Dc Buck Module, Voltage Regulator 6v-32v 30v 24v 12v To 1.5-32v 5v 5a Lcd

US $18.10

Bronx, New York, United States
Aug 27th

Open on mobile:
QR code

DC Buck Module, DROK Adjustable Buck Converter Step Down Voltage Regulator 6V-32V 30V 24V 12V to 1.5-32V 5V 5A LCD Power Supply Volt Reducer Transformer Module Board with USB Port Protective Case PARAMETER --- Input voltage range DC 6V-32V; Output voltage DC 1.5V-32V; Max output current 5A, recommend use of within 4.5A; Max output power 75W, recommend use of within 50W. GENERAL USE --- As ordinary step-down module with over-current protection; As constant current LED driver module; DIY a solar power controller, etc. DISPLAY --- Large clear digital LCD display voltage & current value simultaneously. FEATURES --- Constant current/voltage mode; Voltage calibration & current calibration; USB interface; Protective case; Short-circuit protection; Over-temperature protection; Input reverse connection protection. NOTE --- 1). Output voltage is set as around 20V by default, if your input is lower than that, please turn potentiometer anticlockwise for 10 laps or more until voltage changes. 2). The case is packaged unassembled to avoid damage during transit. It needs to be manually installed. 3). Please carefully read the user’s manual, especially the “Cautions” before using. You can find the PDF Instructions on this page -- Product information -- Product guides and documents -- User Manual [PDF]. Parameters Chip: MP2304 Input voltage: 6~32V Output voltage: 1.5~32V continuously adjustable (Input should be 1.5V higher than output.) Output current: 5A max, adjustable, recommended use within 4.5A. (Over 3A or 35W, please enhance heat dissipation.) Constant current requires an output voltage of above 2V to be adjusted. Current regulation can only be performed in the status of constant current. Output Power: 75W (max), recommended use within 50W. Please reduce the power when voltage difference is large. Operating temperature: -20 to +70 Operating frequency: 180KHz Conversion efficiency: up to 96% Short circuit protection: Yes (Constant current value set by constant current function) Over-temperature protection: Yes (Automatically shut off the output when overtemp.) Input reverse polarity protection: Yes Output backflow prevention: None. Please add a diode when used for charging. Installation: 8x pillars, 8x 3mm screws Wire Connection: terminal block or soldering terminals; VIN is input; VOUT is output. Dimension: 65.6*40*25mm Display Modes: 1). F-0 mode: Display output voltage 2). F-1 mode: Display input voltage 3). F-2 mode: Display input and output voltage alternately 4). USB mode: Display USB output voltage & turn on/off USB output Note: Output is set as around 20V before leaving factory, if your input is lower than that, please turn potentiometer anticlockwise for at least 10 laps until voltage changes. Package Included: 1x DC Buck Module 4x Copper Cylinder Screws M3*6 4x Double-pass Screws M3*12 8x Roundhead Screws M3*6 Buck Converter Buck Converter 12v to 5v Boost Converter Boost Buck Converter Buck Converter Buck Converter Input Voltage DC 6-32V DC 9-36V DC 6-30V DC 6-30V DC 4-32V DC 6.5-36V Output Voltage DC 1.5-32V 5-5.3V DC 7-32V DC 0.5-30V DC 1.25-30.0V DC 1.2-32V Max Current 5A 3.5A/5A/6A 5A 4A 3A 4.5A CC/CV Mode - Display LCD LCD LCD LED LCD Case - USB Ouput Package Dimensions: 5.39 x 2.95 x 1.85 inches; 2.08 Ounces Item Weight: 2.08 ounces Item model number: 180080AFA Best Sellers Rank: #7,394 in Automotive (See Top 100 in Automotive) #60 in Power Converters Is Discontinued By Manufacturer: No Date First Available: October 26, 2018 Manufacturer: DROK Brand: DROK Output Voltage: 5 Volts

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	DROK
UPC	Does not Apply
MPN	180080AFA
EAN	Does not Apply
