your scores. Payment We accept PayPal payment only, and must be received within 3 days from the date of purchase. Please leave note in PayPal when making the payment if you have any special requests. Orders will be processed instantly and dispatched within 1-2 days, so we do NOT accept any email/message note after you place orders. IMPORTANT! PLEASE READ! Buyers are responsible for import duties, custom fees and taxes, if any. Please check with your country Return/Refund Kindly examine your parcel upon receiving your purchase and inform us via eBay message of any damage/defects with clear photographs/pictures/videos as proof within the first 24 hours upon receiving your purchase. NO claims will be liable or entertain after this time period. If you are not happy with your purchase for valid reason, you can return the product to us within the first 14 days after receiving the product. All shipping charges (both ways), handling and packaging costs will be charged to the buyer. The product must be sent back to us in original condition with no defect (new, unused and unopened) within first 14 days of receiving the product. No scratches, damages whatsoever & No altering of any part of the item. Original box/documentation/accessories (if any) and packaging. Buyer is responsible for return shipping cost. Please allow up to 5 working days to process your return items.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
Herstellernummer	nicht zutreffend
Type	12V
Herstellungsland und -region	China
MPN	Does Not Apply
Marke	Markenlos
Model	Does not apply
Amount	1PC
Country/Region of Manufacture	China
Number of Items	1
UPC	Does not apply
Marca	- Senza marca/Generico -
EAN	Does not apply
Type.	12V Automation Relay
Module	3-wire
DC +	5V/12V/24V positive
Product Type	electroniccomponents
DC-	power in negative
Manufacturer Part Number	D011324
Select Product	12V
Interface	CH1
Manufacturer	diymore
Anzahl der Einheiten	1pc
ISBN	Does not apply
