Dc-dc Adjustable Step-up Boost Power Converter Module Xl6009 Replace Lm2577

US $320

Yancheng , ???, China
Mar 12th

Open on mobile:
QR code

DC-DC Adjustable Step-up boost Power Converter Module XL6009 Replace LM2577 Product Description IN-IN + input Positive Input Negative! Positive output OUT + OUT-output negative Test comparison sample reference: Input 3V Output 12V 0.4A 4.8W Input 5V Output 12V 0.8A 9.6W Input 7.4V Output 12V 1.5A 18W Input 12V Output 15V 2A 30W Input 12V Output 16V 2A 32W Input 12V Output 18V 1.6A 28.8W Input 12V Output 19V 1.5A 28.5W Input 12V Output 24V 1 A 24W Vin * Iin * Efficiency = Vout * Iout Vin: Input Voltage Iin: input current Vout: Output Voltage Iout: output current DSN6009 4A is a high-performance step-up switching current (BOOST) module. The module uses the second generation of high-frequency switching technology XL6009E1 core chip performance than the first generation technology LM2577. XL6009 boost module at a lower cost, superior performance, LM2577 module is about to be eliminated. ? Wide input voltage 3V ~ 32V, optimum operating voltage range is 5 ~ 32V; ? Wide Output voltage 5V ~ 35V; ? Built-4A efficient MOSFET switches enable efficiency up to 94%; (LM2577 current is 3A) ? high switching frequency 400KHz, can use a small-capacity filter capacitors that can achieve very good results, the ripple smaller and smaller. (LM2577 frequency only 50KHz) Technical parameters: Model Specification DSN6009 boost module Module Properties Non-isolated boost (BOOST) Rectification Non-Synchronous Rectification Input Range 3V ~ 32V Output Range 5V ~ 35V Input Current 4A (max), no-load 18mA (5V input, 8V output, no-load is less than 18mA. Higher the voltage, the greater the load current.) Conversion efficiency <94% (greater the pressure, the lower the efficiency) Switching frequency 400KHz Output Ripple 50mV (the higher the voltage, the greater the current, the greater the ripple) Load Regulation ± 0.5% Voltage Regulation ± 0.5% Operating Temperature -40 °C ~ +85 °C Dimensions 43mm * 21mm * 14mm (L * W * H) 1pcs Payment Payment Payable To Note PayPal All payments are due within 7 days of the close of auction. Failing to do so, non-paying bidders will be reported to eBay. Shipping Policy Delivery Time We ship to worldwide, it usually takes 10-30 Business Days to delivery. Shipping address We ship to your PayPal address. Please, make sure to provide us with correct, precise, and detailed shipping Address. Send Time Items will be shipped within 1 to 3 business days upon payment received or cleared. Note If you don't receive items over 30 business days, please notify us via eBay message. Return Policy We appreciate your business and offer an instant 7 days return policy.(7 days after receive the item). The returned item has to be in its original condition. We are able to refund your money without shipping cost. Contact us For anything about product, price, shipping or order status, please contact us via eBay message. We love positive feedback and 5 scores DSR. We will leave it for everyone that leaves it for us.
